the required KVA rating are high transformer ambient temperatures (>40° C or >104° F) and
drive operation near the maximum speeds.
Drive/Motor Combination
EN-204/NT-320
EN-204/MG-205
EN-204/MG-208
EN-204/MG-316
EN-208/NT-320
EN-208/NT-330
EN-208/NT-345
EN-208/NT-355
EN-208/MG-316
EN-208/MG-340
EN-208/MG-455
EN-214/NT-345
EN-214/NT-355
EN-214/MG-455
EN-214/MG-490
EN-214/MG-4120
Eb-202/NT-207
Eb-202/NT-212
Eb-203/NT-207
Eb-203/NT-212
Eb-203/MG-316
Eb-205/NT-212
Eb-205/NT-320
Eb-205/NT-330
Eb-205/NT-345
Eb-205/MG-340
Eb-205/MG-316
Transformer output voltage drop may become a limiting factor at motor speeds and loads near
maximum ratings. Typically, higher KVA transformers have lower voltage drop due to lower
impedance.
88
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Suggested KVA Rating
3.0
0.8
1.5
2.3
3.0
3.9
4.3
4.9
2.3
3.9
4.9
4.3
4.3
4.3
6.0
6.5
1.0
1.2
1.0
1.7
2.3
1.7
3.0
3.0
3.0
3.0
2.3
