Epsilon Eb and EN Drives Reference Manual
Front View
Figure 73: EN Input/Output Wiring Diagram
Front View
Figure 74: Epsilon Input/Output Wiring Diagram
102
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
I/O supply
+10 to 30 VDC
Load
2.8 k
1 Amp Fuse
J6
Single point
PE ground.
I/O supply
+10 to 30 VDC
Load
8
Output #3
Output #2
17
7
Output #1
Input #4
12
2
2.8 k Input #3
Input #2 11
Input #1 1
Drive Enable Input 10
I/O Supply + 19
20
I/O Common -
J3
Single point
PE ground.
A highspeed diode
(such as a 1N5819) is
required for inductive
loads such as a relay,
solenoid or contactor.
Load
Load
-
+
24 VDC
A highspeed diode
(such as a 1N5819) is
required for inductive
loads such as a relay,
solenoid or contactor.
Load
Load
1 Amp Fuse
-
+
24 VDC
