CDRO-XXX Cable
WIRE COLOR SOLID/STRIPE
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
BLU/PUR
P
PUR/BLU
ORG/PUR
P
PUR/ORG
BRN/PUR
P
PUR/BRN
RED/BLU
P
BLU/RED
GRN/BLK
P
BLK/GRN
WHT/BLU
P
BLU/WHT
WHT/RED
P
RED/WHT
N/C
GRY/YEL
P
YEL/GRY
GRY/PUR
P
PUR/GRY
BLK/BRN
P
BRN/BLK
BRN/YEL
P
YEL/BRN
WHT/GRN
P
GRN/WHT
GRN/PUR
P
PUR/GRN
N/C
15 14 13 12 11 10 9
30 29 28 27 26 25
44 43 42 41 40 39 38 37 36 35 34 33
Specifications
PIN 1
9
ENCODER OUTPUT A/
8
ENCODER OUTPUT A
24
ENCODER OUTPUT B/
23 ENCODER OUTPUT B
38
ENCODER OUTPUT Z/
37 ENCODER OUTPUT Z
11
ENCODER +5VDC SUPPLY
12
ENCODER SUPPLY COMMON
34
I/O SUPPLY +
16 DRIVE ENABLE INPUT
14
ANALOG COMMAND INPUT -
15 ANALOG COMMAND INPUT +
29
DIAGNOSTIC OUTPUT COMMON
4
INPUT #4
19 OUTPUT #1
26
PULSE INPUT B
40 PULSE INPUT B/
18
OUTPUT #2
17
OUTPUT #3
31
I/O COMMON -
33 I/O SUPPLY +
43
DIAGNOSTIC OUTPUT 1
44 DIAGNOSTIC OUTPUT 2
41
PULSE INPUT A/
27
PULSE INPUT A
8 7 6 5 4 3 2 1
24 23 22 21 20 19 18 17 16
32 31
SOLDER SIDE
