Epsilon Eb and EN Drives Reference Manual
NTE-207 and 212 Brake Motors; Metric Face
159,
FLYING LEAD LENGTH:
39.37±2.00 [1000±50.8]
(-LBNS and -TBNS)
1.98 [50.39]
MAX
NTM-207, 212 -CBNS, TBNS and LBNS Mounting Dimensions
A B
176.40 65.18
207-CBNS
(6.945) (2.566) (0.295)
207-
159.44 65.18
TBNS/
(6.277) (2.566) (0.295)
LBNS
201.80 65.18
212-CBNS
(7.945) (2.566) (0.295)
212-
184.84 65.18
TBNS/
(7.277) (2.566) (0.295)
LBNS
Note
Mounting ears have clearance for 10mm across flats hex nut or 13mm O.D. washer.
216
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
ENCODER CONN: PT02E-16-23P
MATING CONN: PT06E-16-23S (-CBNS)
BRAKE CONN: PT02E-8-3P
MATING CONN: PT06E-8-3S (-CBNS)
MOTOR CONN: PT02E-16-8P
MATING CONN: PT06E-16-8S (-CBNS)
A
mm (inches)
D
C E F
Max
7.49 60.012 2.54 5.80 75.00
(2.363) (0.10) (0.228) (2.953)
7.49 60.012 2.54 5.80 75.00
(2.363) (0.10) (0.228) (2.953)
7.49 60.012 2.54 5.8 75.00
(2.363) (0.10) (0.228) (2.953)
7.49 60.012 2.54 5.8 75.00
(2.363) (0.10) (0.228) (2.953)
MOTOR CONN: PT02E-16-8P
MATING CONN: PT06E-16-8S
(-TBNS)
ENCODER CONN: PT02E-16-23P
MATING CONN: PT06E-16-23S
(-TBNS)
BRAKE CONN: PT02E-8-3P
MATING CONN: PT06E-8-3S
(-TBNS)
J
J
I J K
G
Max Max Min Min
23.51 10.999 13.0 3.97
(0.926) (0.433) (0.512) (0.156)
23.51 10.999 13.0 3.97
(0.926) (0.433) (0.512) (0.156)
23.51 10.999 13.0 3.97
(0.926) (0.433) (0.512) (0.156)
23.51 10.999 13.0 3.97
(0.926) (0.433) (0.512) (0.156)
L M
Min
2.0
(0.079)
2.0
(0.079)
2.0
(0.079)
2.0
(0.079)
