Epsilon Eb and EN Drives Reference Manual
software. PowerTools FM is an easy-to-use Microsoft® Windows®-based setup and
diagnostics tool.
With the FM-1 installed, the base drive functions normally, with some additional features,
including eight more inputs and four more outputs. The additional major features include;
four additional Velocity presets, eight digital Torque presets, two additional Summation
modes, plus an Alternate Operating mode function.
Note
See the FM-1 Speed Module Reference Manual, P/N 400506-01, for more information.

FM-2 Indexing Module

The FM-2 is a compact and rugged indexing module that attaches to the front of the EN drive.
It enables you to initiate up to 16 different indexes, jogging and a single home routine. It also
provides eight digital input lines and four digital output lines in addition to the four input and
three output lines available on the EN drive. The FM-2 is setup using PowerTools FM
software. PowerTools FM is an easy-to-use Microsoft® Windows®-based setup and
diagnostics tool.
Note
See the FM-2 Indexing Module Reference Manual, P/N 400506-01, for more information.

FM-3 and FM-3DN Programming Module

The FM-3 and FM-3DN are compact and rugged programming modules that attach to the
front of the EN drive. They provide eight digital input lines and four digital output lines in
addition to the four input and three output lines available on the EN drive. TheFM-3 and FM-
3DN offer complex motion profiling, along with multi-tasking user programs. A compex
motion profile consists of two or more indexes that are executed in sequence such that the
final velosity of each index except the last is non-zero. Logical instructions between index
statements can provide a powerful tool for altering motion profiles 'on the fly". The FM-3 is
setup using PowerTools PRO software. PowerTools PRO is an easy-to-use Microsoft®
Windows®-based setup and diagnostics tool.
Note
See the FM-3 Programming Module Reference Manual, P/N 400508-01, and the FM-3/
4DN Programming Module Reference Manual, P/N 400508-03, for more information.

FM-4 and FM-4DN Programming Module

The FM-4 and FM-4DN are compact and rugged programming modules that attach to the
front of the EN drive. They provide eight digital input lines and four digital output lines in
190
