Emerson Control Techniques Epsilon Eb Series Reference Manual page 110

Front View
Wire crimp ferrules are recommended:
If 14 AWG, use panduit #PV14-P47.
If 12 AWG, use Panduit #PV10-P55.
Figure 61: EN AC Power Wiring Diagram
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
50/60 Hz
90-264 VAC
L3 is used with the E
Note:
L1 L2 L3 GND
When cycling power make sure AC
power is off for 5 seconds minimum
before reapplying power.
Tighten screws to 5 lb-in.
L1 L2 L3 PE
J1
L1 L2 L3 PE
Installation
-214 only.
N
91
