Using the System

2.8 Using the System
2.8.1 Turning Buzz Navigation (Ceiling-Mounted) On and Off

Switches

The following Buzz Navigation (Ceiling-Mounted) components have mains switches or power
buttons.
Component
Buzz MCU
42" Display In-
wall
Additional 42"
Display In-wall
42" Display On-
wall
Additional 42"
Display On-wall
Connection Unit
Supply Unit / CM
Display / CM
Camera
1
External switch: externally installed mains switches belong to the electrical installation of the OR
Installation. The external mains switches are marked accordingly.
How to Switch On Buzz Navigation (Ceiling-Mounted)
Step
1.
2.
NOTE: MR option: press the power button on the feature panel ① after Buzz Navigation
(Ceiling-Mounted) components and accessories located inside the OR have been powered off
(e.g., for a MR Scan).
48
Mains Switch
Yes
Yes (external
1
switch)
Yes (external
1
switch)
No
No
Yes
Yes (external
1
switch)
Turn the Buzz Navigation (Ceiling-Mounted) mains switches on.
Press the power button on the feature panel ①.
All additional Touch Displays, the CM Display and the CM Camera are powered.
When the power LED on the power button is solid green, the system is ready to use.
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Location Power Button
Back side Yes
OR Installation Yes
OR Installation No
n/a Yes
n/a No
Back side No
OR Installation No
Figure 18
Location
Front side
Front side
n/a
Front side
n/a
n/a
n/a
①
