Ventilation
2.6.3
Ventilation
Ensuring Ventilation
Do not cover or block ventilation openings. Otherwise the system could overheat and be seriously
damaged.
Ventilation Openings on 42" Display On-Wall
Ventilation openings are located on the bottom and sides of the system as marked below.
In-Wall Ventilation Openings
Ventilation openings are located as marked below.
No.
①
②
NOTE: There are no exposed ventilation openings on the In-Wall 42" Display.
NOTE: The MCU must be installed on the bottom plate.
46
①
Component
MCU connection panel
MCU user panel
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Figure 16
②
Figure 17
