SYSTEM OVERVIEW
User Panel: Occupied Ports
The black rectangles in the illustration show which ports are typically reserved for connections to
the Connection Unit and CM Camera. Different configurations are possible:
①
No.
①
②
③
Back Connection Panel
②
①
No.
①
②
③
④
⑤
⑥
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
①
②
③
Component
Connection Unit
CM Camera
3 connections occupied
③
④
Component
Mains Switch
Mains Power Inlet
Potential equalization
Network/USB 2.0 to Feature Panel
Hospital Network (1 GbE)
Hospital Network (10 GbE) - Not in use
①
Figure 10
⑤ ⑥ ⑦
⑪
Figure 11
⑧
⑨
⑩
Can be Used By
Trained user
Trained user
Trained user
Brainlab support
Brainlab support
Brainlab support
