Wireless LAN Connection

2.4.4 Wireless LAN Connection
Wireless LAN Compliance
Buzz Navigation (Ceiling-Mounted) is compliant with the following:
• CE
• FCC
• IC
The WLAN module included in this product cannot be accessed by the end users. The FCC ID
and IC ID of the WLAN module can be found on the label. Please contact Brainlab Support in
case of any related questions.
The wireless device to which the Buzz Navigation (Ceiling-Mounted) shall be connected must
comply with the standard IEEE 802.11 a/b/g/n.
NOTE: Wireless features may be disabled in accordance with local restrictions or pending
approval. Contact Brainlab support for more information.
NOTE: If there is a bad, or no, wireless connection, use a cable connection (LAN cable).
NOTE: The antenna of the WLAN module is behind the Feature Panel glass close to the speaker.
A distance of 20 cm should be maintained between the WLAN antenna and the user.
Wireless LAN Specifications
Specification
Frequency
Modulation Technology
Modulation Type
Supported Security Protocols
Wireless Data Rate
Transmit Power (max)
34 System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Values
The WLAN device uses a frequency band for
sending and receiving:
802.11b/g
2401 - 2495 MHz
802.11a
4910 - 4990 MHz
5150 - 5350 MHz
5470 - 5725 MHz
5725 - 5825 MHz
DSSS, CCK, OFDM
DBPSK, DQPSK, CCK, BPSK, QPSK, 16QAM,
64QAM
Disabled, WEP 64 & 128bit, WPA-PSK(TKIP),
WPA2-PSK(AES)
802.11b 11, 5.5, 2, 1 Mbps
802.11a/g 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n 65, 58.5, 42, 39, 26, 19.5, 13, 6.5
Mbps
802.11b 15 dBm (31.6 mW) 802.11g 12.6 dBm
(18.12 mW) 802.11a 17 dBm (50.1 mW)
