COMPLIANCES AND SPECIFICATIONS
4.4

Physical Specifications

Size and Weight
Component
MCU
42" Display On-Wall
42" Display In-Wall
Additional 42" Display On-Wall
Additional 42" Display In-Wall
CM Display
Additional CM Display
CM Camera
Manual Camera Joint
Connection Unit
Supply Unit
(mounted to wall display)
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Width Height
439 mm 164.5 mm
1189 mm 667 mm
1189 mm 667 mm
1054 mm 667 mm
1054 mm 667 mm
672 mm 411 mm
672 mm 411 mm
116 mm 86 mm
95 mm 450 mm
381 mm 91 mm
169 mm 57 mm
Depth Weight
414 mm 17 kg
103 mm 38 kg
103 mm
(Depth in
38 kg
wall =
98 mm)
103 mm 30 kg
103 mm
(Depth in
30 kg
wall =
98 mm)
73 mm 9.5 kg
73 mm 9.5 kg
613 mm 1.7 kg
192 mm 2.1 kg
377 mm 3.8 kg
300 mm 1.3 kg
75
