SYSTEM OVERVIEW
Connection Unit Rear Connections
No.
①
②
③
④
Related Links
Supported Resolutions on page 72
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
①
②
Component
Fiber optic connections:
• SDI 1 and 2
• USB
• DVI In 1
• IntraOP Data
• DP3 and DVI Out (Mic)
• 3 x Spare
5V DC / 2 A
24 V DC / 0.5 A
Covered when not in use
Potential equalization
Power
③
Figure 14
④
41
