SYSTEM OVERVIEW
2.8.2
System Messages
No Signal Message
This message No Signal Going to Sleep indicates that the Buzz Navigation (Ceiling-Mounted)
42" Display is not receiving a video signal.
Check that the MCU is switched on and booted. If this does not solve the problem, contact
Brainlab support.
Booting Screen
The message booting up... is displayed.
Status LED - Feature Panel
Color
Off
Green
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Status
Explanation
Off
System is turned off (standby).
Flashing
System is booting. Wait until LED is solid before use.
Solid
System is booted and ready for use.
Figure 20
Figure 21
Figure 22
51
