SYSTEM OVERVIEW
Step
2.
How to Secure the Drape
Step
1.
2.
Draped CM Display:
• Do not touch drape with sharp tools.
• To keep sterile field, only touch touchscreen and display housing where covered by drape.
• Dispose of the drape after use.
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Place drape flap over the CM Display so that the orientation arrow is on the back side of
the display and pointing down.
Peel the adhesive liner off one of the adhesive strips on the upper part of the drape and
attach it to the back of the CM Display.
Repeat until all three strips are attached to the back of the display.
Peel the adhesive liner off one of the adhesive strips on the lower part of the drape and
attach it to display post.
Repeat for the second adhesive strip on the lower part of the drape.
Figure 27
