SYSTEM OVERVIEW
No.
①
②
③
④
⑤
NOTE: The MCU is in the server room.
NOTE: If using an additional CM Display, the Supply Unit for it is mounted in the ceiling or in an
opening behind the 42'' Display frame.
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Text in Illustration
Fiber optic signal cable
Camera Ethernet cable
PE cable camera
Copper cable display power
Fiber optic signal cable
Cable bundle
OR
Ceiling
Supply unit
Server room
