SYSTEM OVERVIEW
2.2.1

42" Display

42" Display and Feature Panel
No.
①
②
Display Variants
Location
In-Wall
On-Wall
Additional Touch Display (Optional)
The Buzz Navigation (Ceiling-Mounted) can optionally be installed with an additional 42"
Display.
No.
①
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
①
Component
42" Display
Feature panel
Component
Additional touch display
②
Figure 1
Description
The 42" Display is integrated in the wall
The 42" Display is attached to the surface of
the wall
①
Figure 2
23
