Supported Resolutions

4.3.5 Supported Resolutions
Supported Input Resolutions (MCU Only)
The table below specifies the supported input resolutions for each input available on Buzz
Navigation (Ceiling-Mounted).
Signals outside of the specified resolutions may not be supported. For more information on input
resolution contact Brainlab support.
Imaging Input
S-Video In
Composite In
DVI In
Supported Input Resolutions (MCU and Connection Unit)
The table below specifies the supported input resolutions for each input available on Buzz
Navigation (Ceiling-Mounted).
Signals outside of the specified resolutions may not be supported. For more information on input
resolution contact Brainlab support.
Imaging Input
SDI In
DVI In
72
Color Coding Connector
PAL
mini-DIN
NTSC
PAL
BNC
NTSC
RGB/YCbCr DVI-I
Color Coding Connector
YCbCr BNC
8-Bit RBG DVI-I
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Signal Type Format
576i/25
YC
480i/29.97
576i/25
CVBS
480i/29.97
Contact Brainlab
RGB/YCbCr
support.
Signal Type Format
576i/25
SD-SDI
480i/29.97
720p/50
720p/60
1080i/30
HD-SDI
1080i/60
1080p/25
1080p/30
1080p/50
3G-SDI 1080p/59.94
1080p/60
640x480@60Hz
800x600@60Hz
1024x768@60Hz
1280x720@60Hz
1280x1024@60Hz
Single-Link DVI-D
1920x1080@60Hz
1920x1200@60Hz
1600x1200@60Hz
480p/60
576p/50
