COMPLIANCES AND SPECIFICATIONS
4.6

Electrical Specifications

Power Use
Component
MCU
Converter (3,
MCU Side)
Touch Display
On-Wall
Touch Display In-
Wall
Additional Touch
Display On-Wall
Additional Touch
Display In-Wall
Connection Unit
Supply Unit
Fuse Ratings
Component
MCU
Connection Unit
AC Power Supply
Verify that the AC power supply branch circuit that provides power to Buzz Navigation (Ceiling-
Mounted) is not overloaded. This will reduce the risk of personal injury, fire, or damage to the
equipment.
Buzz Navigation (Ceiling-Mounted) load should not exceed 80% of the branch circuit rating.
Consult the electrical authority responsible for your facility wiring and installation requirements.
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Operating Volt- Current
age
100 - 240 V 8 - 4 A
100 - 240 V 0.16 – 0.08 A
100 - 240 V 3.5 - 1.5 A
100 - 240 V 3.5 - 1.5 A
100 - 240 V 3.5 - 1.5 A
100 - 240 V 3.5 - 1.5 A
100 - 240 V 1.6 - 0.8 A
100 - 240 V 1.5 - 0.8 A
Frequency
50 /60 Hz
50 /60 Hz
50 /60 Hz
50 /60 Hz
50 /60 Hz
50 /60 Hz
50 /60 Hz
50 /60 Hz
Fuse Ratings
2 x T 10A H 250V/5 x 20 mm
2 x T 1.6A H 250V/5 x 20 mm
Power Con-
sumption
Max. 850 W (typi-
cally 350 W)
Max. 19 W
Max. 350 W (typi-
cally 200 W)
Max. 350 W (typi-
cally 200 W)
Max. 350 W (typi-
cally 200 W)
Max. 350 W (typi-
cally 200 W)
Max. 190 W
Max. 190 W
