Brainlab Buzz Navigation System And Technical User Manual page 35

SYSTEM OVERVIEW
Specification
Receive Sensitivity
Antenna Characteristics
Channels
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
Values
802.11b
Rate 11 Mb/s: -86 dBm
Rate 1 Mb/s: -92 dBm
802.11g
Rate 54 Mb/s: -72 dBm
Rate 36 Mb/s: -78 dBm
Rate 18 Mb/s: -84 dBm
Rate 6 Mb/s: -89 dBm
802.11a
Rate 54 Mb/s: -74 dBm
Rate 36 Mb/s: -80 dBm
Rate 18 Mb/s: -86 dBm
Rate 6 Mb/s: -90 dBm
Two (2) U.FL coaxial connectors, 50 Ohms
Max gain @ 5 GHz = 5.5 dBi
Max gain @ 2.4 GHz = 4.1 dBi
US/Canada:
802.11a (36, 40, 44, 48, 52, 56, 60, 64, 100,
104, 108, 112, 116, 132, 136, 140, 149, 153,
157, 161, 165)
802.11b/g (1-11)
Europe:
802.11a
(36,40,44,48,52,56,60,64,100,104,108,112,116,
120,124,128,132,136,140)
802.11b/g (1-13)
Japan:
802.11a
(36,40,44,48 (Known as W52)
52,56,60,64 (Known as W53)
100,104,108,112,116,120,124,128,132,136,140
(Known as W56)
802.11b/g (1-13)
China:
802.11a (149,153,157,161,165)
35
