MCU Ports
No.
⑦
⑧
⑨
⑩
⑪
Back Connection Panel: Occupied Ports
The boxes in the illustration show which ports are typically reserved for connections to other Buzz
Navigation (Ceiling-Mounted) components. Different configurations are possible:
No.
①
②
③
④
⑤
⑥
38
Component
Audio In / Out
• Microphone In
• Audio In
• Audio Out
Video Output and USB 2.0 for Display 1 - 4
Video Output for Display 5
Power connections for transfer line components
4 x 5 V DC / 0.5 A each
NOTE: Only connect equipment specified by Brainlab to the
DC output.
2 x USB 3.0
①
Component
Feature panel
42" Display
CM Display
Additional 42" Display (optional) or additional CM Display (optional)
3 x (+ 1 optional for additional display)
Connection Unit
System and Technical User Guide Rev. 1.2 Buzz Navigation (Ceiling-Mounted) Ver. 1.0
②
⑥
Figure 12
Can be Used By
Brainlab support
Brainlab support
Brainlab support
Brainlab support
Brainlab support
③
④
⑤
