CC Interface Status – Value: The last received value in the IS TLV Value field.
CC Interface Status ‐ Last RX: IS TLV was received in the last received CCM PDU.
Link State Tracking
Enable: When LST is enabled in an instance, Local SF or received 'isDown' in CCM Interface Status TLV, will bring
down the residence port. Only valid in Up‐MEP. The CCM rate must be 1 f/s or faster.
Buttons
Fault Management: Click to go to Fault Management page.
Performance Monitor: Click to go to Performance Monitor page.
Apply: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously saved values.
Messages
UP MEP/MIP is not supported in this domain
Could not set aps config for instance 2
MAX number of Down‐MEPs is exceeded in this flow
Only one MEP can be added for each apply operation
This MIP is not supported
Invalid peer MEP ID
