SIP (32 LSB): Select Any or Specific.
DIP (32 LSB): Select Any or Specific.
DSCP: Select Any, Specific, or Range
Buttons
Apply: Click to save the configuration and move to main QCL page.
Reset: Click to undo any changes made locally and revert to previously saved values.
Cancel: Return to the previous page without saving the configuration change.
Control buttons:
Insert New QCE before this QCE.
Move QCE up.
Edit QCE.
Move QCE down.
Delete QCE.
Example
:
