Transition Networks
Router Port: Display which ports act as router ports. A router port is a port on the Ethernet switch that leads
towards the Layer 3 multicast device or IGMP querier.
Port: Switch port number.
Status: Indicate the type of specific port:
Static denotes the specific port is configured to be a router port.
Dynamic denotes the specific port is learnt to be a router port.
Both denote the specific port is configured or learnt to be a router port.
Buttons
Auto‐refresh : Check this box to refresh the page automatically every 3 seconds.
Refresh: Click to refresh the page immediately.
Clear: Clears all Statistics counters.

33786 Rev. A

https://www.transition.com
SMxxTAT4Xx Web User Guide
Page 130 of 340
