Transition Networks SMxxTAT4Xx Web User Guide
Client Statistics
Transmit to Client: The number of relayed packets from server to client.
Transmit Error: The number of packets that resulted in error while being sent to servers.
Receive from Client: The number of received packets from server.
Receive Agent Option: The number of received packets with relay agent information option.
Replace Agent Option: The number of packets which were replaced with relay agent information option.
Keep Agent Option: The number of packets whose relay agent information was retained.
Drop Agent Option: The number of packets that were dropped which were received with relay agent
information.
Buttons
Auto‐refresh: Check this box to refresh the page automatically every 3 seconds.
Refresh: Click to refresh the page immediately.
Clear: Clear all statistics.
Function select box: Use the dropdown to select the set of statistics to
display.
Port select box: Use the dropdown to select the port which you want to view statistics on.
