IBM Flex System x440 Compute Node Installation And Service Manual page 66

Index Description
Microprocessor installation tool
Miscellaneous parts kit
RFID label tag assembly - EMEA
RFID label tag assembly - US
ServeRAID-M5100 series hard disk drive backplane
ServeRAID-M5100 series Flex cable assembly
ServeRAID-M5100 series solid state drive Flex expansion cable
ServeRAID-M5100 Series super capacitor
ServeRAID-M5100 Series super capacitor power cable
Thermal grease kit
Consumable parts
Consumable parts are not covered by the IBM Statement of Limited Warranty. The
following consumable parts are available for purchase from the retail store.
To order a consumable part, complete the following steps:
1. Go to http://www.ibm.com.
2. From the Products menu, select Upgrades, accessories & parts.
3. Click Obtain maintenance parts; then, follow the instructions to order the part
54
IBM Flex System x440 Compute Node Types 7917 and 2584: Installation and Service Guide
Table 4. Consumable parts
Index Description
1 Top cover (when ordering this part, order the Label kit
(part number (00D6313)
3 Air baffle above DIMMs (Type 2584, models C2x, C4x)
(Type 7917, models A2x, A4x, B2x, B4x, C2x, C4x, D2x,
D4x, F2x, F4x)
7 Filler, 2.5 inch hard disk drive bay (Type 2584, models C2x,
C4x) (Type 7917, models A2x, A4x, B2x, B4x, C2x, C4x,
D2x, D4x, F2x, F4x)
10 Filler, microprocessor socket (Type 2584, models C2x, C4x)
(Type 7917, models : A2x, A4x, B2x, B4x, C2x, C4x, D2x,
D4x, F2x, F4x)
CMOS battery, 3.0 volt (all models)
CRM handle kit
Hard disk drive cage, SAS
Rear bulkhead assembly full wide
ServeRAID-M5115 left-side air baffle
ServeRAID-M5115 center air baffle
from the retail store.
CRU part CRU part
number (Tier number (Tier
1) 2)
94Y9955
46M2832
00E6323
74Y8800
44E4763
00D5089
00D5078
81Y4579
44E4767
41Y9292
Consumable part
number
46M2830
81Y5177
44T2248
00D6325
33F8354
46M2828
46M2829
46M2833
00D5080
46C9933
