80010202-2801ffff Sensor Planar VBAT has detected low battery voltage.
Explanation: The CMOS battery voltage has dropped below its specified threshold.
May also be shown as 800102022801ffff or 0x800102022801ffff
Severity: Error
Alert Category: Critical - Voltage
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0480
SNMP Trap ID: 1
Automatically notify Support: No
User response: Replace the CMOS battery.
80010902-0701ffff Sensor [NumericSensorElementName] has detected high voltage.
Explanation: A voltage has exceeded its specified threshold.
May also be shown as 800109020701ffff or 0x800109020701ffff
Severity: Error
Alert Category: Critical - Voltage
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0494
SNMP Trap ID: 1
Automatically notify Support: Yes
User response: Use one of the following procedures:
v If the specified sensor is Planar 3.3V or Planar 5V, replace the system board.
v If the specified sensor is Planar 12V, check the Chassis Management Module or Flex System Manager event log for
power-supply-related issues, and resolve those issues. If the problem remains, replace the system board.
80010b01-3701ffff Numeric sensor Inlet 1 Temp going high (upper non-recoverable) has asserted. has asserted.
Explanation: The inlet temperature has exceeded its specified threshold. The compute node has initiated a hard
shutdown.
May also be shown as 80010b013701ffff or 0x80010b013701ffff
Severity: Error
Alert Category: Critical - Temperature
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0498
SNMP Trap ID: 0
Automatically notify Support: No
User response: Complete the following steps until the problem is solved:
1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and
correctly installed.
3. Make sure that the room temperature is within operating specifications.
