806f010f-2201ffff • 806f011b-1f03ffff
Severity: Error
Alert Category: Critical - Hard Disk drive
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0164
SNMP Trap ID: 5
Automatically notify Support: Yes
User response: Complete the following steps until the problem is solved:
1. Check the Support Portal for service bulletins and RETAIN tips related to your drive.
2. Check the Support Portal for firmware updates related to your drive.
3. Replace the drive.
4. Check for any other RAID-related errors.
806f010f-2201ffff The System [ComputerSystemElementName] encountered a firmware hang.
Explanation: This message is for the use case when an implementation has detected a System Firmware Hang.
May also be shown as 806f010f2201ffff or 0x806f010f2201ffff
Severity: Error
Alert Category: System - Boot failure
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0186
SNMP Trap ID: 25
Automatically notify Support: No
User response: This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged
IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Info Center
for the appropriate user response.
806f011b-0c01ffff The connector LightPath has encountered a configuration error.
Explanation: The light path LED card is not detected.
May also be shown as 806f011b0c01ffff or 0x806f011b0c01ffff
Severity: Error
Alert Category: Critical - Other
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0266
SNMP Trap ID: 50
Automatically notify Support: Yes
User response: Complete the following steps until the problem is solved:
1. Make sure that the cable from the light path LED card to the system board is securely connected.
2. Replace the light path diagnostics panel.
806f011b-1f03ffff The connector [PhysicalConnectorElementName] has encountered a configuration error.
Explanation: The connections of the SAS cable between the SAS backplane and the planar are not complete.
May also be shown as 806f011b1f03ffff or 0x806f011b1f03ffff
Severity: Error
Alert Category: Critical - Other
