Automatically notify Support: Yes
User response: This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged
IMM message text. Please refer to the UEFI diagnostic code in the "UEFI diagnostic code" section of the Information
Center for the appropriate user response.
806f0313-1701ffff A software NMI has occurred on system [ComputerSystemElementName].
Explanation: A software NMI has occurred. The compute node might have restarted, depending on the
configuration setting.
May also be shown as 806f03131701ffff or 0x806f03131701ffff
Severity: Error
Alert Category: Critical - Other
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0228
SNMP Trap ID: 50
Automatically notify Support: No
User response: Check the operating-system logs and resolve any issues related the NMI.
806f0323-2101ffff Power cycle of system [ComputerSystemElementName] initiated by watchdog IPMI Watchdog.
Explanation: The IPMI watchdog timer has expired. The compute node has been powered off and powered on.
May also be shown as 806f03232101ffff or 0x806f03232101ffff
Severity: Info
Alert Category: System - Other
Serviceable: No
CIM Information: Prefix: PLAT and ID: 0374
SNMP Trap ID:
Automatically notify Support: No
User response: Information only; no action is required.
806f0409-0701ffff [PowerSupplyElementName] has lost power.
Explanation: This message is for the use case when an implementation has detected a Power Unit that has lost
power.
May also be shown as 806f04090701ffff or 0x806f04090701ffff
Severity: Info
Alert Category: System - Other
Serviceable: No
CIM Information: Prefix: PLAT and ID: 0112
SNMP Trap ID:
Automatically notify Support: No
User response: Information only; no action is required.
