816f000d-0406ffff • 816f000f-2201ffff
v If drive is properly seated, replace the drive.
816f000d-0406ffff The Drive [StorageVolumeElementName] has been removed from unit
[PhysicalPackageElementName].
Explanation: Presence of drive 6 is no longer detected. If hard drive is absent from drive bay a filler is required.
May also be shown as 816f000d0406ffff or 0x816f000d0406ffff
Severity: Error
Alert Category: Critical - Hard Disk drive
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0163
SNMP Trap ID: 5
Automatically notify Support: No
User response:
v If drive was intentionally removed, no action required.
v Make sure that the drive properly seated.
v If drive is properly seated, replace the drive.
816f000d-0407ffff The Drive [StorageVolumeElementName] has been removed from unit
[PhysicalPackageElementName].
Explanation: Presence of drive 7 is no longer detected. If hard drive is absent from drive bay a filler is required.
May also be shown as 816f000d0407ffff or 0x816f000d0407ffff
Severity: Error
Alert Category: Critical - Hard Disk drive
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0163
SNMP Trap ID: 5
Automatically notify Support: No
User response:
v If drive was intentionally removed, no action required.
v Make sure that the drive properly seated.
v If drive is properly seated, replace the drive.
816f000f-2201ffff The System [ComputerSystemElementName] has detected a POST Error deassertion.
Explanation: This message is for the use case when an implementation has detected that Post Error has deasserted.
ABR Status. Firmware Error. Sys Boot Status.
May also be shown as 816f000f2201ffff or 0x816f000f2201ffff
Severity: Info
Alert Category: Critical - Other
Serviceable: No
CIM Information: Prefix: PLAT and ID: 0185
SNMP Trap ID: 50
Automatically notify Support: No
User response: This is a UEFI detected event. The UEFI diagnostic code for this event can be found in the logged
