S.680B9 • W.3058009
S.680B9 [S.680B9] External QPI Link Failure Detected.
Explanation: External QPI Link Failure Detected
Severity: Error
User response: Complete the following steps:
1.
Check IBM support site for an applicable service bulletin or firmware update that applies to this error.
2. Inspect processor socket for foreign debris or damage. If debris is found remove debris.
3. If error recurs, or socket damage is found, replace the system board (Trained Service technician only) .
W.11004 [W.11004] A processor within the system has failed the BIST.
Explanation: Processor Self Test Failure Detected
Severity: Warning
User response: Complete the following steps:
1. If the Processor or firmware was just updated, check IBM support site for an applicable service bulletin or
firmware update that applies to this Processor error.
2. (Trained service technician only) If there are multiple Processor's, swap Processor's to move affected Processor to
another Processor socket and retry. If problem follows the affected Processor, or this is a single Processor system,
replace the Processor. Inspect Processor socket on each Processor removal and replace system board first if
damaged or mis-aligned pins are found.
3. (Trained Service technician only) Replace the system board.
W.3048006 [W.3048006] UEFI has booted from the backup flash bank due to an Automatic Boot Recovery (ABR)
event.
Explanation: Automated Boot Recovery, Booting Backup UEFI Image
Severity: Warning
User response: Complete the following steps:
1. Check IBM support site for an applicable service bulletin or firmware update that applies to this error.
2. Reflash Primary UEFI image. Refer to UEFI Recovery section of service information for this product.
3. (Trained service technician only) Replace the system board.
W.305000A [W.305000A] An invalid date and time have been detected.
Explanation: RTC Date and Time Incorrect
Severity: Warning
User response: Complete the following steps:
1. Check IMM/chassis event log. This event should immediately precede 0068002 error. Service that event or any
other battery related errors.
2. Use F1 Setup to reset date and time. If problem returns after a system reset, replace CMOS battery.
3. If problem persists then check IBM support site for an applicable service bulletin or firmware update that applies
to this error.
4. Trained Service technician only) Replace the system board.
W.3058009 [W.3058009] DRIVER HEALTH PROTOCOL: Missing Configuraiton. Requires Change Settings From
F1.
Explanation: DRIVER HEALTH PROTOCOL: Missing Configuration. Requires Change Settings From F1
Severity: Warning
User response: Complete the following steps:
