806f0107-0304ffff • 806f0109-0701ffff
806f0107-0304ffff An over-temperature condition has been detected on [ProcessorElementName].
Explanation: The temperature of microprocessor 4 has exceeded the critical level, causing a hard shutdown of the
compute node.
May also be shown as 806f01070304ffff or 0x806f01070304ffff
Severity: Error
Alert Category: Critical - Temperature
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0036
SNMP Trap ID: 0
Automatically notify Support: No
User response: Complete the following steps until the problem is solved:
1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and
correctly installed.
3. Make sure that the room temperature is within operating specifications.
4. Make sure that the microprocessor heat sink is securely installed.
5. Make sure that the microprocessor heat sink is installed correctly and the thermal material is correctly applied.
6. Replace microprocessor 4.
806f0107-2584ffff An over-temperature condition has been detected on [ProcessorElementName].
Explanation: The temperature of the specified microprocessor has risen above its specified threshold.
May also be shown as 806f01072584ffff or 0x806f01072584ffff
Severity: Error
Alert Category: Critical - Temperature
Serviceable: Yes
CIM Information: Prefix: PLAT and ID: 0036
SNMP Trap ID: 0
Automatically notify Support: No
User response: Complete the following steps until the problem is solved:
1. Check the Chassis Management Module or Flex System Manager event log for any fan- or cooling-related issues.
2. Make sure that the airflow at the front and rear of the chassis is not obstructed and that fillers are in place and
correctly installed.
3. Make sure that the room temperature is within operating specifications.
4. Make sure that the heat sink for the specified microprocessor is securely installed.
5. Make sure that the heat sink for the specified microprocessor is installed correctly and the thermal material is
correctly applied.
6. Replace the specified microprocessor.
806f0109-0701ffff system board 1 has been Power Cycled.
Explanation: The compute node has been powered off and powered on.
May also be shown as 806f01090701ffff or 0x806f01090701ffff
Severity: Info
Alert Category: System - Other
Serviceable: No
