SmartDC

Maintenance Guide

Figure 6-18 Removing the front cover from a camera

Step 2 Remove the screws from the camera.

Figure 6-19 Removing a camera

Step 3 Remove the monitoring network cable from the camera and remove the camera.

Step 4 Install the new camera. Then, set parameters and commission the camera according to the

commissioning guide.

Step 5 Verify that the camera is normal.

----End

6.4.4 Parts Replacement for the Access System

Impact on the System

The aisle access control system cannot be used.

Issue 04 (2020-03-25)

6 Parts Replacement
