Test Procedures
8.3.6 MDCIC in Parallel Drive Systems
8
8
1
2
3
4
5
1
MK110: Connector for current scaling card for module 4
2
MK109: Connector for current scaling card for module 3
3
MK108: Connector for current scaling card for module 2
4
MK107: Connector for current scaling card for module 1
5
MK100: MDCIC-to-control card connection
Illustration 8.6 MDCIC in Parallel Drive Systems
96
®
VLT
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
6
MK113: Connector to module 3
7
MK114: Connector to module 4
8
MK111: Connector to module 1
9
MK112: Connector to module 2
–
–
Danfoss A/S © 02/2019 All rights reserved.
6
7
8
9
MG94A502
