E1h–E4h Drive Disassembly a...
1
2
3
4
5
6
7
8
9
10
13
13
1
Inrush card frame
2
Nut (7 mm)
3
Inrush busbars
4
Nut (7 mm)
5
Rectifier(-) bus plate
Illustration 13.6 Inrush Card Frame and Rectifier Bus Plates
272
®
VLT
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
6
Bus plate screw (T40)
7
Insulator sheet
8
Insulator sheet alignment pin
9
Rectifier(+) bus plate
10
Bus plate screw (T40)
Danfoss A/S © 02/2019 All rights reserved.
MG94A502
