E1h–E4h Drive Disassembly a...
1
2
3
4
1
Cable retaining clip
2
SCR/diode module
13
13
3
Screw (T40)
Illustration 13.7 SCR/Diode Modules
274
®
VLT
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
4
5
6
Danfoss A/S © 02/2019 All rights reserved.
SCR input busbar
Screw (T25)
Nut (8 mm)
5
6
MG94A502
