Spare Parts

15 Spare Parts
BUSBAR REPLACEMENT
Busbars used in some units are aluminum. Spare part busbars are plated copper when available. Plated copper busbars are
useable for all units.
To find spare part numbers and descriptions, use either of these methods:
•
Use the Drive Configurator on the Danfoss website.
•
See the spare parts lists in this chapter.
NOTICE
PARTS LIST DETAILS
The parts numbers listed in the following tables are current at the time of publication. Updated spare parts information
can be found with the Drive Configurator.
All spare parts are suitable for conformal coated drives and can be used in either coated or non-conformal coated drives.

15.1.1 Using the Drive Configurator Tool

For the latest spare parts information, visit the Danfoss website using the following directions.
1. Go to https://vltconfig.danfoss.com/.
2. Under Configurable Products, select the product. The product is listed on the product label and in the first 5 digits
of the type code (T/C). See chapter 3.4 Enclosure Size Identification.
3. Under Configure by Type Code, enter the type code from the drive label and click Configure. Alternatively, select the
drive features in the required fields and click Accept.
4. Check the Configuration Details tab to confirm that it matches the unit.
5. Select the Accessories tab or DrivePro tab to display spare parts and kits.
6. Use the right arrow to scroll through the parts list to find the spare part.
Click the part number for a detailed description of the part. The Drive Configurator is under development and subject to
change. For additional information on spare parts, contact Danfoss.

15.1.2 Spare Parts Lists

This section includes the following tables for referencing spare part numbers:
•
Recommended Current Scaling Cards
•
Spare Parts List, D1h–D4h, 200–240 V AC (T2)
•
Spare Parts List, D1h–D8h, 380–480/500 V AC (T4/T5)
•
Spare Parts List, D1h–D8h, 525–690 V AC (T7)
•
Spare Parts List, E1h–E4h Drives, 380–480/500 V AC (T4/T5)
•
Spare Parts List, E1h–E4h Drives, 525–690 V AC (T7)
