Drive and Motor Application...
1
7 7
2
3
4
L1
L2
L3
PE
5
1 PLC
2
Minimum 16 mm
3 Control cables
4 Minimum 200 mm (7.9 in) between control cables, motor
cables, and mains cables.
5 Mains supply
6 Bare (unpainted) surface
7 Star washers
8 Brake cable (shielded)
9 Motor cable (shielded)
Illustration 7.5 Example of Proper EMC Installation
88
®
VLT FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
2 (6 AWG) equalizing cable
Danfoss A/S © 02/2019 All rights reserved.
90
4
4
PE
10 Mains cable (unshielded)
11 Output contactor
12 Cable insulation stripped
13 Common ground busbar. Follow local and national
requirements for cabinet grounding.
14 Brake resistor
15 Metal box
16 Connection to motor
17 Motor
18 EMC cable gland
6
7
8
9
10
11
12
13
14
15
u
16
v
w
17
18
