Special Test Equipment
SPLIT BUS POWER SUPPLY (130B4146)
24 V DC
Illustration 9.2 Connection During Split Bus Mode for a Single Drive
(+)
SPLIT BUS POWER SUPPLY (130B4146)
24 V DC
(+)
(-)
Illustration 9.3 Connection During Split Bus Mode in Parallel Drive
MG94A502
Service Guide
POWER CARD
650 V DC
DC Bus Connector (MK902)
(-)
POWER CARD
650 V DC
SMPS
DC Bus Connector (MK902)
Danfoss A/S © 02/2019 All rights reserved.
Split Bus Connector (MK901)
SMPS
A C
Split Bus Connector (MK901)
44-Pin
44-Pin
Ribbon
Ribbon
Cable
Cable
LCP
MDCIC
CONTROL
CARD
SERVICE KIT
121
9
9
