Product Overview
3.6 Product Views
3.6.1 Exploded View of D1h/D3h/D5h/D6h/J8 Drive
3
3
1
2
3
4
5
6
7
8
9
10
1
Local control panel (LCP) and bracket
2
Control card and mounting plate
3
Power card and mounting plate
4
RFI filter (optional)
5
Gate drive card
6
Gate drive card support bracket
7
Mains input terminals
8
Motor output terminals
9
Power terminal mounting plate
Illustration 3.2 Exploded View D3h Drive (D1h/D5h/D6h/J8 Drives are Similar).
22
®
VLT
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
10
11
12
13
14
15
16
17
18
Danfoss A/S © 02/2019 All rights reserved.
Balance/high frequency card
Top fan (IP20 only)
Inrush card
Regen/load share terminals (optional)
SCR/diode modules
Brake IGBT module (optional)
IGBT modules
Capacitor bank
Heat sink fan
11
12
13
14
15
16
17
18
MG94A502
