NOTICE
ENCLOSURE SIZE
Enclosure size designations are used throughout this
guide where procedures or components differ between
drives based on size. Refer to chapter 3.4 Enclosure Size
Identification and chapter 3.5 Enclosure Size Definitions in
determining enclosure size.
11.2 D2h/D4h/D7h/D8h/J9 Disassembly and Assembly
11.2.1 General Information
This chapter contains instructions for disassembly and assembly of D2h/D4h drives. The instructions can be used for related
drives and drive modules listed in Table 11.2.
Drive model
D2h drive
D4h drive
D7h drive
D8h drive
J9 drive
Parallel drive modules
Enclosed drive module
Table 11.2 Drives and Drive Modules Related to D2h Drive
MG94A502
Service Guide
Description
Standard drive in an IP21/IP54 (UL type 1/12) enclosure
Similar to D2h, but IP20/Chassis drive with no enclosure
Similar to D2h drive, but with extended options cabinet
Similar to D2h drive, but with tall extended options cabinet
Similar to D2h, but regen terminals are standard, and no brake option is available
Similar to D4h, but includes 2 or 4 drive modules in Db2/Db4 parallel drive systems
Similar to D4h, but includes 1 drive module in D10h enclosed drive system
Danfoss A/S © 02/2019 All rights reserved.
11
11
187
