12.3 Parallel Drive Module Disassembly and Assembly

12.3.1 General Information

The instructions in this chapter include procedures for disassembly of parallel drive systems in IP00 enclosures. The parallel
drive modules within the systems are similar to the D3h/D4h drives described in previous chapters. Instead of an individual
control card, the VLT® Parallel Drive Modules have a blank mounting plate and are controlled by the MDCIC. The
disassembly of the blank mounting plate is described in this chapter. For other disassembly procedures, refer to Table 12.2.
Parallel drive system
Da2 system
Da4 system
Db2 system
Db4 system
Table 12.2 Additional Disassembly Instructions
MG94A502
Service Guide
Parallel drive module disassembly instructions
Refer to chapter 10 D1h/D3h/D5h/D6h/J8 Drive Disassembly and Assembly.
Refer to chapter 10 D1h/D3h/D5h/D6h/J8 Drive Disassembly and Assembly.
Refer to chapter 11 D2h/D4h/D7h/D8h/J9 Unit Disassembly and Assembly.
Refer to chapter 11 D2h/D4h/D7h/D8h/J9 Unit Disassembly and Assembly.
