Da2/Db2/Da4/Db4 Parallel Sy...
12
12
1
DC fuse and microswitch
2
44-pin connector for cable from MDCIC
3
Blank cover plate (no LCP)
4
Blank mounting plate (no control card)
5
Power card
Illustration 12.7 Parallel Drive Module
256
®
VLT
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
1
2
3
4
5
6
7
8
9
Danfoss A/S © 02/2019 All rights reserved.
6
AC input busbars
7
AC fuses
8
Mains terminals to drive module
9
Mixing fan
10
Output terminals to motor
10
MG94A502
