Table 2 Common (*) Commands Summary (continued)
Command
*SRE <mask> (see
page 193)
n/a
page 197)
*TRG (see
n/a
page 199)
*WAI (see
Keysight InfiniiVision M9241/42/43A PXIe Oscilloscopes SCPI Programmer's Guide
Query
page 194)
*SRE? (see
page 195)
*STB? (see
n/a
page 198)
*TST? (see
n/a
Commands Quick Reference
Options and Query Returns
<mask> ::= sum of all bits that
are set, 0 to 255; an integer in
NR1 format. <mask> ::= following
values:
Bit Weight Name Enables
--- ------ ---- ----------
7 128 OPER Operation Status Reg
6 64 ---- (Not used.)
5 32 ESB Event Status Bit
4 16 MAV Message Available
3 8 ---- (Not used.)
2 4 MSG Message
1 2 USR User
0 1 TRG Trigger
<value> ::= 0 to 255; an integer
in NR1 format, as shown in the
following:
Bit Weight Name "1" Indicates
--- ------ ---- ---------------
7 128 OPER Operation status
condition occurred.
6 64 RQS/ Instrument is
MSS requesting service.
5 32 ESB Enabled event status
condition occurred.
4 16 MAV Message available.
3 8 ---- (Not used.)
2 4 MSG Message displayed.
1 2 USR User event
condition occurred.
0 1 TRG A trigger occurred.
n/a
<result> ::= 0 or non-zero value;
an integer in NR1 format
n/a
