Keysight InfiniiVision M9241A Scpi Programmer's Manual page 154

5
Commands Quick Reference
Table 52 :TRIGger:EBURst Commands Summary (continued)
Command
:TRIGger:EBURst:SLOPe
<slope> (see
page 1079)
:TRIGger:EBURst:SOURc
e <source> (see
page 1080)
Table 53 :TRIGger[:EDGE] Commands Summary
Command
:TRIGger[:EDGE]:COUPl
ing {AC | DC |
LFReject} (see
page 1082)
:TRIGger[:EDGE]:LEVel
<level> [,<source>]
page 1083)
(see
:TRIGger[:EDGE]:REJec
t {OFF | LFReject |
HFReject} (see
page 1084)
:TRIGger[:EDGE]:SLOPe
<polarity> (see
page 1085)
:TRIGger[:EDGE]:SOURc
e <source> (see
page 1086)
154
Query
:TRIGger:EBURst:SLOPe
page 1079)
? (see
:TRIGger:EBURst:SOURc
page 1080)
e? (see
Query
:TRIGger[:EDGE]:COUPl
page 1082)
ing? (see
:TRIGger[:EDGE]:LEVel
? [<source>] (see
page 1083)
:TRIGger[:EDGE]:REJec
page 1084)
t? (see
:TRIGger[:EDGE]:SLOPe
page 1085)
? (see
:TRIGger[:EDGE]:SOURc
page 1086)
e? (see
Keysight InfiniiVision M9241/42/43A PXIe Oscilloscopes SCPI Programmer's Guide
Options and Query Returns
<slope> ::= {NEGative | POSitive}
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
Options and Query Returns
{AC | DC | LFReject}
For internal triggers, <level>
::= .75 x full-scale voltage from
center screen in NR3 format.
For external triggers, <level>
::= ±(external range setting) in
NR3 format.
<source> ::= {CHANnel<n> |
EXTernal}
<n> ::= 1 to (# analog channels)
in NR1 format
{OFF | LFReject | HFReject}
<polarity> ::= {POSitive |
NEGative | EITHer | ALTernate}
<source> ::= {CHANnel<n> |
EXTernal | WGEN | WGEN1 | WMOD}
<n> ::= 1 to (# analog channels)
in NR1 format
Note: WGEN and WGEN1 are
equivalent.
