Keysight InfiniiVision M9241A Scpi Programmer's Manual page 448

21
:MEASure Commands
Table 96 :MEASure Commands Summary (continued)
Command
:MEASure:VTOP
[<source>] (see
page 515)
:MEASure:WINDow
page 516)
<type> (see
:MEASure:XMAX
[<source>] (see
page 517)
:MEASure:XMIN
[<source>] (see
page 518)
Introduction to The commands in the MEASure subsystem are used to make parametric
:MEASure measurements on displayed waveforms.
Commands
448
Query
:MEASure:VTOP?
[<source>] (see
page 515)
:MEASure:WINDow? (see
page 516)
:MEASure:XMAX?
[<source>] (see
page 517)
:MEASure:XMIN?
[<source>] (see
page 518)
Keysight InfiniiVision M9241/42/43A PXIe Oscilloscopes SCPI Programmer's Guide
Options and Query Returns
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= voltage at the
top of the waveform in NR3 format
<type> ::= {MAIN | ZOOM | AUTO |
GATE}
<source> ::= {CHANnel<n> |
FUNCtion<m> | FFT | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= horizontal
value of the maximum in NR3
format
<source> ::= {CHANnel<n> |
FUNCtion<m> | FFT | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= horizontal
value of the minimum in NR3
format
