:SBUS<n> Commands
:SBUS<n>:UART Commands
These commands are only valid when the UART/RS-232 triggering and serial decode option
NOTE
(COMP license) has been installed.
Table 112 :SBUS<n>:UART Commands Summary
Command
:SBUS<n>:UART:BASE
page 902)
<base> (see
:SBUS<n>:UART:BAUDrat
e <baudrate> (see
page 903)
:SBUS<n>:UART:BITorde
r <bitorder> (see
page 904)
n/a
:SBUS<n>:UART:COUNt:R
page 906)
ESet (see
n/a
n/a
:SBUS<n>:UART:FRAMing
page
<value> (see
:SBUS<n>:UART:PARity
<parity> (see
page 910)
:SBUS<n>:UART:POLarit
y <polarity> (see
page 911)
900
Query
:SBUS<n>:UART:BASE?
page 902)
(see
:SBUS<n>:UART:BAUDrat
page
e? (see
:SBUS<n>:UART:BITorde
page
r? (see
:SBUS<n>:UART:COUNt:E
page
RRor? (see
n/a
:SBUS<n>:UART:COUNt:R
XFRames? (see
page 907)
:SBUS<n>:UART:COUNt:T
XFRames? (see
page 908)
:SBUS<n>:UART:FRAMing
909) page 909)
? (see
:SBUS<n>:UART:PARity?
page 910)
(see
:SBUS<n>:UART:POLarit
page
y? (see
Keysight InfiniiVision M9241/42/43A PXIe Oscilloscopes SCPI Programmer's Guide
Options and Query Returns
<base> ::= {ASCii | BINary | HEX}
<baudrate> ::= integer from 100
903)
to 8000000, 10000000, or 12000000
<bitorder> ::= {LSBFirst |
904)
MSBFirst}
<frame_count> ::= integer in NR1
905)
format
n/a
<frame_count> ::= integer in NR1
format
<frame_count> ::= integer in NR1
format
<value> ::= {OFF | <decimal> |
<nondecimal>}
<decimal> ::= 8-bit integer from
0-255 (0x00-0xff)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<parity> ::= {EVEN | ODD | NONE}
<polarity> ::= {HIGH | LOW}
911)
