Table 49 :TIMebase Commands Summary
Command
:TIMebase:MODE
<value> (see
page 1041)
:TIMebase:POSition
page 1042)
<pos> (see
:TIMebase:RANGe
<range_value> (see
page 1043)
:TIMebase:REFClock
{{0 | OFF} | {1 |
page 1044)
ON}} (see
:TIMebase:REFerence
{LEFT | CENTer |
RIGHt | CUSTom} (see
page 1045)
:TIMebase:REFerence:L
OCation <loc> (see
page 1046)
:TIMebase:SCALe
<scale_value> (see
page 1047)
:TIMebase:VERNier {{0
| OFF} | {1 | ON}}
page 1048)
(see
:TIMebase:WINDow:POSi
tion <pos> (see
page 1049)
:TIMebase:WINDow:RANG
e <range_value> (see
page 1050)
:TIMebase:WINDow:SCAL
e <scale_value> (see
page 1051)
Keysight InfiniiVision M9241/42/43A PXIe Oscilloscopes SCPI Programmer's Guide
Query
:TIMebase:MODE? (see
page 1041)
:TIMebase:POSition?
page 1042)
(see
:TIMebase:RANGe? (see
page 1043)
:TIMebase:REFClock?
page 1044)
(see
:TIMebase:REFerence?
page 1045)
(see
:TIMebase:REFerence:L
OCation? (see
page 1046)
:TIMebase:SCALe? (see
page 1047)
:TIMebase:VERNier?
page 1048)
(see
:TIMebase:WINDow:POSi
page 1049)
tion? (see
:TIMebase:WINDow:RANG
page 1050)
e? (see
:TIMebase:WINDow:SCAL
page 1051)
e? (see
Commands Quick Reference
Options and Query Returns
<value> ::= {MAIN | WINDow | XY |
ROLL}
<pos> ::= time from the trigger
event to the display reference
point in NR3 format
<range_value> ::= time for 10 div
in seconds in NR3 format
{0 | 1}
<return_value> ::= {LEFT | CENTer
| RIGHt | CUSTom}
<loc> ::= 0.0 to 1.0 in NR3
format
<scale_value> ::= time/div in
seconds in NR3 format
{0 | 1}
<pos> ::= time from the trigger
event to the zoomed view
reference point in NR3 format
<range value> ::= range value in
seconds in NR3 format for the
zoomed window
<scale_value> ::= scale value in
seconds in NR3 format for the
zoomed window
