Page 1 X-Series Signal Analyzers Short Range Comms & IoT Mode E6680A E6680E M9410A M9411A M9415A M9416A N9000B N9010B N9020B N9030B N9040B N9041B USER'S & PROGRAMMER'S REFERENCE...
Page 2 MERCHANTABILITY AND FITNESS FOR A to US government customers under its PARTICULAR PURPOSE. KEYSIGHT SHALL Keysight Technologies, Inc. as governed by standard commercial license, which is NOT BE LIABLE FOR ERRORS OR FOR United States and international copyright...
Page 3 X-Series Signal Analyzers Short Range Comms & IoT Mode User's & Programmer's Reference Table Of Contents Short Range Comms & IoT Mode User's & Programmer's Reference Table Of Contents 1 Documentation Roadmap 1.1 Products Covered by this Document 1.2 Additional Documentation 2 User Interface 2.1 Screen Tabs...
Page 4 Table Of Contents 2.3.1 Window Title 2.3.2 Measurement Data 2.3.3 Annotation Hotspot 2.4 Menu Panel 2.4.1 Right-Click Menu 2.4.1.1 Add to User Menu 2.4.1.2 Help on this setting 2.4.2 User Menu 2.5 Cancel key 2.6 Onscreen Keyboard key 2.7 Touch On/Off Key 2.8 Tab key 2.9 Local Button 2.10 Control Bar...
Page 5 Table Of Contents 2.18.2 Screen List (Remote only command) 2.19 Fullscreen 3 Short-Range Comms & IoT Mode 3.1 Measurement Commands 3.2 Modulation Analysis Measurement 3.2.1 Views 3.2.1.1 Normal 3.2.1.2 Demod Traces 3.2.1.3 Demod Error 3.2.1.4 Decode 3.2.1.5 Result Summary 3.2.2 Windows 3.2.2.1 Data Pre Demod Raw Main Time...
Page 6 Table Of Contents 3.2.3 Amplitude 3.2.3.1 Y Scale Auto Scale Ref Value Scale/Div Ref Position 3.2.3.2 Attenuation Full Range Atten Mech Atten Elec Atten Adjust Atten for Min Clipping Adjust Atten Pre-Adjust for Min Clipping Mech Atten Step 3.2.3.3 Range (Baseband Input models) Range Auto/Man I Range Q Range...
Page 7 Table Of Contents Restore Layout to Default Save Layout as New View Re-Save User View Rename User View Delete User View Delete All User Views View Editor Remote Commands View Listing Query User View Listing Query 3.2.5.3 Annotation Graticule Screen Annotation Trace Annotation Control Annotation Meas Bar...
Page 8 Table Of Contents 3.2.7.5 Marker Function Marker X Band Function Band Span Band Left Band Right 3.2.7.6 Marker To Marker X Mkr -> CF 3.2.8 Meas Setup 3.2.8.1 Settings Avg|Hold Number Averaging On/Off Averaging Mode Auto Couple Meas Preset 3.2.8.2 Meas Standard Radio Standard Preset to Std 3.2.8.3 Meas Time...
Page 9 Table Of Contents Clock Adjust IQ Normalize Low SNR Enhancement Tx Frequency Offset FSK Deviation Ref 3.2.8.5 Advanced IF Gain LO Dither PhNoise Opt 3.2.8.6 Decode Decode Total Packet Num Data Rate 3.2.8.7 Limits Limit Test Tx Power RMS EVM RMS Offset EVM Frequency Error Clock Error...
Page 10 Table Of Contents 3.3.1 Views 3.3.1.1 Quad 3.3.1.2 RF Spectrum 3.3.1.3 Demod Waveform 3.3.1.4 AF Spectrum 3.3.1.5 Transient Analysis 3.3.1.6 Frequency Drift 3.3.1.7 Demod Bits 3.3.1.8 Decode Summary 3.3.2 Windows 3.3.2.1 RF Spectrum 3.3.2.2 Demod Waveform 3.3.2.3 AF Spectrum 3.3.2.4 RF Envelope 3.3.2.5 Raw Demod Waveform 3.3.2.6 Frequency Drift vs Symbols 3.3.2.7 Metrics...
Page 11 Table Of Contents Range Adjust Range for Min Clipping Pre-Adjust for Min Clipping Peak-to-Average Ratio Mixer Lvl Offset 3.3.3.4 Signal Path Presel Center Preselector Adjust Internal Preamp µW Path Control Software Preselection SW Preselection Type SW Preselection BW High Freq Prefilter 3.3.4 BW 3.3.4.1 Settings RF Res BW...
Page 12 Table Of Contents Display Enable (Remote Command Only) 3.3.6 Freq 3.3.6.1 Settings Center Frequency Span CF Step AF Start Freq AF Stop Freq 3.3.7 Marker 3.3.7.1 Select Marker 3.3.7.2 Settings Marker Frequency|Time Marker Amplitude Marker Mode Delta Marker (Reset Delta) Marker Table Marker Settings Diagram All Markers Off...
Page 13 Table Of Contents 3.3.8.2 Meas Standard Radio Standard Preset to Std 3.3.8.3 Demod Spreading Factor Programmed Preamble Length Invert Polarity Implicit Header 3.3.8.4 Decode Decode Enable Decode from Header Coding Rate Payload CRC Enable Data Length (Byte) Low Data Rate Optimization 3.3.8.5 Time Meas Interval Demod Waveform Time...
Page 14 Table Of Contents Sample Rate Sample Points (Display Only) Sample Time (Display Only) 3.3.9.4 Recording Sample Rate (Display Only) Sample Points (Display Only) Sample Time (Display Only) 3.3.10 Trace 3.3.10.1 Trace Control Trace Display Reference Selection Store Reference Show Reference 3.4 HRP UWB Demodulation Measurement 3.4.1 Views 3.4.1.1 Normal...
Page 15 Table Of Contents Adjust Atten Pre-Adjust for Min Clipping Mech Atten Step 3.4.3.3 Range (Non-attenuator models) Range Adjust Range for Min Clipping Pre-Adjust for Min Clipping Peak-to-Average Ratio Mixer Lvl Offset 3.4.3.4 Signal Path Presel Center Preselector Adjust Internal Preamp µW Path Control Software Preselection SW Preselection Type...
Page 16 Table Of Contents Channel Center Frequency CF Step Couple CF and Channel 3.4.7 Marker 3.4.7.1 Select Marker 3.4.7.2 Settings Marker Frequency | Time Marker Mode Delta Marker (Reset Delta) Marker Settings Diagram All Markers Off Couple Markers 3.4.7.3 Peak Search Marker Frequency | Time Peak Search Next Peak...
Page 17 Table Of Contents SFD # SFD Length RSF Parameters MMRS Sequence MMRS Code Index Number of Zeros Gap MMRS Symbol Repetitions Number of RSFs STS/RIF Parameters Number of RIFs (RIF only) Additional Gap to RSF (RIF only) STS Packet Configuration Segment Length Number of Segments Extra Gap (x4 chips)
Page 18 Table Of Contents PHR NRMSE PSDU NRMSE 3.4.8.6 Advanced Phase Noise Optimization IF Gain Transmit Mask Stitching State Transmit Mask Stitching Period 3.4.9 Recall 3.4.9.1 Signal Configuration 3.4.10 Sweep 3.4.10.1 Sweep/Control Sweep/Measure Restart Pause/Resume Abort (Remote Command Only) X Scale Width Ref Value Ref Position...
Page 19 Table Of Contents Scale Range Ref Position Auto Scaling 3.5.3.2 Attenuation Full Range Atten Mech Atten Elec Atten Adjust Atten for Min Clipping Adjust Atten Pre-Adjust for Min Clipping Mech Atten Step 3.5.3.3 Range (Non-attenuator models) Range Adjust Range for Min Clipping Pre-Adjust for Min Clipping Peak-to-Average Ratio Mixer Lvl Offset...
Page 20 Table Of Contents User View Restore Layout to Default Save Layout as New View Re-Save User View Rename User View Delete User View Delete All User Views View Editor Remote Commands View Listing Query User View Listing Query 3.5.6 Frequency 3.5.6.1 Settings Center Frequency Span...
Page 21 Table Of Contents Meas Preset 3.5.8.2 Meas Method Meas Method RRC Filter Alpha RRC Filter BW 3.5.8.3 Meas Standard Radio Standard Preset to Std 3.5.8.4 Limits Power Limit PSD Limit Power Limit Fail (Remote Query Only) PSD Limit Fail (Remote Query only) 3.5.8.5 Advanced Phase Noise Optimization Noise Floor Extension...
Page 22 Table Of Contents Offset Reference 3.5.10.4 Detector Detector Detector Select Auto/Man 3.5.10.5 Trace Function From Trace To Trace Copy Exchange Preset All Traces Clear All Traces 3.5.10.6 Advanced Measure Trace 3.6 Power Stat CCDF Measurement 3.6.1 Views 3.6.1.1 Normal 3.6.2 Windows 3.6.2.1 Graph 3.6.2.2 Metrics 3.6.3 Amplitude...
Page 23 Table Of Contents 3.6.3.5 Signal Path Presel Center Preselector Adjust Internal Preamp µW Path Control Software Preselection SW Preselection Type SW Preselection BW High Freq Prefilter 3.6.4 BW 3.6.4.1 Settings Info BW 3.6.5 Display 3.6.5.1 View View User View Restore Layout to Default Save Layout as New View Re-Save User View Rename User View...
Page 24 Table Of Contents All Markers Off Couple Markers 3.6.7.3 Properties Marker X-Axis Value Relative To Marker Trace Marker Settings Diagram 3.6.8 Meas Setup 3.6.8.1 Settings Counts Meas Cycles Meas Interval Meas Setup Summary Table Auto Couple Meas Preset 3.6.8.2 Meas Standard Radio Standard Preset to Std 3.6.8.3 Advanced...
Page 25 Table Of Contents 3.7.3 Measurement Results for n = 3 3.7.4 Measurement Results for n = 7 3.7.5 Measurement Results for n = 8 3.7.6 Views 3.7.6.1 Normal 3.7.6.2 Carrier Info 3.7.7 Windows 3.7.7.1 Graph 3.7.7.2 Metrics 3.7.7.3 Gate 3.7.7.4 Marker Table 3.7.8 Amplitude 3.7.8.1 Y Scale Ref Value...
Page 26 Table Of Contents High Freq Prefilter 3.7.9 BW 3.7.9.1 Settings Res BW Video BW RBW Filter Type RBW Filter BW 3.7.10 Display 3.7.10.1 Meas Display Bar Graph On/Off 3.7.10.2 Annotation Graticule Screen Annotation Trace Annotation Control Annotation Meas Bar Display Enable (Remote Command Only) 3.7.10.3 View View User View...
Page 27 Table Of Contents 3.7.12.3 Peak Search Marker Frequency Peak Search Next Peak Next Pk Right Next Pk Left Minimum Peak Pk-Pk Search Marker Delta 3.7.12.4 Properties Marker Frequency Relative To Marker Trace Marker Settings Diagram 3.7.13 Meas Setup 3.7.13.1 Settings Avg | Hold Number Averaging On/Off Avg Mode...
Page 28 Table Of Contents Positive Offset Limit (Remote Command only) Negative Offset Limit(Remote Command only) Rel Limit (PSD) Fail Mask Offset Frequency Define Offset Freq Integ BW Offset Side Method Filter Alpha Offset Freq Res BW Video BW Filter Type Filter BW Power Ref Type Limit Test Offset Freq...
Page 29 Table Of Contents Video BW Filter Type Filter BW Limits Limit Test Offset Freq Abs Limit Rel Limit (Car) Positive Offset Limit (Remote Command only) Negative Offset Limit(Remote Command only) Rel Limit (PSD) Fail Mask Offset Frequency Define Offset Freq Integ BW Offset Side Method...
Page 30 Table Of Contents Global Center Freq Global EMC Std Restore Defaults 3.7.13.6 Offset RRC Weighting (Backwards Compatibility SCPI) 3.7.13.7 Offset Filter Alpha (Backward Compatibility SCPI) 3.7.13.8 Method for Carrier (Backward Compatibility SCPI) 3.7.14 Sweep 3.7.14.1 Sweep/Control Sweep Time Minimum Acquisition Time Sweep/Measure Restart Pause/Resume...
Page 31 Table Of Contents Measure Trace 1009 3.8 SEM Measurement 1010 3.8.1 Results for n = 1 1012 3.8.2 Results for n = 2-4 1013 3.8.3 Results for n = 5 1013 3.8.4 Results for n = 6 1014 3.8.5 Results for n = 7-11 1015 3.8.6 Results for n = 12 1017...
Page 32 Table Of Contents Elec Atten 1046 Adjust Atten for Min Clipping 1050 Adjust Atten 1050 Pre-Adjust for Min Clipping 1051 Mech Atten Step 1055 3.8.13.3 Range (Non-attenuator models) 1056 Range 1056 Adjust Range for Min Clipping 1057 Pre-Adjust for Min Clipping 1057 Peak-to-Average Ratio 1058...
Page 33 Table Of Contents Marker Frequency 1091 Marker Mode 1092 All Markers Off 1093 Couple Markers 1093 3.8.17.3 Properties 1093 Marker Frequency 1093 Marker Trace 1094 3.8.18 Meas Setup 1094 3.8.18.1 Settings 1094 Avg/Hold Num 1094 Averaging On/Off 1095 Meas Method 1095 RRC Filter Alpha 1096...
Page 34 Table Of Contents Fail Mask2 1137 Offset Freq Define 1138 Offset Detector 1141 Cumulate Mask 1141 Cumulate Mask Stop Frequency 1142 Start Freq 1142 Stop Freq 1143 Res BW 1144 Meas BW 1145 Video BW 1146 Offset Freq Define 1147 Offset Detector 1147 Cumulate Mask...
Page 35 Table Of Contents 3.8.18.3 Reference 1174 Measurement Type 1174 Reference Power 1174 Total Power Ref 1175 PSD Ref 1175 Spectrum Pk Ref 1176 Offset/Limits Config Table 1177 3.8.18.4 Meas Standard 1177 Radio Standard 1177 Preset to Std 1178 3.8.18.5 Advanced 1180 Noise Floor Extension 1180...
Page 36 Table Of Contents 3.8.20.4 Trace Function 1212 From Trace 1213 To Trace 1213 Copy 1213 Exchange 1214 Preset All Traces 1214 Clear All Traces 1214 3.8.20.5 Advanced 1215 Measure Trace 1215 3.9 Occupied BW Measurement 1216 3.9.1 Views 1218 3.9.1.1 OBW Results 1219 3.9.1.2 OBW Boundaries 1220...
Page 37 Table Of Contents Presel Center 1246 Preselector Adjust 1248 Internal Preamp 1249 1250 µW Path Control 1252 Software Preselection 1261 SW Preselection Type 1262 SW Preselection BW 1263 High Freq Prefilter 1264 3.9.4 BW 1265 3.9.4.1 Settings 1265 Res BW 1266 Video BW 1267...
Page 38 Table Of Contents 3.9.7.1 Select Marker 1286 3.9.7.2 Settings 1287 Marker Frequency 1287 Marker Mode 1288 Delta Marker (Reset Delta) 1289 Marker Settings Diagram 1289 All Markers Off 1289 3.9.7.3 Peak Search 1290 Marker Frequency 1290 Peak Search 1290 Marker Delta 1291 3.9.7.4 Properties 1291...
Page 39 Table Of Contents Global EMC Std 1314 Restore Defaults 1314 3.9.9 Sweep 1315 3.9.9.1 Sweep/Control 1315 Sweep Time 1315 Minimum Acquisition Time 1317 Sweep/Measure 1318 Restart 1320 Pause/Resume 1322 Abort (Remote Command Only) 1323 Sweep Time Annotation (Remote Query Only) 1323 3.9.9.2 Sweep Config 1324...
Page 40 Table Of Contents 3.10.1.2 All Ranges 1357 3.10.2 Windows 1358 3.10.2.1 Graph 1358 3.10.2.2 Table 1359 3.10.2.3 All Range Table 1360 3.10.2.4 Gate 1361 3.10.2.5 Marker Table 1361 3.10.3 Amplitude 1361 3.10.3.1 Y Scale 1361 Ref Value 1362 Scale/Div 1362 Scale Range 1363 Ref Position...
Page 41 Table Of Contents 3.10.5.2 Annotation 1403 Graticule 1403 Screen Annotation 1403 Trace Annotation 1404 Control Annotation 1404 Meas Bar 1405 Display Enable (Remote Command Only) 1405 3.10.5.3 View 1406 Views 1406 Graph + Metrics 1407 All Ranges 1407 User View 1407 Restore Layout to Default 1408...
Page 42 Table Of Contents Relative To 1425 Marker Trace 1425 Marker Settings Diagram 1426 3.10.8 Meas Setup 1426 3.10.8.1 Settings 1426 Avg/Hold Num 1426 Averaging On/Off 1427 Average Mode 1427 Average Type 1428 Meas Type 1428 Spur 1430 Range 1430 Spur Report Mode 1431 Range Settings 1431...
Page 43 Table Of Contents Detector/Sweep 1455 Frequency Range 1455 Enabled 1456 Start Freq 1456 Stop Freq 1456 Center Frequency 1456 Span 1456 Sweep Time 1456 Points 1457 Detector 1 1458 Detector 2 1459 Limits 1460 Frequency Range 1460 Enabled 1460 Start Freq 1460 Stop Freq 1460...
Page 44 Table Of Contents 3.10.10.1 Select Trace 1489 3.10.10.2 Trace Control 1489 Trace Type 1490 Clear and Write | Restart Averaging | Restart Max/Min Hold 1495 View/Blank 1495 3.10.10.3 Math 1498 Math Function 1498 Operand 1 / Operand 2 1504 Offset 1505 Reference 1505...
Page 45 Table Of Contents Mech Atten Step 1533 3.11.3.3 Range (Baseband Input models) 1534 Range Auto/Man 1534 I Range 1535 Q Range 1537 Q Same as I 1538 3.11.3.4 Range (Non-attenuator models) 1538 Range 1539 Adjust Range for Min Clipping 1539 Pre-Adjust for Min Clipping 1539 Peak-to-Average Ratio...
Page 46 Table Of Contents Trace Annotation 1571 Control Annotation 1572 Meas Bar 1572 Display Enable (Remote Command Only) 1572 3.11.6 Frequency 1574 3.11.6.1 Settings 1574 Center Frequency 1574 3.11.7 Marker 1580 3.11.7.1 Select Marker 1580 3.11.7.2 Settings 1581 Marker Time 1581 Marker Mode 1583 Delta Marker (Reset Delta)
Page 47 Table Of Contents Meas Time 1595 Sample Rate 1596 Meas Setup Summary Table 1597 Spur Avoidance 1597 Auto Couple 1600 Meas Preset 1602 3.11.8.2 Meas Standard 1602 Radio Standard 1602 Preset to Std 1604 3.11.8.3 Advanced 1605 Phase Noise Optimization 1605 ADC Dither 1611...
Page 48 Table Of Contents 3.12.3 Amplitude 1633 3.12.3.1 Y Scale 1633 Ref Value 1633 Scale/Div 1633 Scale Range 1634 Ref Position 1635 Auto Scaling 1635 3.12.3.2 Attenuation 1636 Full Range Atten 1638 Mech Atten 1639 Elec Atten 1641 Adjust Atten for Min Clipping 1645 Adjust Atten 1645...
Page 49 Table Of Contents Re-Save User View 1681 Rename User View 1681 Delete User View 1682 Delete All User Views 1682 View Editor Remote Commands 1682 View Listing Query 1682 User View Listing Query 1683 3.12.5.3 Annotation 1683 Graticule 1683 Screen Annotation 1684 Trace Annotation 1684...
Page 50 Table Of Contents 3.12.8 Meas Setup 1707 3.12.8.1 Settings 1707 Avg|Hold Num 1707 Averaging On/Off 1707 Average Mode 1708 Spur Avoidance 1708 Meas Setup Summary Table 1709 Auto Couple 1709 Meas Preset 1711 3.12.8.2 Meas Standard 1711 Radio Standard 1711 Preset to Std 1712 3.12.8.3 Advanced...
Page 51 Table Of Contents 4 System 1742 4.1 System 1743 4.1.1 Show System 1743 4.1.1.1 Show System contents (Remote Query Only) 1744 4.1.1.2 Computer System description (Remote Query Only) 1744 4.1.2 Show Hardware 1744 4.1.3 Show LXI 1744 4.1.4 Show Support Subscriptions 1745 4.1.5 Show Support ID 1745...
Page 52 Table Of Contents SYSTem:PERSona:MODel 1759 SYSTem:PERSona:MODel:DEFault 1760 4.2.5 LXI 1760 4.2.5.1 LAN Reset 1760 4.2.5.2 Device Identification (Remote Command Only) 1760 4.2.6 Restore I/O Config Defaults 1761 4.2.7 Query USB Connection (Remote Query Only) 1761 4.2.8 USB Connection Status (Remote Query Only) 1762 4.2.9 USB Packet Count (Remote Query Only) 1762...
Page 53 Table Of Contents 4.3.7.6 Backlight Intensity 1775 4.3.7.7 Hints 1775 4.3.7.8 Numeric Entry Auto Open 1775 4.3.7.9 Touch On/Off 1776 4.3.7.10 Control Size 1776 4.3.7.11 Quick Save Mode 1776 4.3.7.12 Screen Tabs Left/Right 1777 4.3.7.13 Hide Screen Tabs in Full Screen 1778 4.3.7.14 2-Screen Orientation 1779...
Page 54 Table Of Contents 4.5.5 Alignments 1798 4.5.6 Misc 1798 4.5.7 All 1799 4.6 Alignments 1801 4.6.1 Auto Align 1801 4.6.1.1 Auto Align 1801 4.6.1.2 All but RF 1804 4.6.1.3 Alert 1804 4.6.2 Align Now 1806 4.6.2.1 Align Now All 1808 4.6.2.2 Align Now All but RF 1810 4.6.2.3 Align Now RF...
Page 55 Table Of Contents 4.6.2.23 Align High Band 1826 4.6.3 Path Delay Calibration 1827 4.6.3.1 Source Path Delay Calibration 1827 4.6.3.2 Path Delay Correction On/Off(Remote Command only) 1829 4.6.4 Show Alignment Statistics 1829 4.6.5 Timebase DAC 1841 4.6.5.1 Timebase DAC 1841 4.6.5.2 User Value 1842 4.6.6 Advanced...
Page 56 Table Of Contents 4.7.3 Software Support Expiration Date 1877 4.7.4 Network Licenses 1877 4.7.4.1 Application Licenses 1878 4.7.4.2 Instrument Software Options 1878 4.7.4.3 License Checked Out Query (Remote Query Only) 1878 4.7.4.4 List Licenses Checked Out (Remote Query Only) 1879 4.7.4.5 Borrowed Network Licenses 1879 4.7.4.6 Borrow a License...
Page 57 Table Of Contents 4.11.3 Lock Workstation (Remote Command Only) 1892 4.11.4 List SCPI Commands (Remote Query Only) 1894 4.11.5 Front Panel activity history (Remote Query only) 1894 4.11.6 SCPI activity history (Remote Query only) 1895 4.11.7 Instrument start time (Remote Query only) 1895 4.11.8 SCPI Version Query (Remote Query Only) 1896...
Page 58 Table Of Contents 6.1.4 RF Power 1924 6.1.5 T/R Port High Power Attenuator 1924 6.1.6 Amplitude Setup 1924 6.1.6.1 RF Power 1924 6.1.6.2 Set Reference Power 1928 6.1.6.3 Power Ref 1929 6.1.6.4 Power Unit 1929 6.1.6.5 Amptd Offset 1930 6.1.6.6 Amplitude Increment 1931 6.1.7 Frequency 1931...
Page 59 Table Of Contents Step Configuration of Frequency/Channel Number parameter list (Remote Command Only) 1952 Step Configuration of Power parameter list (Remote Command Only) 1952 Step Configuration of Waveform parameter list (Remote Command Only) 1953 Step Configuration of Step Duration parameter list (Remote Command Only) 1954 Step Configuration of Duration Time or Play Count parameter list (Remote Command Only)
Page 60 Table Of Contents 6.1.11.12 PM Rate Increment 1978 6.1.11.13 ARB Setup 1978 Basic Control 1978 ARB State 1978 Sample Rate 1979 Run-Time Scaling 1983 Baseband Freq Offs 1983 Baseband Power 1984 Mkr 1-4 Polarity 1984 Pulse/RF Blank 1984 ALC Hold 1985 Trigger Type 1986...
Page 61 Table Of Contents Insert Waveform 2004 Segments in ARB Memory 2004 Delete Segment From ARB Mem 2005 Delete All From ARB Memory 2005 Delete Segment 2005 Save Sequence 2005 Build New Sequence (Remote Command Only) 2005 Edit Selected Sequence 2008 Segment 2008 Waveform...
Page 62 Table Of Contents Add Secondary Module 2023 Delete Secondary Module 2023 Sync Runtime Settings (Remote Command Only) 2024 6.1.13.4 Sync Start 2024 6.1.13.5 Sync Stop 2024 6.1.13.6 Sync Connected (Remote Query Only) 2025 6.1.14 Source Preset 2025 6.2 Input 2026 6.2.1 Select Input 2026 6.2.2 RF Input Port...
Page 63 Table Of Contents 6.2.19 I/Q Path 2071 6.2.20 Reference Z 2073 6.2.21 I/Q Setup 2073 6.2.21.1 I Setup 2073 Differential 2073 Input Z 2074 Skew 2075 Combined Differential/Input Z (Remote Command Only) 2076 6.2.21.2 I Probe 2076 Attenuation 2077 Offset 2078 Coupling 2078...
Page 64 Table Of Contents 6.2.23 Audio Input Channel 2092 6.2.24 Audio Calibrator 2092 6.2.25 Audio Coupling 2092 6.2.26 Audio Input Ground 2093 6.2.27 Audio In Impedance 2093 6.2.28 Input/Output Preset 2093 6.3 External Gain 2095 6.3.1 External Preamp 2095 6.3.2 External Gain - MS 2097 6.3.3 External Gain - BTS 2098...
Page 65 Table Of Contents 6.5.6.2 Freq Interpolation 2122 6.5.6.3 Transducer Unit 2124 6.5.6.4 Description 2125 6.5.6.5 Comment 2125 6.5.7 Complex Corrections 2126 6.5.7.1 Go To Row (Select Correction) 2127 6.5.7.2 Delete Row 2127 6.5.7.3 Delete All 2127 6.5.7.4 Correction On 2128 6.5.7.5 Correction Port 2128 6.5.7.6 Direction...
Page 66 Table Of Contents 6.5.14 Merge Correction Data (Remote Command Only) 2140 6.5.15 Set (Replace) Data (Remote Command Only) 2141 6.5.16 Correction Group Range Data (Remote Command Only) 2141 6.5.17 Delete Correction Group Range (Remote Command Only) 2142 6.6 Freq Ref Input 2143 6.6.1 Freq Ref Input 2143...
Page 67 Table Of Contents 6.8.5 Src Trig Out Polarity 2173 6.8.6 Select Src PXI Line 2173 6.8.7 Analyzer PXI Trig Out 2174 6.8.8 Analyzer Trig Out Polarity 2175 6.8.9 Select Analyzer PXI Line 2175 6.8.10 Source Internal Trig Out 2175 6.8.11 Source Internal Trig Out Polarity 2176 6.9 Calibration 2178...
Page 68 Table Of Contents 6.9.1.24 Last Cal 2190 6.9.1.25 Cal Applied 2190 6.9.1.26 Cal Type 2191 6.9.1.27 Start Freq 2191 6.9.1.28 Stop Freq 2192 6.9.1.29 Freq Step 2193 6.9.1.30 Freq Points 2193 6.9.1.31 Mech Atten Type 2194 6.9.1.32 Mech Atten Start 2194 6.9.1.33 Mech Atten Stop 2195...
Page 69 Table Of Contents 6.9.3 Apply Cal Group 2213 6.9.4 All Apply Cal Group Off 2213 6.9.5 Connection 2214 6.10 Calibrator Control 2215 6.10.1 Select Cal Source 2215 6.10.2 Cal Output 2215 6.10.3 Cal Frequency 2216 6.10.4 Cal Signal Type 2216 6.10.5 Cal Comb Spacing 2216 6.10.6 Calibrator Reference...
Page 70 Table Of Contents 7.2.16 Correction 2235 7.2.17 Select Correction 2236 7.2.18 Complex Correction 2236 7.2.19 Select Complex Correction 2237 7.2.20 Recall VDI CCD Correction 2237 7.2.21 Mask 2238 7.2.22 Sequence 2238 7.2.23 Waveform 2238 7.2.24 Load Segment to ARB Memory 2240 7.2.25 Delete Segment From ARB Mem 2241...
Page 71 Table Of Contents 7.3.2 State 2258 7.3.3 Register 1 thru Register 16 2259 7.3.4 Edit Register Names 2259 7.3.5 Trace+State 2260 7.3.6 Save From Trace 2262 7.3.7 Register 1 thru Register 16 2263 7.3.8 Edit Register Names 2263 7.3.9 Screen Config + State 2264 7.3.10 Measurement Data 2264...
Page 72 Table Of Contents 7.3.35 Title 2289 7.3.36 Client 2289 7.3.37 Operator 2289 7.3.38 Product Description 2289 7.3.39 Comment 2290 7.3.40 Meas Setup On/Off 2290 7.3.41 Disturbance List On/Off 2290 7.3.42 Trace (All Traces) On/Off 2290 7.3.43 Channel On/Off 2290 7.3.44 Limit 2290 7.3.45 Select Limit 2294...
Page 73 Table Of Contents 7.3.68 Mass Storage Determine Removable Media Label (Remote Command Only) 2309 7.3.69 Mass Storage Determine Removable Media Write-protect status (Remote Query Only) 2309 7.3.70 Mass Storage Determine Removable Media size (Remote Query Only) 2310 7.3.71 :SYSTem:SET (Remote Command Only) 2310 7.4 Print 2311...
Page 74 Table Of Contents 8.1.2 Trigger Level 2341 8.1.3 Trigger Delay 2343 8.1.4 Trigger Slope 2347 8.1.5 Trigger Level Absolute/Relative 2348 8.1.6 Absolute Trigger Level 2349 8.1.7 Relative Trigger Level 2349 8.1.8 Period 2351 8.1.9 Offset 2352 8.1.10 Reset Offset Display 2353 8.1.11 Offset Adjust (Remote Command Only) 2353...
Page 75 Table Of Contents 8.3.9 Gate View Start Time 2374 8.3.10 Gate Delay Compensation 2375 8.3.11 Min Fast Position Query (Remote Query Only) 2376 8.3.12 Gate Preset (Remote Command Only) 2377 8.3.13 Gate Level (Remote Command Only) 2377 8.3.14 Gate Polarity (Remote Command Only) 2377 8.4 Enables the hardware accelerated stepped FFT gating feature (Display only)
Page 76 Table Of Contents 9.2.3 *ESE - Standard Event Status Enable 2423 9.2.4 *ESR? - Standard Event Status Register Query 2424 9.2.5 *IDN? - Identification Query 2424 9.2.6 *OPC? - Operation Complete 2425 9.2.7 *OPT? - Query Instrument Options 2426 9.2.8 *RCL - Recall Instrument State 2426 9.2.9 *RST - Reset 2426...
Page 77 Table Of Contents 9.4.1 Status Register System Diagram 2450 9.4.2 Status Register Hierarchy 2452 9.4.3 Status Register SCPI Commands 2454 9.4.4 How to Use Status Registers 2455 9.4.4.1 Polling Method 2455 Monitoring Options 2456 9.4.4.2 Service Request (SRQ) Method 2456 Using the Service Request (SRQ) Method 2456 9.4.5 Status Register Bit Parameters...
Page 78 Table Of Contents Questionable Temperature Event Query 2480 Questionable Temperature Negative Transition 2480 Questionable Temperature Positive Transition 2480 9.4.6.8 Questionable Frequency Register 2481 Questionable Frequency Condition 2482 Questionable Frequency Enable 2482 Questionable Frequency Event Query 2483 Questionable Frequency Negative Transition 2483 Questionable Frequency Positive Transition 2484...
Page 79 Table Of Contents 9.4.6.15 Questionable Integrity Output Register 2504 Questionable Integrity Output Condition 2505 Questionable Integrity Output Enable 2505 Questionable Integrity Output Event Query 2506 Questionable Integrity Output Negative Transition 2506 Questionable Integrity Output Positive Transition 2507 9.4.6.16 Questionable Integrity Uncalibrated Register 2507 Questionable Integrity Uncalibrated Condition 2508...
Page 80 Table Of Contents 10.2.21 Trigger Source 2518 10.2.22 Trigger Timeout 2519 10.2.23 Signal Input 2519 10.2.24 Use Preselector 2519 10.2.25 Channel Bandwidth Array 2519 10.2.26 Channel Filter Type Array 2520 10.2.27 Channel Filter Alpha Array 2520 10.2.28 Channel Measurement Function Array 2520 10.2.29 Channel Offset Frequency Array 2521...
Page 81 X-Series Signal Analyzers Short Range Comms & IoT Mode User's & Programmer's Reference 1 Documentation Roadmap This section describes the Keysight products covered by this document, and provides links to related documentation. – "Products Covered by this Document" on page 82 –...
Page 82 1 Documentation Roadmap 1.1 Products Covered by this Document 1.1 Products Covered by this Document For the full list of instrument models covered by this documentation, see the title page: "Short Range Comms & IoT Mode User's & Programmer's Reference" on page Short Range Comms &...
Page 83 1.2 Additional Documentation If your instrument or computer has an internet connection, then you can access the latest editions of all relevant X-Series documentation via the links below. This document is available in 3 formats: – Embedded Help, in the instrument –...
Page 84 Analog Demod Measurement Application Measurement Guide – Phase Noise Measurement Application Measurement Guide – EMI Measurement Application Measurement Guide – M9484C VXG Signal Generator and X-Series Signal Analyzers Measurement Guide Service Guides – N9010B EXA Service Guide – N9020B MXA Service Guide –...
Page 85 X-Series Signal Analyzers Short Range Comms & IoT Mode User's & Programmer's Reference 2 User Interface Here are the basic elements of the Multitouch User Interface. For more information, tap a topic. Included in this section are also topics for several front panel keys not described in other topics.
Page 86 2.1 Screen Tabs 2.1 Screen Tabs In the X-Series Multitouch User Interface (or Multitouch UI), you can run many different Measurement Applications, or “Modes”. Examples are Spectrum Analyzer Mode, LTE-A FDD Mode, IQ Analyzer Mode, and Real Time Spectrum Analyzer Mode.
Page 87 2 User Interface 2.1 Screen Tabs The following topics provide more information: – "Mode/Meas/View Dialog" on page 87 – "Add Screen" on page 104 – "Multiscreen" on page 174 2.1.1 Mode/Meas/View Dialog The Mode/Meas/View dialog opens when you press the selected (blue) Screen tab (see "Screen Tabs"...
Page 88 2 User Interface 2.1 Screen Tabs 2.1.1.1 Mode The first column in the Mode/Meas/View dialog allows you to select the desired Mode from those currently licensed in your instrument. Modes, also known as “measurement applications”, are collections of measurement capabilities packaged together to provide you with an instrument personality specific to your measurement needs.
Page 89 2 User Interface 2.1 Screen Tabs :INSTrument:SELect CONFigure commands separately. See "Mode and Measurement Select" on page :INSTrument[:SELect] <mode_id> Remote Command where <mode_id> is one of the values listed in "Index to Modes" on page 90 below :INSTrument[:SELect]? :INST SA Example :INST:CAT? Notes...
Page 90 2 User Interface 2.1 Screen Tabs :CONF commands Index to Modes The Mode Number in the table below is the parameter for use with the :INSTrument:NSELect command. The Mode Parameter is the parameter for use with the :INSTrument[:SELect] command. Your actual choices will depend upon which applications are installed in your instrument.
Page 91 Each application (Mode) that runs in an X-Series instrument consumes virtual memory. The various applications consume varying amounts of virtual memory, and as more applications run, the memory consumption increases. Keysight characterizes each Mode and assigns a memory usage quantity based on a conservative estimate.
Page 92 Notes "BASIC","GSM","EDGEGSM","CDMA","SERVICE" X-Series uses the ESA/PSA compatible query of a string contain comma separated values: "SA,PNOISE,NFIG,BASIC" Current Application Model (Remote Command Only) Returns a string that is the Model Number of the currently selected application (mode).
Page 93 2 User Interface 2.1 Screen Tabs Current Application Options (Remote Command Only) Returns a string that is the Options list of the currently selected application (Mode). This information is also displayed in the Show System screen :SYSTem:APPLication[:CURRent]:OPTion? Remote Command :SYST:APPL:OPT? Example Notes Query returns a quoted string that is the Option list of the currently selected application (Mode).
Page 94 2 User Interface 2.1 Screen Tabs Application Catalog Revision (Remote Command Only) Returns the Revision of the provided Model Number. :SYSTem:APPLication:CATalog:REVision? <model> Remote Command :SYST:APPL:CAT:REV? ‘N9060A’ Example Notes Returned value is a quoted string of revision for the provided Model Number. The revision will be a null- string ("") if the provided Model Number is not installed, licensed, and loaded.
Page 95 2 User Interface 2.1 Screen Tabs GSM Mode compatibility command (Remote Command only) Provided for backwards compatibility. When this command is received, the analyzer aliases it to the following: :INST:SEL EDGEGSM :INSTrument[:SELect] GSM Remote Command :INST GSM Example SA compatibility command for EMC (Remote Command only) Provided for ESU compatibility.
Page 96 2 User Interface 2.1 Screen Tabs This results in the analyzer being placed in the EMI Receiver Mode, running the APD measurement, in order to emulate the ESU APD Mode. :INSTrument[:SELect] APDistribution Remote Command :INST APD Example IF Mode compatibility command for EMC (Remote Command only) Provided for ESU compatibility.
Page 97 2 User Interface 2.1 Screen Tabs Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 98 2 User Interface 2.1 Screen Tabs 2.1.1.5 Sequencer Allows multiple Screens to update sequentially while in "Multiscreen" on page 174 display mode. Each Screen updates in sequence, and when all have updated, the sequence will start again. To start the Sequencer, you must have more than one Screen defined, and you must have Multiscreen selected (see "Screen Tabs"...
Page 99 2 User Interface 2.1 Screen Tabs In the Sequencer block in the upper left hand corner, tap the Sequencing switch to turn it On: Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 100 2 User Interface 2.1 Screen Tabs The instrument will immediately exit the Mode/Meas/View Dialog and begin making measurements in each of the screens, one after the other. When a measurement is being made in a particular Screen, that Screen’s tab will be blue. Measurement being made in Screen 1: Measurement being made in Screen 2: Short Range Comms &...
Page 101 2 User Interface 2.1 Screen Tabs Touching any key or control on the display will cause the Sequencer to stop, so that you can make desired changes. When this happens, the message “Sequencer stopped” is displayed. When the Sequencer is running, the screens update in the order in which they were created.
Page 102 2 User Interface 2.1 Screen Tabs To reset the name, delete the screen name entirely. Each Screen Name must be unique; you cannot give the same name to more than one screen. :INSTrument:SCReen:REName <alphanumeric> Remote Command :INST:SCR:REN “Baseband” Example Notes The currently active screen is renamed.
Page 103 2 User Interface 2.1 Screen Tabs “This function will delete all defined screens and their settings, except for the current screen. This action cannot be undone. Do you want to proceed?” Pressing OK or Enter deletes the screen, pressing Cancel or ESC does not. :INSTrument:SCReen:DELete:ALL Remote Command...
Page 104 Example :INST:NSEL 101 2.1.2 Add Screen On X-Series analyzers you can configure up to 16 different Screens at one time. Each Screen contains one Mode, each Mode contains one Measurement, and each Measurement contains a number of Windows. You can add screens by pressing the “+” icon in the "Screen Tabs"...
Page 105 2 User Interface 2.1 Screen Tabs If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict; Screen SCPI cannot be used when Display is disabled” appears Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 106 2 User Interface 2.2 Meas Bar 2.2 Meas Bar The Meas Bar is used to display annotation for the current measurement. There are three primary uses for the Meas Bar: 1. To show annotation for the most important parameters in the measurement so you can see them at a glance 2.
Page 107 2 User Interface 2.2 Meas Bar Settings that are colored amber are those that you need to be particularly aware of; for example, if Alignments are off, this is shown in amber, so you will know that you may not be meeting spec. Similarly, if DC coupling is on, this is shown amber, to alert you to be careful what voltage you put on the input.
Page 108 2 User Interface 2.2 Meas Bar LXI indicator This indicator displays in green when LAN is connected, in white when LAN is not connected, and in red when LAN is connected but has a connection problem. PASS/FAIL indicator This annunciator displays when Limits are turned on. It is green if all Limits are passing, and a red FAIL if any limit is not passing.
Page 109 2 User Interface 2.2 Meas Bar In the example above, trace 1 is active, visible, and in Average using the Sample detector, the other traces are inactive, blanked and in Clear/Write using the Normal detector. Tapping this panel drops down controls for the Traces. Short Range Comms &...
Page 110 2 User Interface 2.3 Measurement Display 2.3 Measurement Display The Measurement Display contains one or more data windows displaying the result of the current measurement. These may be graphical or textual windows. Each window in the Measurement display contains a "Window Title"...
Page 111 2 User Interface 2.3 Measurement Display Measurements that support User Views (see "View Editor" on page 153) also display the Window Number in the Window Title, to enable window addressing from SCPI. The number is the number that will be used in the SCPI command to address that window, for example, in the WCDMA Mod Accuracy measurement, Code Domain Power is assigned window number 6, so you address it with the following SCPI command:...
Page 112 2 User Interface 2.3 Measurement Display Note also that the Window Data dropdown can be a cascaded list, if the number of available results requires categorization to hold them all: Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 113 2 User Interface 2.3 Measurement Display Note also that the Window Data dropdown sometimes includes controls for further configuring the window, for example, in LTE choosing the desired Component Carrier and Data format. Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 114 2 User Interface 2.3 Measurement Display Touching a window’s title dropdown also selects the window. 2.3.2 Measurement Data The Measurement Data region shows graphical or textual data for the Data selected in the Window Title Data control. Below you can see examples of both graphical and textual windows in a four-window display.
Page 115 2 User Interface 2.3 Measurement Display Swipe There are several swipe actions, as listed below. One of the most important actions is swiping a spectrum window to the left or right, or up or down, to adjust the frequency and level of the spectrum, as shown below. Swipe actions are summarized in the table below.
Page 116 2 User Interface 2.3 Measurement Display Object Action Toggle control Toggle in that direction Pinch You can also pinch in or out either horizontally or vertically to zoom in the x-axis or y-axis dimension. For example, a pinch horizontally lets you adjust the Span of the Spectrum window.
Page 117 2 User Interface 2.3 Measurement Display Right Click on Lets you select Help the Background Right Click on a Lets you add or remove that control from the User Menu or get Help on that Menu Panel control control Tapping an object causes the actions defined in the table below: Object Action Marker...
Page 118 2 User Interface 2.3 Measurement Display Touching anywhere off the hotspot panel or pressing any hardkey except Save or Quick Save closes the hotspot panel. Annotation which is not currently able to be adjusted is not grayed out on the display, but the control in the hotspot that drops down or pops up is grayed out.
Page 119 2 User Interface 2.4 Menu Panel 2.4 Menu Panel The menu panel is the main focus of the X-Series Multitouch user interface. The controls include active functions, dropdowns, action buttons, radio buttons and toggles. Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 120 2 User Interface 2.4 Menu Panel Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 121 2 User Interface 2.4 Menu Panel The menu panel normally appears on the right side of the display and consists of a rectangular panel with multiple “sub-panels” lying on top of each other, each sub- panel being accessed by a tab on the right. You press a front panel key (or “hardkey”) to access a particular menu.
Page 122 2 User Interface 2.4 Menu Panel Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 123 2 User Interface 2.4 Menu Panel If you move to a different menu panel or sub-panel and then come back to a previous panel, the previous panel is always reset to be scrolled all the way back to the top. Accessing Menus Without Using Front-Panel Keys You can access the menu panels without using the front panel keys, as you would need to do if you were operating the instrument using Remote Desktop.
Page 124 2 User Interface 2.4 Menu Panel for example 13.255 GHz, as in the example below: An active function is “active” if the numeric value is surrounded by a black background with a blue border, as below. In this state, it is ready to receive numeric input from the number pad on the front panel, the knob, or the step keys.
Page 125 2 User Interface 2.4 Menu Panel This causes the Numeric Entry Panel to pop up to receive the numbers you are typing: Type in as many digits as required, then touch one of the unit terminator buttons in the Numeric Entry Panel to complete the entry. In this case, 2 GHz was the desired entry, so you just touch the “GHz”...
Page 126 2 User Interface 2.4 Menu Panel The Numeric Entry Panel disappears and, in the example, the active function value becomes 2 GHz. Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 127 2 User Interface 2.4 Menu Panel It is important to note that you can always pop up the Numeric Entry Panel by touching an active function control while it is active; for example, if you were to touch it in the figure above, the Numeric Entry Panel would pop up right next to the control: Short Range Comms &...
Page 128 2 User Interface 2.4 Menu Panel Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 129 2 User Interface 2.4 Menu Panel You can display the Numeric Entry Panel by touching any active function control while it is active, but you don’t have to pop up the Numeric Entry Panel first, you can just start typing and it will pop up on its own, thus saving you a keystroke. You can also adjust a value without displaying the Numeric Entry panel by turning the knob or using the step keys while an active function is active.
Page 130 – Returns you to Local Control (if in Remote) – If the backlight is off, turns on the backlight, and does nothing else Most of this functionality is the same as earlier X-Series models and similar to ESA and PSA operation.
Page 131 2 User Interface 2.6 Onscreen Keyboard key 2.6 Onscreen Keyboard key This key turns the onscreen alpha keyboard (OSK) on and off. There are two onscreen keyboards: – The Multitouch OSK, which pops up automatically if, while using the analyzer application, a text field becomes the active function –...
Page 132 2 User Interface 2.7 Touch On/Off Key 2.7 Touch On/Off Key This front-panel key turns the display touch functionality on and off. If off, you can turn it back on using the front panel Touch On/Off key. When the touch functionality is off, you can still use a mouse as a pointer.
Page 133 2 User Interface 2.8 Tab key 2.8 Tab key This key has the same function as the Tab key on a PC keyboard. You can use this key to display the Windows Taskbar, as follows. – Alt-Tab to the Desktop –...
Page 134 2 User Interface 2.9 Local Button 2.9 Local Button Appears in the Menu Panel when the instrument is in remote, and can be brought back to local via the Local (ESC) Key. See also "Cancel key" on page 130. Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 135 2 User Interface 2.10 Control Bar 2.10 Control Bar The Control Bar contains controls and readouts that let you control instrument functions independent of the current measurement. Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 136 2 User Interface 2.11 Windows 2.11 Windows Pressing the Windows icon on the "Control Bar" on page 135 has the same effect as pressing the Windows icon on the Windows taskbar. It displays the Windows taskbar and Start Menu, which allows you to launch Windows programs and access features such as the Control Panel.
Page 137 2 User Interface 2.12 Undo/Redo 2.12 Undo/Redo The Undo button in the "Control Bar" on page 135, and the Undo front panel key, are used to undo the most recently executed function. If you Undo a function, and then decide you should not have done so, you can use the Redo button in the "Control Bar"...
Page 138 2 User Interface 2.12 Undo/Redo UNDO stack REDO stack Det = Peak RBW = 1MHz CF = 1 GHz When you press Undo, the top item on the Undo stack is removed, the action represented by that item is undone, and the item is placed on the Redo stack. So pressing Undo once in the above case would undo the setting of the peak detector, and the stacks would look like this: UNDO stack...
Page 139 2 User Interface 2.12 Undo/Redo For example, in the example above, if you now were to change another setting, such as VBW = 1 kHz, the Redo stack gets cleared, and the stacks would look like this: UNDO stack REDO stack VBW = 1 kHz RBW = 1MHz CF = 1 GHz...
Page 140 2 User Interface 2.12 Undo/Redo When you press the Redo icon or Ctl and the Undo hardkey, you are notified with an advisory popup message; for example, if the Center Frequency had been 300 MHz, and you changed it to 1 GHz and then pressed Undo, the message would say: UNDO: Center Freq 1 GHz ->...
Page 141 2 User Interface 2.13 File Functions 2.13 File Functions The File Functions popup contains controls for executing Save, Recall, File and Print operations. You display the File Functions popup by tapping the File Functions icon in the "Control Bar" on page 135.
Page 142 2 User Interface 2.14 Help 2.14 Help Pressing the Help button in the "Control Bar" on page 135, the Help front panel key, or the F1 key if you have a PC keyboard connected, opens the context-sensitive help system. The Help button appears in the "Control Bar"...
Page 143 2 User Interface 2.15 Status Bar 2.15 Status Bar The Status Panel (or Status Bar) appears at the bottom of the display and contains three fields: The Message Balloon appears on the left side of the Status Panel and lets you know when there is an unread message in the queue.
Page 144 2 User Interface 2.15 Status Bar The triangle is unfilled if no there are no open conditions, filled with yellow if all open conditions are warnings, and filled with red if at least one open condition is an error. The number displayed is the total number of open conditions. Touching the Condition Indicator opens up the Show Status dialog (see below) with the Current Conditions tab selected.
Page 145 2 User Interface 2.15 Status Bar If the display fills up, scrolling is enabled just as in other X-Series Multi-touch UI displays. The Status dialog automatically refreshes as new messages and conditions occur. At the bottom of the screen is a Clear Message Queue button. This button clears all errors in all error queues.
Page 146 In some legacy analyzers, the Repeat field shows the number of times the message has repeated since Compatibility the last time the error queue was cleared. In the X-Series, the Repeat field shows the number of times Notes the error has repeated since the last intervening error. So the count may very well be different than in...
Page 147 2 User Interface 2.15 Status Bar The fields on the History display are: Type Displays the icon identifying the event or condition as an error or warning Displays the error number Message Displays the message text Repeat (RPT) This field shows the number of consecutive instances of the event, uninterrupted by other events.
Page 148 2 User Interface 2.15 Status Bar peak found” – A condition is an occurrence of finite duration, that is, it has a start and an end. Conditions are states of the analyzer characterized by some combination of settings or some kind of failure that the user needs to be told about while it is happening, but then can stop being told once it goes away;...
Page 149 2 User Interface 2.15 Status Bar The fields on the Current Conditions display are: Type Displays the icon identifying the event or condition as an error or warning or informational Displays the error number Message Displays the message text Time Shows the most recent time (including the date) at which the event occurred.
Page 150 2 User Interface 2.15 Status Bar Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 151 2 User Interface 2.16 Block Diagram 2.16 Block Diagram When you press the Block Diagram button in the "Control Bar" on page 135, the display changes to a stylized pictorial representation of the current internal hardware setup and signal processing path. When you touch one of the blocks on the Block Diagram, the corresponding menu panel opens.
Page 152 2 User Interface 2.16 Block Diagram And here is the Block Diagram when the I/Q inputs are selected: Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 153 2 User Interface 2.17 View Editor 2.17 View Editor This section describes the use of the View Editor, which allows you to: – Add windows to and delete windows from the current measurement – Resize and rearrange windows – Create User Views User Views are custom Views that you create by adding, deleting, rearranging, resizing, or changing the contents of the windows in an existing View, and then saving the edited View as a new View.
Page 154 2 User Interface 2.17 View Editor Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 155 2 User Interface 2.17 View Editor Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 156 2 User Interface 2.17 View Editor You can save an edited View using the Save Layout as New View control in the View menu (see "To Save a User View" on page 167). On occasion, the instrument may automatically save an edited View for you. If you have edited a View, so that the * is displaying next to the View name, you must save that View as a User View before you save State or switch measurements.
Page 157 2 User Interface 2.17 View Editor To Close the View Editor Tap the View Editor button again. The user chooses the desired View through the use of the Mode/Meas/View dialog (see "Mode/Meas/View Dialog" on page 87) or the View menu (a tab under the Display key).
Page 158 2 User Interface 2.17 View Editor When you do this, you get the View Editor screen, which appears as below. The menu panel switches to the View menu. Here we see that we are in the Predefined View called “Basic”. Each window has two arrows containing + signs.
Page 159 2 User Interface 2.17 View Editor A fifth window has been added, and is automatically assigned the number 5. (The window number, which is displayed in the Window Title region, is used when sending SCPI commands to that window). Note the * that now appears next to Basic in the View menu, indicating that you are now in the modified Basic View.
Page 160 2 User Interface 2.17 View Editor A panel drops down, containing a Data control for specifying window results. Some measurements, such as LTE-A in this example, also provide controls on this dropdown for specifying other window parameters, such as the Component Carrier and Data Format, Tap the Data control and you will see a list of available results for the window.
Page 161 2 User Interface 2.17 View Editor Choose the result you want and tap OK. Here we have chosen IQ Meas Time from the Demod group: Your new, edited User View is now ready to use. Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 162 2 User Interface 2.17 View Editor 2.17.2 To Resize or Rearrange Windows in a View Sometimes you may wish to resize a window. To do this go back into the View Editor and note the large, translucent white circles along the edges of the draggable borders.
Page 163 2 User Interface 2.17 View Editor The outline of the window appears as it is being dragged. When you start to drag a window, target symbols appear in the other windows: If you drop a window on one of the targets, it swaps positions with the target window.
Page 164 2 User Interface 2.17 View Editor When you hover over one of the stripes it gets dimmer, to show the position the window being dragged will take on. If you release a window over an inner stripe, the window you are dragging and the window over which you were hovering resize to share the space the target window originally occupied.
Page 165 2 User Interface 2.17 View Editor In either case, one or more of the remaining windows resize to occupy the space formerly occupied by the window you were dragging. 2.17.3 To Delete a Window from a View The View Editor also lets you delete a window. To do this, tap one of the circled red X’s, as shown below.
Page 166 2 User Interface 2.17 View Editor Now press the View Editor button (the blue hand) to exit the View Editor. At this point, you have an edited Predefined View, as shown by the * next to Basic: When you are finished with it, you can restore the Layout to the default for Basic by pressing “Restore Layout to Default”.
Page 167 2 User Interface 2.17 View Editor View” (if you exit the measurement without saving the edited View, the instrument will save it for you as a User View called “Autosaved”). If you clone the current Screen by pressing the “+” tab, the modified Predefined View will be saved as a User View called “Autosaved”, and it will be available in the new Screen.
Page 168 2 User Interface 2.17 View Editor Notice the User View region which has appeared on the menu panel above, with the new User View called “My New View. Notice also that “Basic” has returned to its original, unedited state and the * is gone from its name. Note also that “Restore Layout to Default”...
Page 169 2 User Interface 2.17 View Editor When naming a new View, you must choose a name that is not already in use for any User View in any measurement; this is because User Views get written to permanent memory and are available to all instances of the Measurement in any screen. They survive a Mode Preset and also survive shutdown and restart of the application.
Page 170 2 User Interface 2.17 View Editor Measurement Name SCPI ID DDEMod Digital Demod DANalyzer Disturbance Analyzer IBSPurious EDR In-band Spurious Emissions EEVM FCAPture Fast Capture FSPectrum Fast Spectrum FMDeviation FM Deviation FMStereo FM Stereo FCOunter Frequency Counter FSCan Frequency Scan PFERror GMSK Phase &...
Page 171 2 User Interface 2.17 View Editor Measurement Name SCPI ID PMDeviation PM Deviation PAMPlifier Power Amplifier PCONtrol Power Control PSTatistic Power Stat CCDF EPVTime Power vs Time PULSe Pulse EVMQpsk QPSK EVM RTSC Real Time Scan RFPower RF Power SEMask FLATness Spectral Flatness RTSA...
Page 172 2 User Interface 2.17 View Editor Note that copying this file to another instrument will overwrite the file already in that instrument, if any, and will destroy any User Views that might have been created on that instrument. Note that when you delete the last User View for a measurement, the file is removed. 2.17.5 To Rename a User View You can rename a User View by selecting that View and tapping “Rename User View.”...
Page 173 2 User Interface 2.17 View Editor NOTE: There are legacy displays like Marker Table, Peak Table, Measure at Marker and Gate View, which are not Views but special display modes. These are retained for backwards compatibility, however they are turned on and off with switches and do not use the View system.
Page 174 2 User Interface 2.18 Multiscreen 2.18 Multiscreen You can configure up to 16 different Screens at a time. Normally, you only see one Screen, and the set of configured screens is shown across the top of the display in a series of "Screen Tabs"...
Page 175 2 User Interface 2.18 Multiscreen While in Multiscreen View, the button changes from a black background to a blue background: To exit Multiscreen view, tap the button again. Multiscreen View cannot be activated if only one screen is configured. Each Screen contains one Mode, each Mode contains one Measurement, and each Measurement contains a number of Windows arranged in Views.
Page 176 2 User Interface 2.18 Multiscreen – Each Screen has a tab that contains the name of the Mode and Measurement in the box and a number associated with the instance of that Mode. You can enter a custom Screen name that replaces the Mode name, by going into the Mode/Meas dialog –...
Page 177 2 User Interface 2.18 Multiscreen Preset Returns the name of the active screen 2.18.2 Screen List (Remote only command) You can obtain a list of currently configured Screens. This permits your remote program to manage screens for selection, renaming, or deletion. :INSTrument:SCReen:CATalog? Remote Command...
Page 178 In ESA/PSA, Full Screen was turned on with a softkey, so pressing any other key turned Full Screen off. Compatibility In the X-Series, because a hardkey is provided to turn this function on and off, pressing any other key Notes no longer turns off Full Screen Short Range Comms &...
Page 179 X-Series Signal Analyzers Short Range Comms & IoT Mode User's & Programmer's Reference 3 Short-Range Comms & IoT Mode This mode enables the instrument to automatically make the following measurements. The detailed results displayed by the measurements enable you to analyze ZigBee (IEEE 802.15.4) ,Z-Wave (ITU-T G.9959), and LoRa CSS system performance.
Page 180 3 Short-Range Comms & IoT Mode 3.1 Measurement Commands 3.1 Measurement Commands The commands for selecting each measurement are shown below. The commands relating to the Views and Windows for each measurement are described in the documentation for each measurement. Example Monitor Spectrum measurement :CONFigure:MONitor...
Page 181 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2 Modulation Analysis Measurement The Modulation Analysis measurement provides the capability of demodulating the modulated signal and displaying the demodulated signal in both the time and frequency domain. It also provides the metrics results such as error vector magnitude, frequency error, clock error, IQ offset, magnitude error and phase error.
Page 182 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Condition Return Value 4. Peak EVM Index (Peak Hold) is the location of the symbol that has the largest EVM 5. RMS Magnitude Error (Average) is a floating point number (in percent) of the average magnitude error over the entire measurement area 6.
Page 183 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Condition Return Value 21. Error Packet Number is a floating point number of the error packet number 22. Total Packet Number is a floating point number of the total packet number that is used to calculate PER Modulation not specified Returns the following 16 comma-separated scalar results:...
Page 184 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Condition Return Value dB/sym) of the change in the magnitude of the signal over the entire measurement 14. PER is a floating point number (in percent) of the packet error ratio 15.
Page 185 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Condition Return Value symbol clock error 12. PER is a floating point number (in percent) of the packet error ratio 13. Error Packet Number is a floating point number of the error packet number 14.
Page 186 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Condition Return Value trace data Modulation IQ Meas Time – returns a series of floating point numbers that Format = Offset alternately represent I and Q pairs of the corrected measured QPSK trace.
Page 187 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Condition Return Value Modulation IQ Ref Spectrum – returns the spectrum of the IQ reference time Format = Offset trace QPSK Modulation FSK Ref Spectrum – returns the spectrum of the reference time Format = 2 FSK trace Modulation...
Page 188 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.1 Views The Modulation Analysis measurement has five pre-defined views – "Normal" on page 188 view, "Demod Traces" on page 188 view, "Demod Error" on page 188 view "Decode" on page 189 view and "Result Summary"...
Page 189 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Multiple windows view consists of the above four windows. :DISP:EVM:VIEW DERR Example 3.2.1.4 Decode Windows:"Decode Results" on page 200 Single window view consists of the above window. :DISP:EVM:VIEW DEC Example 3.2.1.5 Result Summary Windows:"Metrics"...
Page 190 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :DISP:EVM:WIND2:DATA SPEC Example Sets the second window data to Spectrum :DISP:EVM:WIND2:DATA? Couplings Depends on window and modulation format Preset Depends on window and modulation format State Saved Range Raw Main Time | Spectrum | IQ Meas Time | IQ Ref Time | IQ Meas Spectrum | IQ Ref Spectrum | Error Vector Time | Error Vector Spectrum | Mag Error | Phase Error | CH Freq Response | EQ Impulse Response | Metrics | Demod Bits | Decode Results | FSK Meas Time | FSK Meas Spectrum | FSK Ref Time | FSK Ref Spectrum |FSK Error Time | FSK Error Spectrum | Carrier Mag Error | No Data...
Page 191 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement If the modulation format is 2-FSK, then the following replace the IQ measurement and reference time and spectrum data, and error vector magnitude data: Trace Data SCPI Description :MTIMe FSK Meas Time Demodulated Time Trace :MSPEctrum FSK Meas Spectrum...
Page 192 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement IQ Meas Time is the measured time data results for the input signal. There are 6 available formats for this trace data: I-Q, Constellation, Real, Imaginary, I-Eye and Q-Eye. Normally this trace data is displayed with I-Q format. Format name Description Real part of data is shown on horizontal axis, imaginary part is shown on vertical...
Page 193 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement IQ Meas Spectrum Available only for all modulation formats but 2-FSK. IQ Meas Spectrum is the frequency spectrum of the IQ Meas Time trace data. The demodulator produces the spectrum by windowing and FFT the IQ measured data. If the measured filter is selected, the spectrum represents the signal after filtering.
Page 194 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :DISP:EVM:WIND:FORM CONS selects Constellation as the first window data format FSK Ref Time Available only when the demodulation format is 2-FSK. FSK Ref Time is the reconstructed ideal time waveform to compare FSK Meas Time against.
Page 195 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement FSK Ref Spectrum is the frequency spectrum of the FSK Ref Time trace data. The demodulator produces the spectrum by windowing and FFT the FSK reference data. If the reference filter is selected, the spectrum represents the signal after filtering. :DISP:EVM:WIND:DATA RSPE Example sets the first window data to FSK Ref Spectrum...
Page 196 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Phase Error Available only for all modulation formats but 2-FSK. This trace shows the phase error trace in time domain. This trace is computed by comparing the unwrapped phase, point by points, of the IQ measured signal with the unwrapped phase of the IQ reference signal.
Page 197 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Response Displays the trace data choices that show equalizer response results. CH Freq Response The CH Frequency Response trace shows the channel frequency response for which the equalizer is correcting. It’s computed as the inverse of the equalization filter’s frequency response.
Page 198 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Peak Offset EVM location of the symbol which has peak Offset EVM in symbol XX sym Index the measurement area Rms EVM float64 EVM over the entire measurement area percent XX.XX % Peak EVM float64...
Page 199 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Freq Error float64 frequency error in the measured signal XX.XX ppm I/Q Offset float64 the I and Q error (magnitude squared) offset from XX.XX dB the origin Clock Error float64 Symbol clock error XX.XX ppm Amp Droop...
Page 200 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Decode Results Decode Results shows the PER and decode bits results. :DISP:EVM:WIND:DATA DECR Example sets the first window data to Decode Results 3.2.2.2 Format This control enables you to choose the available format of the selected trace. The formats are: Format Name Description...
Page 201 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement State Saved Range Log Mag (dB) | Linear Mag (Abs Value) | Real (I) (Lin) | Imaginary (Q) (Lin) | I-Q | Constellation | Phase | I- Eye | Q-Eye | Group Delay 3.2.3 Amplitude The Amplitude front-panel key activates the Amplitude menu and selects Reference Value as the active function.
Page 202 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Preset Depends on trace data State Saved Saved in instrument state Min/Max -9.9E+37/9.9E+37 Annotation The reference value is displayed above the graticule with the title “Ref Value” Scale/Div Controls the Y scale per division of the selected trace. :DISPlay:EVM:WINDow[1]|2|...|6:Y[:SCALe]:PDIVision <real>...
Page 203 Controls the attenuator functions and interactions between the attenuation system components. There are two attenuator configurations in the X-Series. One is a Dual-Attenuator configuration consisting of a mechanical attenuator and an optional electronic attenuator. The other configuration uses a single attenuator with combined mechanical and electronic sections that controls all the attenuation functions.
Page 204 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Note that Configuration 2 is not strictly speaking a dual-section attenuator, since there is no electronic section available. However, it behaves exactly like Configuration 1 without the Electronic Attenuator Option EA3, therefore for the sake of this document it is grouped into the “Dual-Attenuator”...
Page 205 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Full Range Atten This control and Attenuator Summary only appear in N9041B, when the RF input is selected, the RF Input Port is set to RF Input 2, and the Full Range Attenuator is installed.
Page 206 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Mech Atten Labeled Mech Atten in Dual-Attenuator models, and Atten in Single-Attenuator models. In the Dual-Attenuator configuration, this control only affects the mechanical attenuator. Lets you modify the attenuation applied to the RF input signal path. This value is normally auto-coupled to Ref Level, "Internal Preamp"...
Page 207 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 7.5 GHz to above 7.5 GHz, the attenuation setting changes to a multiple of 10 dB that is no smaller than the previous setting. For example, 4 dB attenuation changes to 10 dB Preset Auto The Auto value is 10 dB State Saved Saved in instrument state...
Page 208 As described under "Attenuation" on page 1636, there are two distinct attenuator configurations available in the X-Series, the Single Attenuator and Dual-Attenuator configurations. In Dual-Attenuator configurations, we have mechanical attenuation and electronic attenuation, and current total attenuation is the sum of electronic + mechanical attenuation.
Page 209 However, in the Single-Attenuator configuration, EATT SCPI commands are accepted for compatibility with other X-series instruments, and set a “soft” attenuation. The “soft” attenuation is treated as an addition to the “main” attenuation value set by the...
Page 210 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Transition Rules" on page 211 Preset 0 dB State Saved Saved in instrument state 0 dB Dual-Attenuator configuration: 24 dB Single-Attenuator configuration: the total of ATT and EATT cannot exceed 50 dB. So, if the EATT is set to 24 dB first, the main attenuation cannot be greater than 26 dB and will be reduced accordingly;...
Page 211 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Mechanical Attenuator Transition Rules When the Electronic Attenuator is enabled, the Mechanical Attenuator transitions to a state that has no Auto function. Below are the rules for transitioning the Mechanical Attenuator. Note that the information below only applies to the Dual- Attenuator configurations, and only when the Electronic Attenuator is installed: When the Electronic Attenuation is enabled from a disabled state: –...
Page 212 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Using the Electronic Attenuator: Pros and Cons The electronic attenuator offers finer steps than the mechanical attenuator, has no acoustical noise, is faster, and is less subject to wear. The “finer steps” advantage of the electronic attenuator is beneficial in optimizing the alignment of the instrument dynamic range to the signal power in the front panel as well as remote use.
Page 213 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement – Electric attenuator only – Combination of Electric attenuator and Mechanical attenuator when [:SENSe]:POWer[:RF]:RANGe:OPTimize IMMediate is executed. [:SENSe]:POWer[:RF]:RANGe:OPTimize:TYPE EONLy | COMBined Remote Command [:SENSe]:POWer[:RF]:RANGe:OPTimize:TYPE? :POW:RANG:OPT:TYPE EONL Example :POW:RANG:OPT:TYPE? Dependencies Does not appear in the Swept SA, RTSA, Monitor Spectrum and Complex Spectrum measurements Appears in the Waveform measurement in BASIC and 5G NR Modes COMBined Preset...
Page 214 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :POW:RANG:OPT:ATT? Notes The parameter option ELECtrical sets this function to in Single-Attenuator models The parameter option COMBined is mapped to ELECtrical in Single-Attenuator models. If you send COMBined, it sets the function to and returns ELEC to a query...
Page 215 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Single-Attenuator Models Dual-Attenuator models "Adjust Atten for Min Clipping" on page 1645 "Pre-Adjust for Min Clipping" on page 213 selection is Mech + Elec Atten: Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 216 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 217 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement "Pre-Adjust for Min Clipping" on page 213 selection is Elec Only. Note that the Mech Atten value is not adjusted, and the value previously set is used. Therefore, there is a case that IF Overload is still observed depending on the input signal level and the Mech Atten setting.
Page 218 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement [:SENSe]:POWer[:RF]:ATTenuation:STEP[:INCRement]? :POW:ATT:STEP 2 Example :POW:ATT:STEP? Notes Has a toggle control on the front panel, but takes a specific value (in dB) when used remotely. The only valid values are 2 and 10 Dependencies Blanked in EXA, CXA and CXA-m if option FSA (2 dB steps) is not present.
Page 219 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Not all measurements support Range Auto/Man. If Auto is not supported in the current measurement, this control is grayed-out, displaying Man, and returned to a SCPI query, but this does not change the Auto/Man setting for Range. When you switch to a measurement that supports Auto, it goes back to Auto if it was previously in Auto mode.
Page 220 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :VOLT:IQ:RANG? Notes The numeric entries are mapped to the smallest gain range whose break point is greater than or equal to the value, or 1 V Peak if the value is greater than 1 V Couplings When "Q Same as I"...
Page 221 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Q Range The internal gain range for the Q channel. Q Range only applies to Input Path Q Only and Ind I/Q. For input I+jQ "I Range" on page 1535 determines both I and Q channel range settings.
Page 222 State Saved Saved in instrument state OFF|ON Range 3.2.3.4 Range (Non-attenuator models) Only available for Keysight’s modular signal analyzers and certain other Keysight products, such as VXT and M941xE. State Saved Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 223 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Range Represents the amplitude of the largest sinusoidal signal that could be present within the IF without being clipped by the ADC. For signals with high peak-to- average ratios, the range may need to exceed the rms signal power by a significant amount to avoid clipping.
Page 224 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement [:SENSe]:POWer[:RF]:RANGe:OPTimize:ATTenuation? Notes Because there is no attenuator control available in these models, the control displays only choices. However, for SCPI compatibility with other platforms, all three parameters (ELECtrical, COMBined, and ON) are honored and all are mapped to ELECtrical, so if any of these three parameters is sent, a subsequent query will return ELEC Dependencies...
Page 225 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement via SCPI, but is not changeable. In such applications the control is grayed-out. Attempts to change the value via SCPI are ignored, but no error message is generated Dependencies Does not appear in Spectrum Analyzer Mode Preset VXT Models M9410A/11A 0 dB...
Page 226 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement This tab does appear in VXT Models M9410A/11A/15A/16A and M9410E/11E/15E/16E, because "Software Preselection" on page 1669 is under this tab, and VXT Models M9410A/11A/15A/16A and M9410E/11E/15E/16E implement a version of Software Preselection. Presel Center Adjusts the centering of the preselector filter to optimize the amplitude accuracy at the frequency of the selected marker.
Page 227 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement dependencies subsequent measurement has completed, nor are results returned in response to :READ :MEASure queries Measuring bit remains set (true) while this command is operating, and does not go false until the subsequent sweep/measurement has completed Proper Preselector Operation Certain considerations should be observed to ensure proper operation:...
Page 228 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement – Does not appear in VXT Models M9410A/11A/15A/16A – Does not appear in M9410E/11E/15E/16E – Grayed-out if microwave preselector is off – Grayed-out if entirely in Band 0, that is, if Stop Freq is lower than about 3.6 GHz –...
Page 229 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Selection Example Note :POW:GAIN OFF Low Band :POW:GAIN ON Sets the internal preamp to use only the low band. The frequency range of the installed (optional) low-band :POW:GAIN:BAND preamp is displayed in square brackets on the Low Band selection in the dropdown Full Range :POW:GAIN ON...
Page 230 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement When the USB Preamp is connected to USB, the Preamp annotation says “Preamp: USB” if the internal preamp is off or “Preamp: USB, Int” if the internal preamp is on (only for measurements that support the USB preamp) Auto Function [:SENSe]:POWer[:RF]:GAIN[:STATe] OFF | ON | 0 | 1...
Page 231 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement More Information When LNA is installed, the preamp annotation changes to show the state of both LNA and Internal Preamp. Below is an example: Note that when operating entirely in the low band (below about 3.6 GHz), if LNA is on, Internal Preamp is switched off (even if you have its switch set to ON).
Page 232 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement without giving the best possible noise floor. The preamp, if purchased and used, gives better noise floor than does Low Noise Path Enable, but the preamp’s compression threshold and third-order intercept are much poorer than that of Low Noise Path Enable.
Page 233 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement In any of these cases, if the required options are not present and the SCPI command is sent, error - 241, "Hardware missing; Option not installed" is generated Low Noise Path Enable and Full Bypass Enable are grayed-out if the current measurement does not support them Low Noise Path Enable and Full Bypass Enable are not supported in Avionics and MMR Modes (non- modulation measurements).
Page 234 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement This allows the function to automatically switch based on certain Auto Rules as shown below: VMA Mode Measurement µW Path Control Auto behavior Digital Demod Use Standard Path unless tuned frequency > 3.6 GHz and IFBW > 15 MHz, in which case choose Preselector Bypass Monitor Spectrum Always Presel Bypass...
Page 235 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Measurement µW Path Control Auto behavior Modulation Use Standard Path unless tuned frequency > 3.6 GHz and IFBW > 15 MHz, in Analysis which case choose Full Bypass if conditions warrant(FBP Option is available and “Allow Full Bypass in Auto”...
Page 236 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Low Noise Path Enable Low Noise Path Enable provides a lower noise floor under some circumstances, particularly when operating in the 21–26.5 GHz region. With the Low Noise Path enabled, the low band/high band switch and microwave preamp are bypassed whenever all the following are true: –...
Page 237 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement range of the preamp path is too little and the noise floor of the standard path is too high, the Low Noise Path can provide the best dynamic range The graph below illustrates the concept. It shows, in red, the performance of an instrument at different attenuation settings, both with the preamp on and off, in a measurement that is affected by both instrument noise and instrument TOI.
Page 238 Option MPB or pre-selector bypass provides an unpreselected input mixer path for certain X-Series signal analyzers with frequency ranges above 3.6 GHz. This signal path allows a wider bandwidth and less amplitude variability, which is an advantage when doing modulation analysis and broadband signal analysis.
Page 239 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement interface. Also, if the preamp is turned on, the Low Noise Path is not used, whether or not the Full Bypass Enable is selected in the user interface. The only time the Low Noise Path is used is when Full Bypass Enable is selected, the sweep is completely in High Band (>...
Page 240 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Preselector and Bandwidth Conflict When the Frequency Extender Preselector is applied and the signal bandwidth is greater than 2.5 [GHz], then a settings alert message will show to warn the user that the signal may be distorted due to the limitation of the Frequency Extender Preselector bandwidth.
Page 241 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement N9042B+V3050A Software Preselection compensates for the frequency range limit of the microwave preselector. Since the microwave preselector only goes up to 50 GHz, software preselection must be used to suppress and separate images above 50 GHz. The specific algorithm used for software preselection is specified by the SW Preselection Type selection –...
Page 242 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Preset N9041B N9042B+V3050A M9410A/11A State Saved Saved in instrument state SW Preselection Type Specifies the algorithm used for software preselection. Two hidden sweeps occur in succession. The second sweep is offset in LO frequency by 2 * IF / N.
Page 243 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement SW Preselection BW Specifies the effective bandwidth to be used for Software Preselection. The options are: – NORMal – when making Swept measurements, a software preselection algorithm is used which takes up to 4 background acquisitions, then post-processes the result.
Page 244 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement and 6000 MHz. The Prefilter provides the necessary rejection of the unwanted signal. [:SENSe]:<measurement>:PFILter[:STATe] ON | OFF | 1 | 0 Remote Command [:SENSe]:<measurement>:PFILter[:STATe]? Example Enable High Freq Prefilter for the Complex Spectrum Measurement in BASIC Mode: :SPEC:PFIL ON...
Page 245 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.4 BW The BW key opens the bandwidth menu, which contains the Info BW control. 3.2.4.1 Settings The Settings Tab contains controls that pertain to the X axis parameters of the measurement.
Page 246 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.5.1 Meas Display The Meas Display tab contains controls for setting up the display for the current Measurement, View or Window. Demod/Decode Bits Format This control enables you to choose the display format of demod bits and decode bits: hexadecimal or binary digits.
Page 247 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :DISP:VIEW ZSP Example sets the zone span view in Swept SA NORM Preset State Saved Saved in Instrument State User View Lets you choose a View from the saved User Views for the current measurement. This panel only appears if a User View exists for the current measurement.
Page 248 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement If the specified view is not a valid View, the query returns the error message “-224, Illegal parameter value; View with the name <alphanumeric> does not exist” :DISP:ENAB OFF) then the error message “-221, Settings conflict; If the display is disabled (via View SCPI cannot be used while Display is disabled”...
Page 249 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Rename User View You can rename the current View by giving it a new unique name. Only User Views can be renamed, if the current View is a Predefined View, an error occurs. :DISPlay:VIEW:ADVanced:REName <alphanumeric>...
Page 250 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :DISP:VIEW:ADV:DEL:ALL Example Notes Disabled if there are no User Views View Editor Remote Commands The following remote commands help you manage Views and User Views. Note that the SCPI node for User Views handles both Predefined and User Views. The legacy nodes, :DISPlay:VIEW[:SELect] and :DISPlay:VIEW:NSEL, are retained for...
Page 251 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.5.3 Annotation Contains controls for setting up the annotation for the current Mode or Measurement. Graticule Turns the display graticule On or Off for all windows with graticules in all measurements in the current Mode.
Page 252 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Trace Annotation Turns on and off the labels on the traces, showing their detector (or their Math Mode) as described in the Trace section, for all windows in all measurements in the current Mode for which Trace Annotation on/off is supported.
Page 253 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :DISP:ANN:MBAR OFF Example Dependencies Grayed out and forced to when System Display Settings, Annotation is Preset This remains through a Preset when System Display Settings, Annotation is set to State Saved Saved in instrument state Display Enable (Remote Command Only) Turns the display on/off, including the display drive circuitry.
Page 254 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Name Command :INSTrument:SCReen:DELete:ALL Delete All But This Screen :INSTrument:SCReen:CREate Add Screen :INSTrument:SCReen:REName Rename Screen :SYSTem:SEQuencer Sequencer On/Off :DISPlay:ENABle OFF | ON | 0 | 1 Remote Command :DISPlay:ENABle? :DISP:ENAB OFF Example Couplings :DISP:ENAB OFF...
Page 255 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement modes are also able to share a Mode Global center frequency value. If this is the case, the Mode will have a Global tab in its Meas Setup menu. [:SENSe]:FREQuency:CENTer <freq> Remote Command [:SENSe]:FREQuency:CENTer?
Page 256 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.7 Marker Accesses a menu that enables you to select, set up and control the markers for the current measurement. If there are no active markers, Marker selects marker 1, sets it to Normal and places it at the center of the display.
Page 257 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :CALCulate:EVM:MARKer[1]|2|...|12:X <real> Remote Command :CALCulate:EVM:MARKer[1]|2|...|12:X? :CALC:EVM:MARK:X 0.325 Example :CALC:EVM:MARK:X? Notes Marker X does not go outside the bounds of the data unless it is Fixed. If you attempt to set it to a value outside the bounds, it is clipped at the closest limit and error -222 Data Out of Range is generated If suffix is sent, it must match the X units for the trace the marker is on.
Page 258 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Marker Y Imag Enables you to set or read back the selected marker's quadrature (imaginary) Y value in the current Y Axis Scale unit. It has no affect (other than to cause the marker to become selected) if the marker mode is other than fixed or if the current trace format is not complex (Vector or Constellation).
Page 259 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :CALCulate:EVM:MARKer[1]|2|...|12:MODE POSition | DELTa | FIXed | OFF Remote Command :CALCulate:EVM:MARKer[1]|2|...|12:MODE? :CALC:EVM:MARK2:MODE POS Example :CALC:EVM:MARK2:MODE? Couplings The marker addressed by this command becomes the selected marker on the front panel Preset (all markers) State Saved...
Page 260 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement All Markers Off This control turns off all markers. :CALCulate:EVM:MARKer:AOFF Remote Command :CALC:EVM:MARK:AOFF Example Couple Markers When this function is On, moving any marker causes an equal X Axis movement of every other marker which is not Fixed or Off. ...
Page 261 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Peak Search Pressing the Peak Search control moves the selected marker to the trace point which has the maximum y-axis value for that trace. Pressing the Peak Search hardkey automatically moves you to the Peak Search NOTE page of the Marker menu AND performs a Peak Search.
Page 262 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Next Pk Left This control enables you to move the selected marker to the nearest peak left of the current marker that meets all enabled peak criteria. If there is no valid peak to the left of the current marker position, a “No peak found”...
Page 263 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :CALCulate:EVM:MARKer[1]|2|...|12:PTPeak Remote Command :CALC:EVM:MARK:PTP Example Notes Turns on the Marker D active function Couplings The selected marker becomes a delta marker if not already in delta mode State Saved Not part of saved state Marker Delta Pressing this control is exactly the same as pressing the “Delta”...
Page 264 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :CALC:EVM:MARK2:REF 4 Example :CALC:EVM:MARK2:REF? Notes This command causes the marker specified with the subopcode to become selected Range (for SCPI command): 1 to 12. If the range is exceeded the value is clipped A marker cannot be relative to itself so that choice is not available, and if sent from SCPI generates error -221: “Settings conflict;...
Page 265 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.7.5 Marker Function The controls on the Marker Function tab allow you to control the Marker Functions of the instrument. Marker Functions perform post-processing operations on marker data. Marker X This control enables you to set the X Axis value of the selected marker in the current X Axis Scale unit.
Page 266 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :CALC:EVM:MARK2:FUNC:BAND:SPAN? Preset When marker turned on, 1/20th of current span or displayed time length State Saved Min/Max -9.9E+37 / 9.9E+37 Band Left This control enables you to adjust the left side of the band. In order to remain centered in the band, the marker position must also change as you change the left edge.
Page 267 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.7.6 Marker To The controls on the Marker -> tab enable you to copy the current marker’s value into other instrument parameters (for example, Center Freq). The currently selected marker is made the active function on entry to this menu (if the currently selected marker is not on when you press this front panel key, it will be turned on at the center of the screen as a normal type marker and then made the active function).
Page 268 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.8.1 Settings The Settings tab contains the basic Bandwidth functions. It is the only tab under Bandwidth. Avg|Hold Number This control enables you to specify the number of N averages that will be used for the measurement.
Page 269 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Repeat After reaching the average count, the averaging is reset and a new average is started [:SENSe]:EVM:AVERage:TCONtrol EXPonential | REPeat Remote Command [:SENSe]:EVM:AVERage:TCONtrol? :EVM:AVER:TCON REP Example :EVM:AVER:TCON? Notes Selects the type of termination control used for averaging. This determines the averaging action after the specified number of frames (average count) is reached Preset EXPonential...
Page 270 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.8.2 Meas Standard This tab contains controls for setting the standard based on which the current measurement is made. The standards include ZigBee (IEEE 802.15.4), Z-Wave (ITU- T G.9959), LoRa (CSS) and HRP UWB.
Page 271 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement ZigBee (IEEE 802.15.4) LoRa HRP UWB Z-Wave (ITU-T G.9959) Channel Power Spurious Emissions CCDF IQ Waveform Monitor Spectrum Modulation Analysis (Digital) LoRa CSS Demod (Analog) Preset to Std This group of controls lets you easily set up the analyzer for ZigBee (IEEE 802.15.4), Z-Wave (ITU-T G.9959) , LoRa CSS or HRP UWB measurements.
Page 272 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement – For Spurious Emissions, there isn’t any customized setting for any radio standard; – SEM is only supported by ZigBee; – LoRa’s preset isn’t supported by SEM and ACP; The major changes of the settings of the power measurements which are impacted by preset to standard are listed in the table below.
Page 273 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Search Length This control enables you to define the time length that the analyzer searches for a burst. [:SENSe]:EVM:SYNC:SLENgth <time> Remote Command [:SENSe]:EVM:SYNC:SLENgth? :EVM:SYNC:SLEN 3.0 ms Example :EVM:SYNC:SLEN? Couplings Minimum: Meas Interval / Symbol Rate * 1.2 Maximum: Depends on span Preset 3.0E-3...
Page 274 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement State Saved Min/Max 21/4096 Annotation Time Length is annotated on the bottom right of Spectrum or Inst Spectrum traces, in units of Seconds. Time Length is Meas Interval / Symbol Rate. Under frequency-domain demod results, time length is annotated in units of symbols Capture Time Diagram This control accesses a dialog that enables you to set up time parameters.
Page 275 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement query the Y ref value of the third window Preset Depends on trace data State Saved Saved in instrument state Min/Max -9.9E+37/9.9E+37 Annotation The reference value is displayed above the graticule with the title “Ref Value” Ref Position Positions the reference level at the top, center, or bottom of the Y Scale display.
Page 276 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement [:SENSe]:EVM:SYNC:BURSt:STATe OFF | ON | 0 | 1 Remote Command [:SENSe]:EVM:SYNC:BURSt:STATe? :EVM:SYNC:BURS:STAT OFF Example :EVM:SYNC:BURS:STAT? Preset State Saved Range Off|On Annotation PULSE NOT FOUND appears in the corner of the demod result traces if a burst search fails Search Length This control enables you to define the time length that the analyzer searches for a burst.
Page 277 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement The resolution bandwidth is annotated below any spectrum trace. [:SENSe]:EVM:SWEep:POINts <integer> Remote Command [:SENSe]:EVM:SWEep:POINts? :EVM:SWE:POIN 501 Example :EVM:SWE:POIN? Preset State Saved Min/Max 21/4096 Annotation Time Length is annotated on the bottom right of Spectrum or Inst Spectrum traces, in units of Seconds. Time Length is Meas Interval / Symbol Rate.
Page 278 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement standard is not Z-Wave, the 2-FSK will be grayed out Preset OQPSK State Saved Range OQPSK|BPSK|FSK2 Symbol Rate This control enables you to set the symbol rate (symbols per second) for the analyzer's digital demodulator.
Page 279 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement If the Modulation Format is BPSK and 2FSK, the available values are 1, 2, 4, 5, 10 and 20 Numeric entries are rounded to the nearest valid value Preset State Saved Min/Max 1/20 Ref Filter...
Page 280 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement This control enables you to determine the filter characteristics of the Gaussian filter used by the analyzer's digital demodulator. [:SENSe]:EVM:FILTer:BT <real> Remote Command [:SENSe]:EVM:FILTer:BT? :EVM:FILT:BT 0.5 Example :EVM:FILT:BT? Dependencies This control is available for the Gaussian filter only Preset State Saved Min/Max...
Page 281 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement The following parameters affect measurement speed when using adaptive equalization: meas interval filter length (for the equalization filter) points/symbol [:SENSe]:EVM:EQUalization:STATe OFF | ON | 0 | 1 Remote Command [:SENSe]:EVM:EQUalization:STATe? :EVM:EQU:STAT ON Example :EVM:EQU:STAT?
Page 282 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Notes Must be an odd number. If an even number is entered, it is rounded up to the next odd Preset State Saved Min/Max 3/99 Convergence This control enables you to set the adaptive filter convergence factor higher to converge faster.
Page 283 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement FFT Window This control enables you to choose the Window function that is applied to the time data prior to the FFT calculation used for Spectrum, Error Vector Spectrum, IQ Meas Spectrum, and IQ Ref Spectrum results.
Page 284 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Use the eye diagram with an eye length of one (1) to observe the accuracy of the symbol clock timing. You can also monitor the EVM (Error Vector Magnitude) in the metrics table while adjusting the clock adjust to obtain the optimum symbol timing.
Page 285 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement State Saved Annunciation When this is on, the ideal state positions are identified by graphics on the constellation diagram Low SNR Enhancement This parameter enhances the ability of the demodulator to lock on to signals with low SNR.
Page 286 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement There are two possible FSK Deviation Reference modes: – Manual: This selection enables you to manually set the deviation reference. When a Preset to Standard FSK format is selected (e.g., Z-Wave R1 (9.6 kbps) FSK), the Manual field is populated with a deviation that is calculated using the format's data rate and modulation index.
Page 287 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement control “IF Gain” can be used to set the IF Gain function to Auto, or to On (the extra 10 dB) or Off. These settings affect sensitivity and IF overloads. This only applies to the RF input.
Page 288 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement [:SENSe]:EVM:LO:DITHer[:STATe] ON | OFF | 1 | 0 Remote Command [:SENSe]:EVM:LO:DITHer[:STATe]? :EVM:LO:DITH 1 Example :EVM:LO:DITH? Dependencies This feature is only available when the instrument has the Option H1G installed. If you try to turn ON LO Dither in any other case, an error message is generated, -241,"Hardware missing;...
Page 289 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 4: In instruments with EP0, balances close-in phase noise with spur avoidance. In instruments without EP0 this setting is accepted but no action taken 5: In instruments with EP0, emphasizes spur avoidance with close-in phase noise performance. In instruments without EP0 this setting is accepted but no action taken The actual behavior varies somewhat depending on model number and option;...
Page 290 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Best Close-In Phase Noise [offset < 140 kHz] | Best Wide-Offset Phase Noise [offset > 160 kHz] | Fast Tuning [single loop] EP2 & EP3: Best Close-In Phase Noise [offset < 70 kHz] | Best Wide-Offset Phase Noise [offset >...
Page 291 "Phase Noise Optimization Auto Rules" on page 293 for details on the Auto rules. The X-Series has two grades of LO; a high performance LO that gives the best phase noise performance; and a medium-performance LO that gives excellent performance.
Page 292 In instruments with Option EP0, this is the same configuration as the Best Spurs configuration. It is available with this “Fast Tuning” label to inform the user, and to make the user interface more consistent with other X-Series analyzer family members.
Page 293 This setting is never selected when Phase Noise Optimization is in Auto, you must select it manually. Phase Noise Optimization Auto Rules The X-Series has several grades of LO that offer different configurations when in the Auto Mode. – "Models with Option EP0" on page 293...
Page 294 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.8.6 Decode This tab enables you to set decode parameters. Decode This control enables you to turn decoding on and off. [:SENSe]:EVM:DECode:STATe OFF | ON | 0 | 1 Remote Command [:SENSe]:EVM:DECode:STATe? :EVM:DEC:STAT ON Example...
Page 295 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :EVM:DEC:DRAT:TYPE? Couplings Available only when the radio standard is Z-Wave and the demodulation format is 2-FSK Preset State Saved Range R1 | R2 | R3 3.2.8.7 Limits This tab accesses a menu that allows you to set the following limits: –...
Page 296 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :CALC:EVM:LIM:POW -30.0 dBm Example :CALC:EVM:LIM:POW? Preset -50.0 State Saved Min/Max -200.0 / 200.0 RMS EVM This control enables you to set the limit for the RMS EVM or FSK Error measurement pass/fail test.
Page 297 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :CALCulate:EVM:LIMit:FERRor:PPM <real> Remote Command :CALCulate:EVM:LIMit:FERRor:PPM? :CALC:EVM:LIM:FERR:PPM 40.0 Example :CALC:EVM:LIM:FERR:PPM? Preset 40.0 State Saved Min/Max 0.0 / 5.0e5 Clock Error This control enables you to set the limit for the symbol clock error measurement pass/fail test.
Page 298 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement 3.2.8.8 Global The controls in this menu apply to all Modes in the instrument. Some controls (for example, "Global Center Freq" on page 1717) allow you to switch certain Meas Global parameters to a Mode Global state. These switches apply to all Modes that support global settings.
Page 299 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Restore Defaults Resets all functions in the Global settings menu to OFF. Pressing System, Restore Defaults, All Modes has the same effect. :INSTrument:COUPle:DEFault Remote Command :INST:COUP:DEF Example :GLOBal:DEFault Backwards Compatibility SCPI 3.2.9 Sweep The Sweep key contains controls that allow you to control the sweep and...
Page 300 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Preset (Note that SYST:PRESet sets INIT:CONT *RST sets INIT:CONT to OFF) State Saved Saved in instrument state Annunciation The Single/Continuous icon in the Meas Bar changes depending on the setting. A line with an arrow is Single, a loop with an arrow is Continuous Backwards See the description of this control in the Swept SA measurement...
Page 301 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Restart The Restart function restarts the current sweep, or measurement, or set of averaged/held sweeps or measurements. If you are Paused, pressing Restart does a Resume. The front-panel key Restart performs this exact same function The Restart function is accessed in several ways: –...
Page 302 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Abort (Remote Command Only) This command is used to stop the current measurement. It aborts the current measurement as quickly as possible, resets the sweep and trigger systems, and puts the measurement into an "idle"...
Page 303 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Couplings If Auto Scaling is set to On, the X Width is determined by the trace data Preset Depends on trace data State Saved Min/Max -9.9E+37 / 9.9E+37 Ref Value Controls the X value of the selected trace at the chosen X Reference Position.
Page 304 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement :DISPlay:EVM:EYE:TRACe:INTerval <real> Remote Command :DISPlay:EVM:EYE:TRACe:INTerval? :DISP:EVM:EYE:TRAC:INT 300 Example :DISP:EVM:EYE:TRAC:INT? Preset State Saved 8192 Auto Scaling This control enables you to toggle the Auto Scaling function between On and Off. :DISPlay:EVM:WINDow[1]|2|...|6:X[:SCALe]:COUPle 0 | 1 | OFF | ON Remote Command :DISPlay:EVM:WINDow[1]|2|...|6:X[:SCALe]:COUPle?
Page 305 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement – Input/Output, "Data Source" on page 2101 A complete tutorial for Record/Playback functionality, including how to load and NOTE save recording files, can be found in the help for the tab "Data Source"...
Page 306 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement – Sweep, "Recording" on page 536 – Sweep, Playback (this tab) – Input/Output, "Data Source" on page 2101 A complete tutorial for Record/Playback functionality, including how to load and NOTE save recording files, can be found in the help for the tab "Data Source"...
Page 307 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Where <meas> is the mnemonic for the current measurement, for example, Example For EVM measurement in 5G NR Mode: :CALC:EVM:PLAY:MODE CONT :CALC:EVM:PLAY:MODE? Preset State Saved Saved in instrument state Range Fixed | Iterative Playback Start Once you have loaded an IQ data file using Recall, Recording, this control enables...
Page 308 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement In this mode, turn the knob or use the Up/Down keys on the front panel to move through records in the recording. You will see Playback Start change from 0 to successively higher values as you move deeper into the data.
Page 309 3 Short-Range Comms & IoT Mode 3.2 Modulation Analysis Measurement Command Where <meas> is the mnemonic for the current measurement, for example, Example For EVM measurement in 5G NR Mode: :CALC:EVM:PLAY:STEP:FORW State Saved Saved in instrument state Sample Rate Displays the sample rate of the recalled IQ data file if the recalled file format contains sampling rate information (.csv, .sdf, .txt).
Page 310 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3 LoRa (CSS) Demodulation Measurement This measurement provides the capability of demodulating the LoRa signals and displaying the demodulated signal both in the time domain and in the frequency domain.
Page 311 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Return Value Deviation (RMS) Max Hold (Hz) Burst length of the Analyzed Burst (s) Start Time of the Analyzed Burst (s) Preamble Length of the Analyzed Burst (the time elapse from the first preamble chirp to the start of the first header chirp) (s) Payload Length of the Analyzed Burst (the time elapse from the first header chirp to the end of the analyzed burst) (s)
Page 312 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Return Value The y-values are in units of Hz If Avg/Hold is off, all y-values are 1 GHz This query returns the max demod trace data as a list of x,y pairs. The x-axis values are in units of seconds. The y-values are in units of Hz If Avg/Hold is off, all y-values are -1 GHz This query returns the demod trace data as a list of x,y pairs.
Page 313 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Return Value This query returns the demod reference trace data as a list of x,y pairs. The x-axis values are in units of seconds. The y-values are in units of Hz If there is no stored reference trace or the reference trace is cleared, all y-values are -999.0 Returns the decimal values representing the demod bits (de-chirp bits) of the symbols starting from the first preamble within the analyzed burst.
Page 314 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement View Result "Demod Bits" on page 315 Demod Bits "Decode Summary" on page 315 Decode Info Decode Bits View – Selection by Enum (Remote Command Only) :DISPlay:LORA:VIEW[:SELect] QUAD | RFSPectrum | DEMod | AFSPectrum | ARTime | Remote DRIFt | DBITs | DECode Command...
Page 315 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.1.5 Transient Analysis Windows: "RF Envelope" on page 318, "Raw Demod Waveform" on page 319 The Transient Analysis view provides an easy way to measure DUT’s settling time, attack time or release time. In this view, the screen is split into two windows. The top window displays the RF envelope of the signal in the time domain, and the bottom window shows the demodulated signal in the time domain.
Page 316 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Window "Metrics" on page 321 "Result Table" on page 322 "Marker Table" on page 390 "Demod Bits" on page 323 "Decode Bits" on page 324 "Decode Info" on page 324 3.3.2.1 RF Spectrum This window shows a spectral display of the input RF signal with the ordinate being amplitude and the abscissa being time.
Page 317 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement will be performed on the truncated part based on the point number set by the demod waveform time under Sweep -> Sweep/Control. Four traces are provided by this window. See the following table. Trace Name Color Note...
Page 318 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.2.3 AF Spectrum The demodulated signal is displayed in the frequency domain on this window. Both the abscissa and the ordinate are frequency. The unit of the ordinate varies from Hz to dBHz depending on the type of the Y scale.
Page 319 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.2.5 Raw Demod Waveform The raw demodulated signal without interpolation is displayed in the time domain on this window. The abscissa is time. The ordinate is the modulation frequency. The Y axis is linearly scaled.
Page 320 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement The range of the display is determined by the parameters ref value, scale/div and ref position (under the Sweep\X Scale tab). 3.3.2.6 Frequency Drift vs Symbols For LoRa CSS signals, a frequency offset is intentionally imposed to each symbol. The abscissa is the index of symbols starting from the first preamble symbol and the ordinate is the value of the frequency drift imposed on each symbol.
Page 321 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement When averaging is On, four colored traces will be displayed on this window to represent the instantaneous frequency drift (green), the RMS averaged frequency drift (yellow), the max-hold frequency (cyan) drift and the min-hold frequency drift (magenta), respectively.
Page 322 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement When averaging is on, the column marked “current” is relabeled with “average” and the results in that column are averaged over the coming measurement cycles until the average/hold number is reached. After that, for continuous mode, exponential averaging will be applied for the successive measurement cycles.
Page 323 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Burst Length Represents the time duration of the analyzed burst Payload Represents the time duration of the payload in the analyzed burst. This is calculated by subtracting the Length preamble length from the burst length.
Page 324 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.2.10 Decode Bits This window displays both the state of the decoder and the decode bits of the analyzed payload symbols (including CRC, if the payload CRC exists). Ideally, the number of bytes displayed on this window equals the value set in Data Length (Byte) (Meas Setup ->...
Page 325 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.3 Amplitude The Amplitude key activates the Amplitude menu and selects the Reference Value as the active function. 3.3.3.1 Y Scale The Y Scale tab contains controls that pertain to the Y axis parameters of the measurement.
Page 326 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Raw Demod Waveform: 5 Frequency Drift vs Symbols: 6 :DISP:LORA:WIND:TRAC:Y:RLEV 20 dBm Example Couplings The reference values of the raw demod waveform window and the demod waveform window are coupled with the LoRa BW.
Page 327 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement RF Envelope: 4 Raw Demod Waveform: 5 Frequency Drift vs Symbols: 6 :DISP:LORA:WIND:TRAC:Y:PDIV 5 Db Example Couplings The Scale/Div of the raw demod waveform window and the demod waveform window are coupled with the LoRa BW.
Page 328 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Demod Waveform: 2 AF Spectrum: 3 RF Envelope: 4 Raw Demod Waveform: 5 Frequency Drift vs Symbols: 6 :DISP:LORA:WIND:TRAC:Y:RPOS BOTT Example Couplings The reference value of the raw demod waveform window and the demod waveform window are coupled with the LoRa BW.
Page 329 Controls the attenuator functions and interactions between the attenuation system components. There are two attenuator configurations in the X-Series. One is a Dual-Attenuator configuration consisting of a mechanical attenuator and an optional electronic attenuator. The other configuration uses a single attenuator with combined mechanical and electronic sections that controls all the attenuation functions.
Page 330 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Dual-Attenuator Configurations Configuration 1: Mechanical attenuator + optional electronic attenuator Configuration 2: Mechanical attenuator, no optional electronic attenuator Note that Configuration 2 is not strictly speaking a dual-section attenuator, since there is no electronic section available.
Page 331 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement (Note that depending on the measurement, there may be no Auto/Man functionality on the Mech Atten control.) In the Single-Attenuator configuration, you control the attenuation with a single control, as the fixed stage has only two states. In the Dual-Attenuator configuration, both stages have significant range, so you are given separate control of the mechanical and electronic attenuator stages.
Page 332 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement On the Meas Bar, the field “Atten” displays as follows: – If the sweep is entirely < 50 GHz, the value shown after “Atten:” is equal to Mech Atten + Elec Atten + Full Range Atten –...
Page 333 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Auto/Man is remembered and restored when the electronic attenuator is once again disabled. This is described in more detail in "Elec Atten" on page 1641 "Attenuator Configurations and Auto/Man" on page 334 for more information on the Auto/Man functionality Couplings...
Page 334 As described under "Attenuation" on page 1636, there are two distinct attenuator configurations available in the X-Series, the Single Attenuator and Dual-Attenuator configurations. In Dual-Attenuator configurations, we have mechanical attenuation and electronic attenuation, and current total attenuation is the sum of electronic + mechanical attenuation.
Page 335 However, in the Single-Attenuator configuration, EATT SCPI commands are accepted for compatibility with other X-series instruments, and set a “soft” attenuation. The “soft” attenuation is treated as an addition to the “main” attenuation value set by the Attenuation control or :POW:ATT, and affects the total attenuation displayed on the Attenuation Short Range Comms &...
Page 336 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement control and the Meas Bar The electronic attenuator, and the “soft” attenuation function provided in Single-Attenuator config- urations, are unavailable above the low band (0-3.6 GHz, 0-3.4 GHz, 0-3 GHz, depending on the model).
Page 337 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement :POW:EATT:STAT? Preset (Disabled) for Swept SA measurement (Enabled) for all other measurements that support the electronic attenuator The maximum Center Frequency for Low Band can change based on the NOTE selected IFBW for measurements that support IFBW (for example, Waveform measurement across all Modes that support it).
Page 338 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement – The Electronic Attenuator is set to 10 dB less than the previous value of the Mechanical Attenuator, within the limitation that it must stay within the range of 0 to 24 dB of attenuation Examples in the Dual-Attenuator configuration: –...
Page 339 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement electrical attenuator. With the mechanical attenuator, TOI, SHI, and compression threshold levels increase dB-for-dB with increasing attenuation, and the noise floor does as well. With the electronic attenuator, there is an excess attenuation of about 1 to 3 dB between 0 and 3.6 GHz, making the effective TOI, SHI, and so forth, less well known.
Page 340 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Pre-Adjust for Min Clipping If this function is ON, it applies the adjustment described under "Adjust Atten for Min Clipping" on page 1645 each time a measurement restarts. Therefore, in Continuous measurement mode, it only executes before the first measurement.
Page 341 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Range Dual-Attenuator models: Off | Elec Atten Only | Mech + Elec Atten Single-Attenuator models: Off | On Backwards Compatibility Command Notes aliases to "Elec Atten Only" (:POW:RANG:OPT:ATT ELEC) aliases to "Off"...
Page 342 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Single-Attenuator Models Dual-Attenuator models "Adjust Atten for Min Clipping" on page 1645 "Pre-Adjust for Min Clipping" on page 340 selection is Mech + Elec Atten: Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 343 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 344 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement "Pre-Adjust for Min Clipping" on page 340 selection is Elec Only. Note that the Mech Atten value is not adjusted, and the value previously set is used. Therefore, there is a case that IF Overload is still observed depending on the input signal level and the Mech Atten setting.
Page 345 All other models: 2 dB State Saved Saved in instrument state 3.3.3.3 Range (Non-attenuator models) Only available for Keysight’s modular signal analyzers and certain other Keysight products, such as VXT and M941xE. State Saved Range Represents the amplitude of the largest sinusoidal signal that could be present within the IF without being clipped by the ADC.
Page 346 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Adjust Range for Min Clipping Sets the combination of attenuation and gain based on the current measured signal level so that clipping will be at a minimum. This is an "immediate action" function, that is, it executes once, when the key is pressed.
Page 347 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Peak-to-Average Ratio Used with "Range (Non-attenuator models)" on page 1651 to optimize the level control in the instrument. The value is the ratio, in dB, of the peak power to the average power of the signal to be measured.
Page 348 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Mixer Lvl Offset This is an advanced setting to adjust target Range at the input mixer, which in turn affects the signal level in the instrument’s IF. This setting can be used when additional optimization is needed after setting "Peak-to-Average Ratio"...
Page 349 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement between Start Freq and Stop Freq, the instrument first performs a peak search, and then performs centering on the marker’s center frequency. The value displayed on "Preselector Adjust" on page 1656 changes to reflect the new preselector tuning.
Page 350 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement search to find 2. If the selected marker is already On, the instrument attempts the centering at that marker’s frequency. There is no preselector for signals below about 3.6 GHz, so if the marker is on a signal below 3.6 GHz, no centering is attempted, and an advisory message is generated 3.
Page 351 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement State Saved The Preselector Adjust value set by "Presel Center" on page 1654, or by manually adjusting Preselector Adjust Not saved in instrument state, and does not survive a Preset or power cycle Min/Max –/+500 MHz [:SENSe]:POWer[:RF]:MW:PADJust...
Page 352 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement The maximum Center Frequency for Low Band, displayed in square brackets, NOTE can change based on the selected IFBW for measurements that support IFBW (for example, Waveform measurement across all Modes that support it). In certain models (such as N9042B &...
Page 353 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement LNA is an additional preamplifier that provides superior DANL and frequency range compared to "Internal Preamp" on page 1657. LNA provides lower system noise figure, especially at frequencies above 100 MHz, and can be operated up to the full range of 50 GHz instruments.
Page 354 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement µW Path Control Options for this control include µW Preselector Bypass (Option MPB), Low Noise Path (Option LNP) and Full Bypass Enable in the High Band path circuits. When the µW Preselector is bypassed, flatness is improved, but will be subject to spurs from out of band interfering signals.
Page 355 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement [:SENSe]:POWer[:RF]:MW:PATH STD | LNPath | MPBypass | FULL Remote Command [:SENSe]:POWer[:RF]:MW:PATH? :POW:MW:PATH LNP Example Enables the Low Noise path :POW:MW:PATH? Notes When "Presel Center" on page 1654 is performed, the instrument momentarily switches to the Standard Path, regardless of the setting of µW Path Control The DC Block will always be switched in when the low noise path is switched in, to protect succeeding circuitry from DC.
Page 356 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Annotation In the Meas Bar, if the Standard path is chosen: µW Path: Standard If Low Noise Path is enabled but the LNP switch is not thrown: µW Path: LNP,Off If the Low Noise Path is enabled and the LNP switch is thrown: µW Path: LNP,On If the preselector is bypassed:...
Page 357 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Measurement µW Path Control Auto behavior Always Presel Bypass Always Presel Bypass Spurious Always Standard Path Emissions WLAN Mode Measurement µW Path Control Auto behavior Modulation Always Presel Bypass Analysis Spectral Flatness Always Presel Bypasss...
Page 358 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Measurement µW Path Control Auto behavior Emissions Transmit On|Off Use Standard Path unless tuned frequency > 3.6 GHz and Info BW > 15 MHz, in Power which case choose Preselector Bypass Channel Quality Mode Measurement µW Path Control Auto behavior...
Page 359 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement whether or not the Low Noise Path Enable is selected in the user interface. The only time the Low Noise Path is used is when Low Noise Path Enable is selected, the sweep is completely in High Band (>...
Page 360 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement There are other times where selecting the low noise path improves performance, too. Compression-limited measurements such as finding the nulls in a pulsed-RF spectrum can profit from the low noise path in a way similar to the TOI-limited measurement illustrated.
Page 361 3.3 LoRa (CSS) Demodulation Measurement Option MPB or pre-selector bypass provides an unpreselected input mixer path for certain X-Series signal analyzers with frequency ranges above 3.6 GHz. This signal path allows a wider bandwidth and less amplitude variability, which is an advantage when doing modulation analysis and broadband signal analysis.
Page 362 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement whenever Full Bypass Enable is selected, a warning message appears in the status bar: “Full Bypass Enabled, maximum safe input power reduced” Microwave Preselector Bypass Backwards Compatibility Example Bypass the microwave preselector: :POW:MW:PRES OFF Notes Included for Microwave Preselector Bypass backwards compatibility...
Page 363 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Settings Alert message in the error queue Software Preselection Provided in some instruments, either to compensate for issues with provided hardware preselection or to provide the preselection function when there is no hardware preselector.
Page 364 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Note that for N9042B+V3050A, in the Swept SA measurement, Software Preselection works even if the measurement is using an FFT Sweep Type. In measurements other than Swept SA, Software Preselection is not used if the measurement is using an FFT Sweep Type.
Page 365 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Two hidden sweeps occur in succession. The second sweep is offset in LO frequency by 2 * IF / N. For each point in each trace, the smaller amplitude from the two traces is taken and placed in that point in the selected trace.
Page 366 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement wideband signals with occupied bandwidths up to 2 GHz. This increases the risk of images failing to be rejected, but improves the measurement speed [:SENSe]:POWer[:RF]:SWPResel:BW NORMal | NARRow Remote Command [:SENSe]:POWer[:RF]:SWPResel:BW? :POW:SWPR:BW NARR Example...
Page 367 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement State Saved Saved in instrument state Prefilter Presets Meas Mode Preset SPEC BASIC BASIC, WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA WCDMA WCDMA PCON WCDMA EVMQ WCDMA...
Page 368 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement [:SENSe]:LORA:BANDwidth[:RESolution] <bandwidth> Remote Command [:SENSe]:LORA:BANDwidth[:RESolution]? :LORA:BAND 5.1 kHz Example :LORA:BAND? Notes Only certain discrete resolution bandwidths are available. For numeric entries, all RBW Types choose the nearest (arithmetically, on a linear scale, rounding up) available RBW to the value entered Couplings When the RF resolution bandwidth is set to auto, the resolution bandwidth is automatically calculated according to the span with an approximate ratio of span/RBW being 106:1.
Page 369 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Preset 25 kHz State Saved Saved in instrument state 390 Hz Hardware dependent: – No Option = 10 MHz – Option B25 = 25 MHz – Option B40 = 40 MHz –...
Page 370 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement AF Res BW Auto [:SENSe]:LORA:AFSPectrum:BANDwidth:AUTO ON | OFF | 1 | 0 Remote Command [:SENSe]:LORA:AFSPectrum:BANDwidth:AUTO? :LORA:AFSP:BAND:AUTO ON Example :LORA:AFSP:BAND:AUTO? AUTO Preset 3.3.5 Display The Display key opens the Display Menu, which enables you to configure display items for the current Mode, Measurement View or Window.
Page 371 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Peak+ Only Only displays the Peak+ metric on the metrics window. :DISP:LORA:VIEW:METR:MMAG PPK Example Pk-Pk/2 Only Only displays the Pk-Pk/2 metric on the metrics window. :DISP: LORA:VIEW:METR:MMAG PNPK Example RMS Only Only displays the RMS metric on the metrics window.
Page 372 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement is generated, the RMS Ratio and Ratio Ref values display --- and queries of either return not a number (9.91 e37). To turn off the ratio display, select one of the other modulation magnitude views. The ratio references are saved in State, and when the recalled state of the metrics settings is RMS Ratio, the saved reference for the current measurement should be recalled and used, rather than establishing a new one.
Page 373 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement State Saved Saved in instrument state 0.1 Hz 1GHz Set Reference Sets the ratio reference value for the RMS ratio’s calculation. This has the same effect as sending the SCPI command “:DISP:LORA:VIEW:METR:MMAG RMSR”. Carrier Power Unit Toggles the unit of the carrier power on the metrics window between watts and dBm.
Page 374 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Views Lets you choose a View from the predefined Views for the current measurement. The Views vary from measurement to measurement. See the “Views” section of your measurement’s help for a list of all the Views supported by your measurement. If you have modified the current View, using the "View Editor"...
Page 375 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement measurement, you send: :DISP:VIEW:ADV:SEL "Trace Zoom" because “Trace Zoom” is the name of the View as seen in the Mode/Meas dialog or in the Display, View menu You cannot use the legacy View parameter (which in this case would be TZOom) with :DISP:VIEW:ADV:SEL <alphanumeric>...
Page 376 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Re-Save User View You can re-edit a User View; if you make changes, then an asterisk will appear next to the User View’s name. You can then tap Re-Save User View to save it back to its existing name, or Save Layout as New View to add another, new User View.
Page 377 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict; View SCPI cannot be used while Display is disabled” is generated Delete All User Views Deletes all previously saved User Views.
Page 378 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement :DISPlay:VIEW:ADVanced:USER:CATalog? Remote Command :DISP:VIEW:ADV:USER:CAT? Example Notes Returns a quoted string of the available User Views for the current measurement, separated by commas. Example: "Baseband,myView1,yourView1" If you switch measurements with the display disabled (see "Display Enable (Remote Command Only)"...
Page 379 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement This does not include marker annotation (or the N dB result). When OFF, the graticule expands to fill the entire graticule area, leaving only the 1.5% gap above the graticule, as described in the Trace section. :DISPlay:ANNotation:SCReen[:STATe] OFF | ON | 0 | 1 Remote Command :DISPlay:ANNotation:SCReen[:STATe]?
Page 380 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement This remains through a Preset when System Display Settings, Annotation is set to State Saved Saved in instrument state Meas Bar Turns the Measurement Bar at the top of the screen on and off for all measurements in the current Mode.
Page 381 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement If the display is OFF, many SCPI commands related to User Views and Multiscreen functionality do not work, and return the error messages “-221, Settings conflict; Screen SCPI cannot be used when Display is disabled” or “221, Settings conflict; View SCPI cannot be used while Display is disabled”.
Page 382 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Center Frequency Sets the displayed center frequency value. [:SENSe]:FREQuency:CENTer <freq> Remote Command [:SENSe]:FREQuency:CENTer? :FREQ:CENT 50 MHz Example :FREQ:CENT UP Changes the center frequency to 150 MHz if you use FREQ:CENT:STEP 100 MHz to set the center frequency step size to 100 MHz...
Page 383 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement [:SENSe]:LORA:FREQuency:SPAN <freq> Remote Command [:SENSe]:LORA:FREQuency:SPAN? :LORA:FREQ:SPAN 10 MHz Example :LORA:FREQ:SPAN? Dependencies If the electrical attenuator is enabled, any attempt to set the span such that the stop Frequency would be greater than 3.6 GHz will result in an error Preset 75 kHz...
Page 384 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Increases the current center frequency value by 500 MHz :FREQ:CENT:STEP? Notes Preset and Max values are depending on Hardware Options (503, 507, 508, 513, 526) Dependencies Freq Offset is not available in External Mixing. In this case the Freq Offset control is grayed out and shows a value of zero.
Page 385 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement [:SENSe]:LORA:AFSPectrum:FREQuency:STARt? Command :LORA:AFSP:FREQ:STAR 10 Hz Example :LORA:AFSP:FREQ:STAR? Couplings If the start frequency is set to a value less than the value of the stop frequency minus 10 Hz, the stop frequency will not change during the adjustment of the start frequency.
Page 386 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.7.1 Select Marker Specifies the selected marker. The term “selected marker” is used throughout this document to specify which marker will be affected when you change marker settings, perform a peak search, etc. The control appears above the menu panel, indicating that it applies to all the controls under the marker menu.
Page 387 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Marker Amplitude Accesses the specified marker’s Y-Axis value. The value of this parameter is settable only when the marker’s mode is fixed. :CALCulate:LORA:MARKer[1]|2|...|12:Y <real> Remote Command :CALCulate:LORA:MARKer[1]|2|...|12:Y? Notes This command (not the query) makes the specified marker to be the selected marker Preset 9.91E+37 -9.9E+37...
Page 388 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Couplings The marker specified by this command will be set as the selected marker Preset State Saved The marker control mode (Normal, Delta, Fixed, Off) and X Axis value are saved in instrument state Range Normal|Delta|Fixed|Off Annunciation...
Page 389 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Value Example Notes By default, the reference marker for marker 1 is marker 2; for marker 2 is 3 and so on, but the reference marker can be changed. See "Relative To"...
Page 390 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement A delta marker is forced to Normal mode if you turn its reference off or if you move its reference to another trace. (In the latter case the reference is not turned off even if it is fixed.) If you change the selected marker's reference (using the Marker, Properties, Relative To), the selected marker is forced to Delta mode.
Page 391 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement All Markers Off Turns off all markers. :CALCulate:LORA:MARKer:AOFF Remote Command :CALC:LORA:MARK:AOFF Example 3.3.7.3 Peak Search The controls on the peak search tab provide the users with a convenient way of identifying the peaks of the signal.
Page 392 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Pressing the peak search hardkey will navigate the menu to the peak search NOTE page and perform a peak search if the previous menu wasn’t of markers. Marker Frequency|Time Sets the X-axis position of the specified marker on the trace.
Page 393 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement :CALCulate:LORA:MARKer[1]|2|...|12:MINimum Remote Command :CALC:LORA:MARK:MIN Example State Saved Not part of saved state Pk-Pk Search Looks for the peak and the pit on the trace where the specified marker locates and displays the amplitude and frequency (or time, if in the time domain) differences between the peak and the pit.
Page 394 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.7.4 Properties The controls on the properties tab are used to set certain properties of the specified marker. Marker Frequency|Time Sets the X-axis position of the selected marker on the trace. This is the same as the "Marker Frequency|Time"...
Page 395 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement the bottom tip of the diamondThe lines are blue in color. If the marker is off screen the lines should be extended from the marker so that they go through the screen area if possible. This is really useful for off screen Fixed markers as it lets you see their amplitude even though they are off the X Axis.
Page 396 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Auto Initialize When the auto initialize function is true for the specified marker, the marker’s trace is pre-determined automatically by the analyzer whenever the marker is on (Normal, Delta or Fixed). When the parameter is switched off for the specified marker, the association between the marker and its trace remains.
Page 397 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement This flowchart makes it clear that putting all lower-numbered traces in View is the simplest way to specify which trace you want the markers to go to when they turn on.
Page 398 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Marker Frequency|Time Sets the X-axis position of the selected marker on the trace. This is the same as the "Marker Frequency|Time" on page 386 in the Settings tab. Mkr->CF Sets the center frequency of the analyzer to the frequency of the specified marker.
Page 399 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Window Average Type RF Spectrum Pwr Average Demod Waveform Arithmetic Average Frequency Drift vs. Symbols Arithmetic Average AF Spectrum Log Average [:SENSe]:LORA:AVERage:COUNt <integer> Remote Command [:SENSe]:LORA:AVERage:COUNt? [:SENSe]:LORA:AVERage[:STATe] ON | OFF | 1 | 0 [:SENSe]:LORA:AVERage[:STATe]? :LORA:AVER:COUN 10 Example...
Page 400 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement The RF spectrum and AF spectrum traces are not averaged. The demod waveform window will display only the demod trace. The frequency drift window will display only the frequency drift trace. The metrics window will display only a “current”...
Page 401 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Auto Couple Changes all Auto/Man settings in the measurement to either auto or manual. :COUPle ALL Remote Command :COUP ALL Example Backwards :COUPLE NONE puts all Auto/Man parameters in manual mode, decoupling all the coupled Compatibility instrument parameters Notes...
Page 402 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Auto Setup GUI only, no SCPI command. When Auto Setup is selected, the current sweep is aborted, and a full measurement will be performed. The results of the measurement will be used to determine the following settings: Ref Value, Scale/Div, Ref Position of Y Scale of Demod Waveform, RF Envelope, Raw Demod Waveform, and Freq Drift;...
Page 403 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement [:SENSe]:RADio:STANdard ZIGBee | ZWAVe | LORA | HUWB Remote Command [:SENSe]:RADio:STANdard? :RAD:STAN ZIGB Example :RAD:STAN? Notes This setting was removed from GUI in XA25 because “Preset to Standard” was redesigned using cascading list, thus all radio standards and the associated preset options are accessible at one time.
Page 404 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Notes “Preset to Standard” was re-designed using cascading list dialog in XA25, thus all radio standards and the associated preset options are accessible at one time (prior to XA25, users need to select Radio Standard first, then select “preset to standard”...
Page 405 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.8.3 Demod This tab contains the parameters of the LoRa PHY layer. Spreading Factor Sets the spreading factor of the chirp signal, which affects the symbol period and the bit rate. [:SENSe]:LORA:DEMod:SFACtor <integer>...
Page 406 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement This bandwidth does not affect the data acquisition. Theoretically, the value of this parameter should be less than the value of the channel bandwidth. [:SENSe]:LORA:DEMod:BANDwidth BW7K | BW10K | BW15K | BW20K | BW31K | BW41K | Remote BW62K | BW125K | BW203K | BW250K | BW406K | BW500K | BW812K | BW1625K Command...
Page 407 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement :LORA:DEM:BAND BW20K Example 31.25 kHz Sets the bandwidth of the chirp signal to 31.25 kHz. :LORA:DEM:BAND BW31K Example 41.667 kHz Sets the bandwidth of the chirp signal to 41.667 kHz. :LORA:DEM:BAND BW41K Example 62.5 kHz...
Page 408 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 406.25 kHz Sets the bandwidth of the chirp signal to 400 kHz. :LORA:DEM:BAND BW406K Example 812.5 kHz Sets the bandwidth of the chirp signal to 812.5 kHz. :LORA:DEM:BAND BW812K Example 1.625 MHz Sets the bandwidth of the chirp signal to 1.625 MHz.
Page 409 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Invert Polarity Toggles the state of the invert polarity between on and off. [:SENSe]:LORA:DEMod:PINVert[:STATe] OFF | ON | 0 | 1 Remote Command [:SENSe]:LORA:DEMod:PINVert[:STATe]? :LORA:DEM:PINV ON Example :LORA:DEM:PINV? Preset State Saved Range On|Off...
Page 410 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Decode from Header This parameter determines if the parameters used by decoding the payload are obtained from decoding the header. If not, the parameters are obtained from the manual settings. This parameter is switched off and grays out when Implicit Header is switched On.
Page 411 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement [:SENSe]:LORA:DECode:CRC[:STATe]? :LORA:DEC:CRC ON Example :LORA:DEC:CRC? Dependencies The control is only enabled when: Implicit Header is On, Or Implicit Header and Decode from Header are both Off Preset State Saved Range On|Off Data Length (Byte)
Page 412 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Preset State Saved Range On|Off 3.3.8.5 Time Sets the time related parameters for the demodulation. Meas Interval Sets the number of symbols to be analyzed, i.e., the maximum length of the frequency drift vs.
Page 413 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.8.6 Filters Sets the filter applied after the demodulation. If a filter is switched on but fails to be applied, the error “161 Setting Modified; Filters not applied” will appear. Highpass Filter (Post Demod) Adjusts the post demodulation high pass filters.
Page 414 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 50 Hz Sets the post demodulation high pass filter to 50 Hz. It is a 2-pole Butterworth filter, its 3 dB cutoff frequency is 50 Hz. :LORA:HPF HPF50 Example 300 Hz Sets the post demodulation high pass filter to 300 Hz.
Page 415 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Dependencies Only active when high pass filter type is Manual Preset 500 Hz State Saved Saved in instrument state Min/Max 20 Hz / Half of the maximum DIF BW Lowpass Filter (Post Demod) Adjusts the post demodulation low pass filter.
Page 416 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3 kHz Selects the 3 kHz post demodulation low pass filter. It is a 5-pole Butterworth filter, its 3 dB cutoff frequency is 3 kHz. :LORA:LPF LPF3K Example 15 kHz Selects the 15 kHz post demodulation low pass filter.
Page 417 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 100 kHz Selects the 100 kHz (“>20 kHz”) post demodulation low pass filter. It is a 9-pole Bessel filter designed for minimum overshoot (<1% nom) on square wave modulation, its 3 dB cutoff frequency is 100 kHz. :LORA:LPF LPF100K Example Manual...
Page 418 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Other controls (for example, Extend Low Band) are actually set in this menu, but apply to all Modes. Global Center Freq The software maintains a Mode Global value called Global Center Freq. When Global Center Freq is switched ON, the current Mode’s center frequency is copied into the Global Center Frequency, and from then on all Modes that support global settings use the Global Center Frequency, so you can switch between any of...
Page 419 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement 3.3.9 Sweep The Sweep key accesses controls for users to configure and control the acquisition of data and the X-axis parameters of the instrument. 3.3.9.1 Sweep Control This tab accesses controls for users to configure Sweep Control parameters, such as the sweep time and the continuous/single mode.
Page 420 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Demod Waveform Points Sets the number of points of the demod waveform trace. [:SENSe]:LORA:DWSWeep:POINts <integer> Remote Command [:SENSe]:LORA:DWSWeep:POINts? :LORA:DWSW:POIN 1001 Example :LORA:DWSW:POIN? Preset 1001 State Saved Saved in instrument state Min/Max 101 / 100001 Meas Time...
Page 421 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement empirical data symbol length. The product will be further multiplied with an empirical coefficient and eventually set as the minimum measure time Preset 72 ms State Saved Saved in instrument state Min/Max 1 us / 100 s Meas Time Auto...
Page 422 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement More Information With Avg/Hold Num (in the Meas Setup menu) set to Off or set to On with a value of 1, a sweep is taken after the trigger condition is met; and the analyzer continues to take new sweeps after the current sweep has completed and the trigger condition is again met.
Page 423 Notes restart Max Hold and Min Hold In the X-Series, the Restart hardkey and the INITiate:RESTart command restart not only Trace Average, but Max Hold and Min Hold traces as well For wireless comms modes in ESA and PSA, the Restart hardkey and the INITiate:RESTart command restart every measurement, which includes all traces and numeric results.
Page 424 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement (sweep) taken once the trigger condition is met. If the analyzer is in the process of aligning when a Restart is executed, the alignment finishes before the restart function is performed. Even when set for Single operation, multiple sweeps may be taken when Restart is pressed (for example, when averaging/holding is on).
Page 425 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Does not display in Modes that do not support Pausing Annotation Only on control 3.3.9.2 X Scale This tab accesses controls that enable you to set the horizontal scale parameters. Ref Value Sets the reference value of the abscissa of the RF envelope window, the raw demod waveform window, and the frequency drift window.
Page 426 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Notes WINDow4: RF envelope window WINDow5: raw demod waveform window Couplings If the value is not a multiple of the sample interval, it’ll be adjusted to the closest multiple For window #4 and #5, the X scale parameters of both windows are coupled when the X axis coupled is on, and decoupled otherwise Preset...
Page 427 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Preset State Saved Saved in instrument state Width Sets the width of the X axis of the frequency drift window. :DISPlay:LORA:WINDow6:TRACe:X[:SCALe]:WIDTh <real> Remote Command :DISPlay:LORA:WINDow6:TRACe:X[:SCALe]:WIDTh? :DISP:LORA:WIND6:TRAC:X:WIDT 1000 Example :DISP:LORA:WIND6:TRAC:X:WIDT? Dependencies Changing the measure interval ...
Page 428 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Sample Rate Display sample rate of recalled IQ data file if recalled file format contains sampling rate information(.csv, .sdf, .txt). Set sampling rate to playback recalled IQ data if recalled file format is .bin or .binx which does not contain sampling rate information.
Page 429 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement Sample Time (Display Only) Display the total sample time of saved IQ data file. 3.3.10 Trace The Trace menu lets you control the acquisition, display, storage, detection and manipulation of trace data for the available traces. 3.3.10.1 Trace Control The controls on the Trace Control tab allow you to set the type of the Trace.
Page 430 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement :DISP: LORA:TRAC:DAV OFF Turn off the Demod Average trace display :DISP: LORA:TRAC:DAV? Dependencies The max demod trace, the min demod trace and the average demod trace are only visible when the averaging is on Preset State Saved...
Page 431 3 Short-Range Comms & IoT Mode 3.3 LoRa (CSS) Demodulation Measurement :DISPlay:LORA:RTRace[:STATe] OFF | ON | 0 | 1 Remote Command :DISPlay:LORA:RTRace[:STATe]? :DISP:LORA:RTR OFF Example :DISP:LORA:RTR? Dependencies An error message will appear when this control is switched on if there was no reference trace stored. The control remains off The stored reference trace will be purged when either the time, the offset or the points number of the demod waveform changes.
Page 432 Programming the Instrument. Note that, in general, :CONF:<Measurement> resets the specified measurement settings to their defaults. X-Series permits the addition of the NDEFault node to the command, which prevents a measurement preset after a measurement switch. The tables below list setup commands for this measurement and queries to retrieve results.
Page 433 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Return Value The Q values are the odd-indexed values. Not specified Returns the following comma-separated scalar results: or 1 Item Unit Frequency Error Channel Power Time Offset Rmarker – first chip after SFD Chip Clock Error Main Lobe Peak Main Lobe Width...
Page 434 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Return Value Pass/Fail result of Main lobe width Pass/Fail result of Side Lobe Peak Pass/Fail result of STS Normalized RMSE Pass/Fail result of SHR Normalized RMSE Pass/Fail result of Data Normalized RMSE Pass/Fail result of Transmit Mask Limit Pass/Fail result of PHR Normalized RMSE Pass/Fail result of PSDU Normalized RMSE...
Page 435 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Return Value ERDEV-BPRF. For item 15 (SECDED Status), possible values and corresponding error types are: value SECDED Status Unknown Single Error Double Error For item 14 (SECDED Err Loc), the number specifies the error location of SECDED, and is valid only when SECDED Status is Single Error.
Page 436 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement View SCPI Windows NORMal "RRC Correlated" on page 437 "Transmit Mask" on page 437 "Raw Main Time" on page 437 "Impulse Response" on page 438 "Metrics" on page 437 DECode "Decode Summary"...
Page 437 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Window "Frame Info" on page 438 "Impulse Response" on page 438 "Error Vector Time" on page 438 "MMS Packet Results" on page 438 3.4.2.1 RRC Correlated Window #1 Shows the cross-correlation between the measured UWB pulse and a root raised cosine (RRC) pulse.
Page 438 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Shows the measurement numeric results. The available tabular data changes depending on the modulation format chosen. 3.4.2.6 Decoded Bits Window #6 Shows the decoded bits. 3.4.2.7 Frame Info Window #7 Shows the detail frame information results.
Page 439 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement 3.4.3 Amplitude Activates the Amplitude menu and selects Reference Level or Reference Value as the active function, depending on the measurement. Some features in this menu apply to multiple measurements. Some other features apply only to specific measurements and their controls are blanked or grayed-out in measurements that do not support the feature.
Page 440 Controls the attenuator functions and interactions between the attenuation system components. There are two attenuator configurations in the X-Series. One is a Dual-Attenuator configuration consisting of a mechanical attenuator and an optional electronic Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 441 Meas Preset. Only available when the hardware set includes an input attenuator, which is typically only the case for Keysight’s benchtop instruments. For example, this tab does not appear in VXT models M9420A/10A/11A/15A/16A, M9410E/11E/15E/16E, nor in UXM. In UXM, all Attenuation and Range settings are disabled, as the expected input power level is handled by the Call Processing App that drives the DUT power control.
Page 442 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Single-Attenuator Configuration You can tell which attenuator configuration you have by pressing the Attenuation tab, which (in most Modes) opens the Attenuation menu. If the first control in the Attenuation menu says Mech Atten you have the Dual-Attenuator configuration.
Page 443 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :POW:FRAT? Notes When you enter an amplitude value that falls between valid values, the value will be incremented to the next smallest valid value Dependencies Only appears if input RF is selected, RF Input Port 2 is selected, and the Full Range Attenuator exists Couplings This value is never changed by any coupling, but other couplings use this value.
Page 444 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement [:SENSe]:POWer[:RF]:ATTenuation <rel_ampl> Remote Command [:SENSe]:POWer[:RF]:ATTenuation? :POW:ATT 20 Example Dual-Attenuator configuration: sets the mechanical attenuator to 20 dB Single-Attenuator mode: sets the main attenuation to 20 dB (see below for definition of “main” attenuation) In either case, if the attenuator was in Auto, it is set to Manual Dependencies...
Page 445 As described under "Attenuation" on page 1636, there are two distinct attenuator configurations available in the X-Series, the Single Attenuator and Dual-Attenuator configurations. In Dual-Attenuator configurations, we have mechanical attenuation and electronic attenuation, and current total attenuation is the sum of electronic + mechanical attenuation.
Page 446 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement the Single-Attenuator configuration, for compatibility purposes). Then current total attenuation is the sum of main + soft attenuation. "Elec Atten" on page 1641 for more about “soft” attenuation. In some measurements, the Mech Atten control has an Auto/Man function. In NOTE these measurements, an Auto/Man switch is shown on the Mech Atten control: Note that in configurations that include an Electronic Attenuator, this switch is...
Page 447 However, in the Single-Attenuator configuration, SCPI commands are accepted for compatibility with other X-series instruments, and set a “soft” attenuation. The “soft” attenuation is treated as an addition to the “main” attenuation value set by the...
Page 448 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Auto Function [:SENSe]:POWer[:RF]:EATTenuation:STATe OFF | ON | 0 | 1 Remote Command [:SENSe]:POWer[:RF]:EATTenuation:STATe? :POW:EATT:STAT ON Example :POW:EATT:STAT? Preset (Disabled) for Swept SA measurement (Enabled) for all other measurements that support the electronic attenuator The maximum Center Frequency for Low Band can change based on the NOTE selected IFBW for measurements that support IFBW (for example, Waveform...
Page 449 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement knob, and it behaves as it normally would in manual mode – The Auto/Man state of (Mech) Atten is saved – The Auto/Man toggle on the (Mech) Atten control disappears, and the auto rules are disabled –...
Page 450 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement than the even-decibel steps, so one tradeoff for this superior relative accuracy is reduced absolute amplitude accuracy. Another disadvantage of the electronic attenuator is that the spectrum analyzer loses its “Auto” setting, making operation less convenient. Also, the relationship between the dynamic range specifications (TOI, SHI, compression, and noise) and instrument performance are less well-known with the electrical attenuator.
Page 451 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :POW:RANG:OPT:TYPE? Dependencies Does not appear in the Swept SA, RTSA, Monitor Spectrum and Complex Spectrum measurements Appears in the Waveform measurement in BASIC and 5G NR Modes COMBined Preset State Saved Saved in instrument state Pre-Adjust for Min Clipping...
Page 452 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement "Pre-Adjust for Min Clipping" on page 451 is grayed-out Does not appear in the Swept SA, RTSA, Monitor Spectrum and Complex Spectrum measurements Appears in the Waveform measurement in BASIC and 5G NR Modes ELEC Preset when Elec Atten is Disabled at preset, otherwise...
Page 453 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Single-Attenuator Models Dual-Attenuator models "Adjust Atten for Min Clipping" on page 1645 "Pre-Adjust for Min Clipping" on page 451 selection is Mech + Elec Atten: Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 454 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 455 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement "Pre-Adjust for Min Clipping" on page 451 selection is Elec Only. Note that the Mech Atten value is not adjusted, and the value previously set is used. Therefore, there is a case that IF Overload is still observed depending on the input signal level and the Mech Atten setting.
Page 456 All other models: 2 dB State Saved Saved in instrument state 3.4.3.3 Range (Non-attenuator models) Only available for Keysight’s modular signal analyzers and certain other Keysight products, such as VXT and M941xE. State Saved Range Represents the amplitude of the largest sinusoidal signal that could be present within the IF without being clipped by the ADC.
Page 457 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Adjust Range for Min Clipping Sets the combination of attenuation and gain based on the current measured signal level so that clipping will be at a minimum. This is an "immediate action" function, that is, it executes once, when the key is pressed.
Page 458 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Peak-to-Average Ratio Used with "Range (Non-attenuator models)" on page 1651 to optimize the level control in the instrument. The value is the ratio, in dB, of the peak power to the average power of the signal to be measured.
Page 459 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Mixer Lvl Offset This is an advanced setting to adjust target Range at the input mixer, which in turn affects the signal level in the instrument’s IF. This setting can be used when additional optimization is needed after setting "Peak-to-Average Ratio"...
Page 460 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement between Start Freq and Stop Freq, the instrument first performs a peak search, and then performs centering on the marker’s center frequency. The value displayed on "Preselector Adjust" on page 1656 changes to reflect the new preselector tuning.
Page 461 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement search to find 2. If the selected marker is already On, the instrument attempts the centering at that marker’s frequency. There is no preselector for signals below about 3.6 GHz, so if the marker is on a signal below 3.6 GHz, no centering is attempted, and an advisory message is generated 3.
Page 462 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement State Saved The Preselector Adjust value set by "Presel Center" on page 1654, or by manually adjusting Preselector Adjust Not saved in instrument state, and does not survive a Preset or power cycle Min/Max –/+500 MHz [:SENSe]:POWer[:RF]:MW:PADJust...
Page 463 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement The maximum Center Frequency for Low Band, displayed in square brackets, NOTE can change based on the selected IFBW for measurements that support IFBW (for example, Waveform measurement across all Modes that support it). In certain models (such as N9042B &...
Page 464 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement LNA is an additional preamplifier that provides superior DANL and frequency range compared to "Internal Preamp" on page 1657. LNA provides lower system noise figure, especially at frequencies above 100 MHz, and can be operated up to the full range of 50 GHz instruments.
Page 465 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement µW Path Control Options for this control include µW Preselector Bypass (Option MPB), Low Noise Path (Option LNP) and Full Bypass Enable in the High Band path circuits. When the µW Preselector is bypassed, flatness is improved, but will be subject to spurs from out of band interfering signals.
Page 466 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement [:SENSe]:POWer[:RF]:MW:PATH STD | LNPath | MPBypass | FULL Remote Command [:SENSe]:POWer[:RF]:MW:PATH? :POW:MW:PATH LNP Example Enables the Low Noise path :POW:MW:PATH? Notes When "Presel Center" on page 1654 is performed, the instrument momentarily switches to the Standard Path, regardless of the setting of µW Path Control The DC Block will always be switched in when the low noise path is switched in, to protect succeeding circuitry from DC.
Page 467 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Annotation In the Meas Bar, if the Standard path is chosen: µW Path: Standard If Low Noise Path is enabled but the LNP switch is not thrown: µW Path: LNP,Off If the Low Noise Path is enabled and the LNP switch is thrown: µW Path: LNP,On If the preselector is bypassed:...
Page 468 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Measurement µW Path Control Auto behavior Always Presel Bypass Always Presel Bypass Spurious Always Standard Path Emissions WLAN Mode Measurement µW Path Control Auto behavior Modulation Always Presel Bypass Analysis Spectral Flatness Always Presel Bypasss...
Page 469 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Measurement µW Path Control Auto behavior Emissions Transmit On|Off Use Standard Path unless tuned frequency > 3.6 GHz and Info BW > 15 MHz, in Power which case choose Preselector Bypass Channel Quality Mode Measurement µW Path Control Auto behavior...
Page 470 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement whether or not the Low Noise Path Enable is selected in the user interface. The only time the Low Noise Path is used is when Low Noise Path Enable is selected, the sweep is completely in High Band (>...
Page 471 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement There are other times where selecting the low noise path improves performance, too. Compression-limited measurements such as finding the nulls in a pulsed-RF spectrum can profit from the low noise path in a way similar to the TOI-limited measurement illustrated.
Page 472 3.4 HRP UWB Demodulation Measurement Option MPB or pre-selector bypass provides an unpreselected input mixer path for certain X-Series signal analyzers with frequency ranges above 3.6 GHz. This signal path allows a wider bandwidth and less amplitude variability, which is an advantage when doing modulation analysis and broadband signal analysis.
Page 473 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement whenever Full Bypass Enable is selected, a warning message appears in the status bar: “Full Bypass Enabled, maximum safe input power reduced” Microwave Preselector Bypass Backwards Compatibility Example Bypass the microwave preselector: :POW:MW:PRES OFF Notes Included for Microwave Preselector Bypass backwards compatibility...
Page 474 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Settings Alert message in the error queue Software Preselection Provided in some instruments, either to compensate for issues with provided hardware preselection or to provide the preselection function when there is no hardware preselector.
Page 475 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Note that for N9042B+V3050A, in the Swept SA measurement, Software Preselection works even if the measurement is using an FFT Sweep Type. In measurements other than Swept SA, Software Preselection is not used if the measurement is using an FFT Sweep Type.
Page 476 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Two hidden sweeps occur in succession. The second sweep is offset in LO frequency by 2 * IF / N. For each point in each trace, the smaller amplitude from the two traces is taken and placed in that point in the selected trace.
Page 477 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement wideband signals with occupied bandwidths up to 2 GHz. This increases the risk of images failing to be rejected, but improves the measurement speed [:SENSe]:POWer[:RF]:SWPResel:BW NORMal | NARRow Remote Command [:SENSe]:POWer[:RF]:SWPResel:BW? :POW:SWPR:BW NARR Example...
Page 478 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Prefilter Presets Meas Mode Preset SPEC BASIC BASIC, WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA WCDMA WCDMA PCON WCDMA EVMQ WCDMA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA WCDMA, LTEAFDD, LTEATDD, 5GNR, VMA, SA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA...
Page 479 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :HUWB:BAND 8 MHz Example :HUWB:BAND? Preset 750 MHz State Saved Saved in instrument state Min/Max 1 kHz / Max Info BW Max Info BW depends on Data Source and Input Type: Data Source Type Option...
Page 480 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement user interface. For example, if you are trying to select the Trace Zoom view in the Swept SA measurement, you send: :DISP:VIEW:ADV:SEL "Trace Zoom" because “Trace Zoom” is the name of the View as seen in the Mode/Meas dialog or in the Display, View menu You cannot use the legacy View parameter (which in this case would be TZOom) with :DISP:VIEW:ADV:SEL...
Page 481 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement View SCPI cannot be used while Display is disabled” is generated Re-Save User View You can re-edit a User View; if you make changes, then an asterisk will appear next to the User View’s name.
Page 482 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement delete a Predefined View” is generated If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict; View SCPI cannot be used while Display is disabled” is generated Delete All User Views Deletes all previously saved User Views.
Page 483 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement User View Listing Query Returns a string containing a comma-separated list of names for only the User Views available for the current Measurement. :DISPlay:VIEW:ADVanced:USER:CATalog? Remote Command :DISP:VIEW:ADV:USER:CAT? Example Notes Returns a quoted string of the available User Views for the current measurement, separated by commas.
Page 484 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Screen Annotation Controls the display of the annunciation and annotation around the graticule, including any annotation on lines (such as the display line, the threshold line, etc.) and the Y-Axis annotation, for all windows with screen annotation in all measurements in the current Mode.
Page 485 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Control Annotation Turns on and off the display of values on the Active Function controls for all measurements in the current Mode. This is a security feature. :DISPlay:ACTivefunc[:STATe] ON | OFF | 1 | 0 Remote Command :DISPlay:ACTivefunc[:STATe]? :DISP:ACT OFF...
Page 486 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement – and you are in local operation, the display can be turned back on by pressing any :SYSTem:DEFaults MISC :DISPlay:ENABle ON key or by sending (neither *RST nor :SYSTem:PRESet enable the display) –...
Page 487 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement 3.4.6 Frequency Opens the Frequency menu, which contains controls representing frequency settings. 3.4.6.1 Settings Contains controls that pertain to the X axis parameters of the measurement. These parameters control the way the data is presented on the abscissa. Channel Sets the channel number of the transmitted signal.
Page 488 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :FREQ:CENT? Couplings Coupled with "Channel" on page 487 Setting Channel sets Center Frequency to the value corresponding to that channel Setting Center Frequency also changes the Channel value. If the Center Frequency value entered does not exactly correlate with a channel, the key label changes to display the closest channel number to the entered frequency, along with a >...
Page 489 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Couplings When auto-coupled in a non-zero span, the center frequency step size is set to 10% of Span. When auto-coupled in zero span, the center frequency step size is set to the equivalent -3 dB RBW value AUTO Preset State Saved...
Page 490 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement 3.4.7.1 Select Marker Specifies the selected marker. The term “selected marker” is used throughout this document to specify which marker will be affected when you change marker settings, perform a peak search, etc. This control appears above the menu panel, indicating that it applies to all controls under the Marker menu.
Page 491 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement POSition Normal A marker that can be moved to any point on the X Axis by specifying its X Axis value, and whose absolute Y Axis value is then the value of the trace point at that X Axis value DELTa Delta...
Page 492 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Value SCPI Notes at all unless the traces have the same domain and ranges) By default, the reference marker for marker 1 is marker 2; for marker 2 is 3 and so on, but the reference marker can be changed.
Page 493 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Preset OFF. Preset by Mode Preset and All Markers Off State Saved Saved in instrument state 3.4.7.3 Peak Search The controls on this tab provide a convenient way of identifying the peaks of the signal.
Page 494 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement If there is no valid peak lower than the current marker position, a “No peak found” message is generated, and the marker is not moved. If the selected marker was Off, then it is turned on as a Normal marker and a peak search is performed.
Page 495 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :CALCulate:HUWB:MARKer[1]|2|…|12:MINimum Remote Command :CALC:HUWB:MARK:MIN Example State Saved Not part of saved state Pk-Pk Search Looks for the peak and the pit on the trace where the specified marker locates and displays the amplitude and frequency (or time, if in the time domain) differences between the peak and the pit.
Page 496 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :CALCulate:HUWB:MARKer[1]|2|…|12:REFerence? Command :CALC:HUWB:MARK3:REF 2 Example :CALC:HUWB:MARK3:REF? Notes Range (for SCPI command): 1 to 12. If the range is exceeded the value is clipped A marker cannot be relative to itself so that choice is not available, and if sent from SCPI generates error -221: “Settings conflict;...
Page 497 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Normal When the auto initialize function is on, the marker trace is automatically set whenever the marker is switched on RFSP Preset State Saved Saved in instrument state Range RRC Correlated | Transmit Mask | Spectrum | Raw Main Time | Impulse Shape | Error Vector Time | Transmit Mask Limit Option Details...
Page 498 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement [:SENSe]:HUWB:AVERage:COUNt <integer> Remote Command [:SENSe]:HUWB:AVERage:COUNt? :HUWB:AVER:COUN 1000 Example :HUWB:AVER:COUN? Preset State Saved 10000 Averaging On/Off Turns averaging on or off. [:SENSe]:HUWB:AVERage[:STATe] OFF | ON | 0 | 1 Remote Command [:SENSe]:HUWB:AVERage[:STATe]? :HUWB:AVER OFF Example...
Page 499 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement State Saved EXPonential|REPeat Range Auto Couple Immediately puts all Auto/Man functions into Auto. Auto Couple is confined to the current measurement only. It does not affect other measurements in the Mode. In the Auto state, Auto/Man functions are said to be “coupled”, meaning their values change as you make changes to other values in the measurement.
Page 500 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement parameters. The coupling and dependency rules for each parameter are defined in the section describing that parameter. Executing Auto Coupledoes not affect markers, marker functions, trace or display attributes, or any other instrument setting other than those specifically mentioned above.
Page 501 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :CONF:HUWB Example Auto Re-Calculation In single mode, turn on/off automatic result recalculation and update (without measurement restart) when you change specific parameters (unless the change triggered Capture Length change): Name Path Search Length...
Page 502 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Option SCPI Description NERDev Non-ERDEV Selects the original PHY mode defined by the 802.15.4-2015 standard BPRF ERDEV- Selects the base pulse repetition frequency (BPRF) ERDEV mode BPRF defined by the 802.15.4z standard HPRF ERDEV- Selects the higher pulse repetition frequency (HPRF) ERDEV mode...
Page 503 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement [:SENSe]:HUWB:MMS[:STATe] OFF | ON | 0 | 1 Remote Command [:SENSe]:HUWB:MMS[:STATe]? :HUWB:MMS ON Example :HUWB:MMS? Couplings Available when PHY Mode is ERDEV HPRF and STS Packet Configuration is SP3 Preset State Saved OFF|ON...
Page 504 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement State Saved Saved in instrument state 1|…|32 Range Delta Length Sets the zero interpolation of the code to create a sync symbol (Si) for UWB synchronization header (SHR). Available Delta Length choices also depend on which "Channel"...
Page 505 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement SFD # Sets which SFD (start-of-frame delimiter) sequence is used for UWB synchronization header (SHR). [:SENSe]:HUWB:SHR:SFD:NUMBer <integer> Remote Command [:SENSe]:HUWB:SHR:SFD:NUMBer? :HUWB:SHR:SFD:NUMB 2 Example :HUWB:SHR:SFD:NUMB? Dependencies Only available when "PHY Mode" on page 501 is ERDEV-HPRF or ERDEV-BPRF Valid values: ERDEV-BPRF: 0, 2...
Page 506 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement – Length-128 Sequence: Length-128 complementary MMRS sequences – Length-91 Ternary Code: Length-91 ternary codes as defined in Table 15-7a of IEEE 802.15.4z-2020 – Length-127 Ternary Code: length-127 4z ternary codes as defined in Table 15-7 of IEEE 802.15.4-2020 [:SENSe]:HUWB:RSF:MMRS:SEQuence L128 | L91 | L127 Remote...
Page 507 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :HUWB:RSF:ZGAP:NUMB? Preset State Saved Saved in instrument state MMRS Symbol Repetitions Sets the number of MMRS symbol repetitions within one RSF. [:SENSe]:HUWB:RSF:MMRS:SREPetition S32 | S40 | S48 | S64 | S128 | S256 Remote Command [:SENSe]:HUWB:RSF:MMRS:SREPetition?
Page 508 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Preset State Saved Saved in instrument state 0|1|2|4|8 Range Additional Gap to RSF (RIF only) Enables an extra 1 ms gap between RSFs and RIFs. [:SENSe]:HUWB:RIF:AGAP[:STATe] OFF | ON | 0 | 1 Remote Command [:SENSe]:HUWB:RIF:AGAP[:STATe]? :HUWB:RIF:AGAP ON...
Page 509 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Number of Segments Sets the total number of segments in the STS field. [:SENSe]:HUWB:STS:SEGMent:NUMBer N1 | … | N4 Remote Command [:SENSe]:HUWB:STS:SEGMent:NUMBer? :HUWB:STS:SEGM:NUMB N2 Example Couplings "PHY Mode" on page 501 –...
Page 510 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :HUWB:STS:KEY 14148674D1D336AAF86050A814EB220F Example :HUWB:STS:KEY? Couplings Available when "PHY Mode" on page 501 is not Non-ERDEV, "STS Packet Configuration" on page 502 not No STS and Modulation Analysis is enabled Must be a 32-character string, entered in hexadecimal format.
Page 511 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement PHR/PSDU Parameters Hop Bursts Sets the number of hopping burst locations in each half of a BPM-BPSK symbol. [:SENSe]:HUWB:DATA:HBURsts <integer> Remote Command [:SENSe]:HUWB:DATA:HBURsts? :HUWB:DATA:HBUR 8 Example :HUWB:DATA:HBUR? Couplings There are only three valid values: 2, 8, 32 Available when "PHY Mode"...
Page 512 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Constraint Length Sets the convolutional code to use. is the original code defined in the 2015 standard. is defined in the 802.15.4z standard. [:SENSe]:HUWB:DATA:CONStraint:LENGth CL3 | CL7 Remote Command [:SENSe]:HUWB:DATA:CONStraint:LENGth? :HUWB:DATA:CONS:LENG CL3 Example...
Page 513 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement FCS Type The MAC may optionally employ the 4-octet FCS with the HRP UWB PHY in HPRF mode, but in all other HRP UWB PHY modes shall employ the 2-octet FCS. [:SENSe]:HUWB:DATA:FCSType OCTet2 | OCTet4 Remote Command...
Page 514 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :HUWB:TIME:SLEN 1ms Example :HUWB:TIME:SLEN? Preset 1 ms State Saved Depends on signal configuration Depends on System BW Search Offset Search Offset specifies the start position of input data for valid burst search. [:SENSe]:HUWB:TIME:SOFFset <time>...
Page 515 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Search Offset + Search Length Depends on System BW 3.4.8.4 Demod Contains parameters for the UWB PHY layer. Data Analysis Enables analysis of the data portion of the frame (PHR+PSDU) to calculate the power metrics and NRMSE result.
Page 516 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :HUWB:COMP:CCLO ON Example :HUWB:COMP:CCLO? Preset State Saved OFF|ON Range Advanced Demod Setup Configures advanced demodulation parameters. Phase Tracking Enables phase tracking. [:SENSe]:HUWB:PHASe:TRACking[:STATe] OFF | ON | 0 | 1 Remote Command [:SENSe]:HUWB:PHASe:TRACking[:STATe]? :HUWB:PHAS:TRAC ON...
Page 517 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Exclude TX Settling Time From NRMSE Computation Sets the transmitter settling time in seconds. The samples within TX settling time are omitted in analysis or NRMSE computation. [:SENSe]:HUWB:TX:STIMe[:EFNRmse] <time> Remote Command [:SENSe]:HUWB:TX:STIMe[:EFNRmse]? :HUWB:TX:STIM 1us...
Page 518 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :CALC:HUWB:LIM:TEST? Preset State Saved OFF|ON Range Main Lobe Width Sets the limit for main lobe width pass/fail test. :CALCulate:HUWB:LIMit:MLWidth <time> Remote Command :CALCulate:HUWB:LIMit:MLWidth? :CALC:HUWB:LIM:MLW 1ns Example :CALC:HUWB:LIM:MLW? Preset 500ps State Saved 10ns Side Lobe Peak...
Page 519 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Preset 20ppm State Saved 0ppm 500ppm Chip Clock Error Sets the limit for chip clock error pass/fail test. :CALCulate:HUWB:LIMit:CCERror <real> Remote Command :CALCulate:HUWB:LIMit:CCERror? :CALC:HUWB:LIM:CCER 20 Example :CALC:HUWB:LIM:CCER? Preset 20ppm State Saved 0ppm 500ppm...
Page 520 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Preset State Saved 100.0% Data NRMSE (Remote Command Only) Sets the limit for data NRMSE pass/fail test. :CALCulate:HUWB:LIMit:NRMSe:DATA <real> Remote Command :CALCulate:HUWB:LIMit:NRMSe:DATA? :CALC:HUWB:LIM:NRMS:DATA 25 Example :CALC:HUWB:LIM:NRMS:DATA? Preset State Saved 100.0% PHR NRMSE Sets the limit for PHR NRMSE pass/fail test.
Page 521 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Preset State Saved 100.0% 3.4.8.6 Advanced Lets you configure advanced parameters. Phase Noise Optimization Enables you to select the LO (local oscillator) phase noise behavior for various desired operating conditions. For full details, see "Parameter Options, Installed Options &...
Page 522 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Option Description – In instruments without EP0 optimizes phase noise for small frequency offsets from the carrier "Best Wide- Optimizes phase noise for wide frequency offsets from the carrier offset"...
Page 523 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement code compatibility across the family. Parameter 4 selects "Best Close-in" on page 522, which is usually not as good a choice as "Balanced" on page 523. Balanced :FREQ:SYNT 1 In instruments with EP0, the LO is configured for the best possible phase noise at offsets up to 600 kHz from the carrier whenever there are no significant spurs within the span observed with an on-screen carrier.
Page 524 523. It is available with the "Fast Tuning" on page 523 label for convenience, and to make the user interface more consistent with other X-Series instrument family members. (In models whose hardware does not provide for a "Fast Tuning" on page 523...
Page 525 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Models with Option Conditions Selection loop local oscillator, which switches to Source Mode is set to “Tracking” a single loop for fast tuning Center frequency is < 195 kHz, or "Best Close-in"...
Page 526 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement – The RBW to be used in the calculations is the equivalent –3 dB bandwidth of the current RBW filter – The rules apply whether in swept spans, zero span, or FFT spans Ranges Option Option #...
Page 527 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :HUWB:IF:GAIN:AUTO OFF Example :HUWB:IF:GAIN:AUTO? Couplings When either auto attenuation works (for example, with electrical attenuator), or the optimized mechanical attenuator range is requested, the IF Gain setting is changed according to the following rule: Auto sets IF Gain to under any of the following conditions: the input attenuator is set to 0 dB...
Page 528 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement ON|OFF Range Transmit Mask Stitching Period Specifies repeat period of input signal. [:SENSe]:HUWB:TRANsmit:MASK:STITching:PERiod <time> Remote Command [:SENSe]:HUWB:TRANsmit:MASK:STITching:PERiod? :HUWB:TRAN:MASK:STIT:PER 1ms Example :HUWB:TRAN:MASK:STIT:PER? Preset 2.909 ms State Saved 1 usec 100 msec 3.4.9 Recall 3.4.9.1 Signal Configuration Selects a Signal Studio N7610C scp file from which to import the demod settings to...
Page 529 X-Series B-models have a Cont/Single toggle control instead of Single and Cont hardkeys, but it is still true that, if in single measurement, the Cont/Single toggle control never restarts a measurement and...
Page 530 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement reaches the Average/Hold Num, the count stops incrementing, but the instrument keeps sweeping See the Trace key description under Trace Average for the averaging formula used both before and after the Average/Hold Num is reached. The trigger condition must be met prior to each sweep The type of trace processing for multiple sweeps is set under the Trace key, with choices of Trace Average, Max Hold, or Min Hold...
Page 531 (displayed average count reset to 1) for a trace in Clear Write, but did not Notes restart Max Hold and Min Hold In X-Series, the Restart hardkey and the :INIT:REST command restart not only Trace Average, but...
Page 532 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement If the instrument is in the process of aligning when a Restart is executed, the alignment finishes before the restart function is performed. Even when set for Single operation, multiple sweeps may be taken when Restart is pressed (for example, when averaging/holding is on).
Page 533 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Event Trace Effect Min Hold pressed (even if already in Min Hold) Set to maxtracevalue Trace Average pressed (even if already in Trace Trace data unaffected but start new Average) sweep/avg/hold Restart pressed...
Page 534 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Abort (Remote Command Only) Stops the current measurement. Aborts the current measurement as quickly as possible, resets the sweep and trigger systems, and puts the measurement into an "idle" state. If the instrument is in the process of aligning when :ABORt is sent, the alignment finishes before the abort function is performed, so...
Page 535 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement :DISP:HUWB:WIND3:X:WIDT 10e6 Example set the X width of the third window to 10 MHz :DISP:HUWB:WIND3:X:WIDT? query the X width of the third window Couplings "Auto Scaling" on page 536 is ON, the X Width is determined by the trace data Preset Depends on trace data...
Page 536 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Auto Scaling Toggles this function On or Off. :DISPlay:HUWB:WINDow[1]|2|3|4|8:X[:SCALe]:COUPle 0 | 1 | OFF | ON Remote Command :DISPlay:HUWB:WINDow[1]|2|3|4|8:X[:SCALe]:COUPle? :DISP:HUWB:WIND3:X:COUP ON Example do the X auto scale for the third window :DISP:HUWB:WIND3:X:COUP? query the X auto scale state of the third window Couplings...
Page 537 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Sample Rate Displays the sample rate of the saved IQ data file. If you have not saved an IQ data file, the value is 0. Sample Points Displays the total number of sample points in the saved IQ data file. If you have not saved an IQ data file, the value is 0.
Page 538 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement 2101 under the Input/Output menu. This menu includes the following display-only fields: Sample Points Displays the total number of sample points in the recalled IQ data file. If you have not recalled an IQ data file, the value is 0.
Page 539 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Playback Start Once you have loaded an IQ data file using Recall, Recording, this control enables you to specify the start position of the IQ data playback range to be analyzed. If its value is less than zero, an additional zero is inserted at the beginning of the IQ data.
Page 540 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement that until you press Restart, the “invalid data” indicator (yellow asterisk) is displayed in each window. After you press Restart, the invalid data indicator disappears. :CALCulate:<meas>:PLAY:STARt <time> Remote Command :CALCulate:<meas>:PLAY:STARt? Where <meas>...
Page 541 3 Short-Range Comms & IoT Mode 3.4 HRP UWB Demodulation Measurement Sample Rate Displays the sample rate of the recalled IQ data file if the recalled file format contains sampling rate information (.csv, .sdf, .txt). In this case, the control is grayed-out.
Page 542 Programming the Instrument. Note that, in general, :CONF:<Measurement> resets the specified measurement settings to their defaults. X-Series permits the addition of the NDEFault node to the command, which prevents a measurement preset after a measurement switch. The tables below list setup commands for this measurement and queries to retrieve results.
Page 543 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Backwards Compatibility Queries Query Return Value :FETCh:CHPower:CHPower? Returns the Channel Power (dBm) :MEASure:CHPower:CHPower? :READ:CHPower:CHPower? :FETCh:CHPower:DENSity? Returns the Power Spectral Density (dBm/Hz) :MEASure:CHPower:DENSity? :READ:CHPower:DENSity? The results returned by the queries depend on the currently-selected Mode and the value of (where required).
Page 544 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Results Returned Channel Power A floating-point number representing the total channel power in the specified integration bandwidth PSD (Power The power in the specified unit bandwidth. The unit bandwidth is Spectral selected by "PSD Unit"...
Page 545 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement LTE-Advanced FDD/TDD Mode Measurement Results Results Returned 1 or not Returns scalar results: specified Channel Power A floating-point number representing the total channel power in the specified integration bandwidth PSD (Power The power in the specified unit bandwidth.
Page 546 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement 5G NR Mode Measurement Results Results Returned 1 or not Returns scalar results: specified Channel Power A floating-point number representing the total channel power in the specified integration bandwidth PSD (Power The power in the specified unit bandwidth.
Page 547 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement WLAN Channel Power Measurement Results Results Returned 1 or not Returns scalar results: specified When the radio standard is not 802.11ac 80 + 80 MHz or 802.11ax 80 + 80 MHz: Channel Power A floating-point number representing the total channel power in the specified integration bandwidth Peak PSD (Power Spectral Density)
Page 548 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Results Returned Returns floating point numbers that are the captured trace data of the power (in dBm/resolution BW) of the signal for Trace 2. The frequency span of the captured trace data is specified by Span Returns floating point numbers that are the captured trace data of the power (in dBm/resolution BW) of the signal for Trace 3.
Page 549 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement 3.5.1.2 Carrier Info Windows: "Graph" on page 549, "Metrics" on page 550 Dual window view: Channel Power graph and Carrier Info table. :DISP:CHP:VIEW CINF Example Dependencies Only available in MSR, LTE-A FDD/TDD and 5G NR Modes 3.5.2 Windows This section describes the windows that are available in the Channel Power measurement:...
Page 550 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Spectrum View with Bar Graph On This is the same as the Spectrum view, but has a blue bar between the markers that indicates the measured output power level. The bar graph is activated when the “Bar Graph”...
Page 551 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Measure Trace See: "Measure Trace" on page 1508. Power Results Total carrier power, total PSD and total format carrier power are displayed in the lower window. Total format carrier power is total power of carriers of the same Radio Format.
Page 552 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Integ Bw) multiplied by the number of carriers with carrier measure state setting to yes. RF-BW Displays the total bandwidth from the lowest carrier to the highest carrier, whether their measurement states are on or off. Carrier Power This is the power in all the currently defined carriers.
Page 553 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement This is the total power of all the carriers with carrier measure state setting to On. The power is calculated by integrating across the bandwidth declared by the Carrier Integ Bw parameter for each carrier and then totaling the sums. The total integration bandwidth is shown as part of the result.
Page 554 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Parameter Set Displays which format parameter set is selected. 3.5.2.3 Gate Window #3 Turning on Gate View displays the Gate Window, which allows you to see your gating signal at the same time as the measured data. See the description under "Gate View On/Off"...
Page 555 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :DISPlay:CHPower:WINDow[1]:TRACe:Y[:SCALe]:RLEVel <real> Remote Command :DISPlay:CHPower:WINDow[1]:TRACe:Y[:SCALe]:RLEVel? :DISP:CHP:WIND:TRAC:Y:RLEV 10 dBm Example :DISP:CHP:WIND:TRAC:Y:RLEV? Couplings When "Auto Scaling" on page 556 (default), this value is automatically determined by the measurement result. When you set a value manually, Auto Scaling changes to Attenuation is not coupled to Ref Value Preset 10.00 dBm...
Page 556 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Scale Range Sets the Y-Axis scale range. Remote Command Replace <meas> with the identifier for the current measurement :DISPlay:<meas>:WINDow[1]:TRACe:Y[:SCALe]:RANGe <rel_ampl> :DISPlay:<meas>:WINDow[1]:TRACe:Y[:SCALe]:RANGe? :DISP:CHP:WIND:TRAC:Y:RANG 100 Example :DISP:CHP:WIND:TRAC:Y:RANG? Couplings Coupled to Scale/Div as follows Scale Range = Scale/Div * 10 (number of divisions) When you change this value, Auto Scaling automatically changes to Preset...
Page 557 Controls the attenuator functions and interactions between the attenuation system components. There are two attenuator configurations in the X-Series. One is a Dual-Attenuator configuration consisting of a mechanical attenuator and an optional electronic attenuator. The other configuration uses a single attenuator with combined mechanical and electronic sections that controls all the attenuation functions.
Page 558 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Dual-Attenuator Configurations Configuration 1: Mechanical attenuator + optional electronic attenuator Configuration 2: Mechanical attenuator, no optional electronic attenuator Note that Configuration 2 is not strictly speaking a dual-section attenuator, since there is no electronic section available. However, it behaves exactly like Configuration 1 without the Electronic Attenuator Option EA3, therefore for the sake of this document it is grouped into the “Dual-Attenuator”...
Page 559 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement (Note that depending on the measurement, there may be no Auto/Man functionality on the Mech Atten control.) In the Single-Attenuator configuration, you control the attenuation with a single control, as the fixed stage has only two states. In the Dual-Attenuator configuration, both stages have significant range, so you are given separate control of the mechanical and electronic attenuator stages.
Page 560 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement On the Meas Bar, the field “Atten” displays as follows: – If the sweep is entirely < 50 GHz, the value shown after “Atten:” is equal to Mech Atten + Elec Atten + Full Range Atten –...
Page 561 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Auto/Man is remembered and restored when the electronic attenuator is once again disabled. This is described in more detail in "Elec Atten" on page 1641 "Attenuator Configurations and Auto/Man" on page 562 for more information on the Auto/Man functionality Couplings...
Page 562 As described under "Attenuation" on page 1636, there are two distinct attenuator configurations available in the X-Series, the Single Attenuator and Dual-Attenuator configurations. In Dual-Attenuator configurations, we have mechanical attenuation and electronic attenuation, and current total attenuation is the sum of electronic + mechanical attenuation.
Page 563 However, in the Single-Attenuator configuration, EATT SCPI commands are accepted for compatibility with other X-series instruments, and set a “soft” attenuation. The “soft” attenuation is treated as an addition to the “main” attenuation value set by the Attenuation control or :POW:ATT, and affects the total attenuation displayed on the Attenuation Short Range Comms &...
Page 564 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement control and the Meas Bar The electronic attenuator, and the “soft” attenuation function provided in Single-Attenuator config- urations, are unavailable above the low band (0-3.6 GHz, 0-3.4 GHz, 0-3 GHz, depending on the model).
Page 565 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :POW:EATT:STAT? Preset (Disabled) for Swept SA measurement (Enabled) for all other measurements that support the electronic attenuator The maximum Center Frequency for Low Band can change based on the NOTE selected IFBW for measurements that support IFBW (for example, Waveform measurement across all Modes that support it).
Page 566 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement – The Electronic Attenuator is set to 10 dB less than the previous value of the Mechanical Attenuator, within the limitation that it must stay within the range of 0 to 24 dB of attenuation Examples in the Dual-Attenuator configuration: –...
Page 567 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement electrical attenuator. With the mechanical attenuator, TOI, SHI, and compression threshold levels increase dB-for-dB with increasing attenuation, and the noise floor does as well. With the electronic attenuator, there is an excess attenuation of about 1 to 3 dB between 0 and 3.6 GHz, making the effective TOI, SHI, and so forth, less well known.
Page 568 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Pre-Adjust for Min Clipping If this function is ON, it applies the adjustment described under "Adjust Atten for Min Clipping" on page 1645 each time a measurement restarts. Therefore, in Continuous measurement mode, it only executes before the first measurement.
Page 569 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Range Dual-Attenuator models: Off | Elec Atten Only | Mech + Elec Atten Single-Attenuator models: Off | On Backwards Compatibility Command Notes aliases to "Elec Atten Only" (:POW:RANG:OPT:ATT ELEC) aliases to "Off" (:POW:RANG:OPT:ATT OFF) :POW:RANG:AUTO?
Page 570 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Single-Attenuator Models Dual-Attenuator models "Adjust Atten for Min Clipping" on page 1645 "Pre-Adjust for Min Clipping" on page 568 selection is Mech + Elec Atten: Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 571 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 572 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement "Pre-Adjust for Min Clipping" on page 568 selection is Elec Only. Note that the Mech Atten value is not adjusted, and the value previously set is used. Therefore, there is a case that IF Overload is still observed depending on the input signal level and the Mech Atten setting.
Page 573 All other models: 2 dB State Saved Saved in instrument state 3.5.3.3 Range (Non-attenuator models) Only available for Keysight’s modular signal analyzers and certain other Keysight products, such as VXT and M941xE. State Saved Range Represents the amplitude of the largest sinusoidal signal that could be present within the IF without being clipped by the ADC.
Page 574 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Adjust Range for Min Clipping Sets the combination of attenuation and gain based on the current measured signal level so that clipping will be at a minimum. This is an "immediate action" function, that is, it executes once, when the key is pressed.
Page 575 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Peak-to-Average Ratio Used with "Range (Non-attenuator models)" on page 1651 to optimize the level control in the instrument. The value is the ratio, in dB, of the peak power to the average power of the signal to be measured.
Page 576 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Mixer Lvl Offset This is an advanced setting to adjust target Range at the input mixer, which in turn affects the signal level in the instrument’s IF. This setting can be used when additional optimization is needed after setting "Peak-to-Average Ratio"...
Page 577 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement between Start Freq and Stop Freq, the instrument first performs a peak search, and then performs centering on the marker’s center frequency. The value displayed on "Preselector Adjust" on page 1656 changes to reflect the new preselector tuning.
Page 578 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement search to find 2. If the selected marker is already On, the instrument attempts the centering at that marker’s frequency. There is no preselector for signals below about 3.6 GHz, so if the marker is on a signal below 3.6 GHz, no centering is attempted, and an advisory message is generated 3.
Page 579 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement State Saved The Preselector Adjust value set by "Presel Center" on page 1654, or by manually adjusting Preselector Adjust Not saved in instrument state, and does not survive a Preset or power cycle Min/Max –/+500 MHz [:SENSe]:POWer[:RF]:MW:PADJust...
Page 580 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement The maximum Center Frequency for Low Band, displayed in square brackets, NOTE can change based on the selected IFBW for measurements that support IFBW (for example, Waveform measurement across all Modes that support it). In certain models (such as N9042B &...
Page 581 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement LNA is an additional preamplifier that provides superior DANL and frequency range compared to "Internal Preamp" on page 1657. LNA provides lower system noise figure, especially at frequencies above 100 MHz, and can be operated up to the full range of 50 GHz instruments.
Page 582 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement µW Path Control Options for this control include µW Preselector Bypass (Option MPB), Low Noise Path (Option LNP) and Full Bypass Enable in the High Band path circuits. When the µW Preselector is bypassed, flatness is improved, but will be subject to spurs from out of band interfering signals.
Page 583 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement [:SENSe]:POWer[:RF]:MW:PATH STD | LNPath | MPBypass | FULL Remote Command [:SENSe]:POWer[:RF]:MW:PATH? :POW:MW:PATH LNP Example Enables the Low Noise path :POW:MW:PATH? Notes When "Presel Center" on page 1654 is performed, the instrument momentarily switches to the Standard Path, regardless of the setting of µW Path Control The DC Block will always be switched in when the low noise path is switched in, to protect succeeding circuitry from DC.
Page 584 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Annotation In the Meas Bar, if the Standard path is chosen: µW Path: Standard If Low Noise Path is enabled but the LNP switch is not thrown: µW Path: LNP,Off If the Low Noise Path is enabled and the LNP switch is thrown: µW Path: LNP,On If the preselector is bypassed:...
Page 585 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Measurement µW Path Control Auto behavior Always Presel Bypass Always Presel Bypass Spurious Always Standard Path Emissions WLAN Mode Measurement µW Path Control Auto behavior Modulation Always Presel Bypass Analysis Spectral Flatness Always Presel Bypasss Power vs Time...
Page 586 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Measurement µW Path Control Auto behavior Emissions Transmit On|Off Use Standard Path unless tuned frequency > 3.6 GHz and Info BW > 15 MHz, in Power which case choose Preselector Bypass Channel Quality Mode Measurement µW Path Control Auto behavior Group Delay...
Page 587 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement whether or not the Low Noise Path Enable is selected in the user interface. The only time the Low Noise Path is used is when Low Noise Path Enable is selected, the sweep is completely in High Band (>...
Page 588 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement There are other times where selecting the low noise path improves performance, too. Compression-limited measurements such as finding the nulls in a pulsed-RF spectrum can profit from the low noise path in a way similar to the TOI-limited measurement illustrated.
Page 589 3.5 Channel Power Measurement Option MPB or pre-selector bypass provides an unpreselected input mixer path for certain X-Series signal analyzers with frequency ranges above 3.6 GHz. This signal path allows a wider bandwidth and less amplitude variability, which is an advantage when doing modulation analysis and broadband signal analysis.
Page 590 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement whenever Full Bypass Enable is selected, a warning message appears in the status bar: “Full Bypass Enabled, maximum safe input power reduced” Microwave Preselector Bypass Backwards Compatibility Example Bypass the microwave preselector: :POW:MW:PRES OFF Notes Included for Microwave Preselector Bypass backwards compatibility...
Page 591 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Settings Alert message in the error queue Software Preselection Provided in some instruments, either to compensate for issues with provided hardware preselection or to provide the preselection function when there is no hardware preselector.
Page 592 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Note that for N9042B+V3050A, in the Swept SA measurement, Software Preselection works even if the measurement is using an FFT Sweep Type. In measurements other than Swept SA, Software Preselection is not used if the measurement is using an FFT Sweep Type.
Page 593 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Two hidden sweeps occur in succession. The second sweep is offset in LO frequency by 2 * IF / N. For each point in each trace, the smaller amplitude from the two traces is taken and placed in that point in the selected trace.
Page 594 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement wideband signals with occupied bandwidths up to 2 GHz. This increases the risk of images failing to be rejected, but improves the measurement speed [:SENSe]:POWer[:RF]:SWPResel:BW NORMal | NARRow Remote Command [:SENSe]:POWer[:RF]:SWPResel:BW? :POW:SWPR:BW NARR Example Dependencies...
Page 595 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement State Saved Saved in instrument state Prefilter Presets Meas Mode Preset SPEC BASIC BASIC, WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA WCDMA WCDMA PCON WCDMA EVMQ WCDMA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA...
Page 596 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Res BW Activates the resolution bandwidth active function, which allows you to manually set the resolution bandwidth (RBW) of the instrument. Normally, Res BW (Auto) selects automatic coupling of Res BW to "Span"...
Page 597 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement [:SENSe]:CHPower:BANDwidth[:RESolution]:AUTO? Command :CHP:BAND:AUTO ON Example :CHP:BAND:AUTO? RBW Presets Mode Preset Value LTEAFDD Auto LTEATDD Auto 100 kHz NR5G Auto Auto SRCOMMS 3.9 kHz 240 kHz WCDMA 240 kHz WLAN 100 kHz More Information When Res BW is set to Auto, the bandwidth selected depends on "RBW Filter Type"...
Page 598 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Bandwidth Auto RBW, kHz 5 MHz 10 MHz 15 MHz 20 MHz 25 MHz 30 MHz 35 MHz 40 MHz 45 MHz 50 MHz 60 MHz 70 MHz 1000 80 MHz 1100 90 MHz 1300...
Page 599 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :CHP:BAND:VID? Notes For numeric entries, the instrument chooses the nearest (arithmetically, on a linear scale, rounding up) available VBW to the value entered. The 50 MHz VBW is defined to mean “wide open” The values shown in this table reflect the conditions after a Mode Preset Dependencies Sometimes the displayed Video BW is not actually used to process the trace data:...
Page 600 –3 dB bandwidth of the filter. That is, a 10 MHz Res BW filter was a Gaussian shape with its –3 dB points 10 MHz apart. In X-Series, the RBW Filter BW menu lets you choose between a Gaussian and Flat Top filter shape, for varying measurement conditions.
Page 601 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement 3.5.5 Display Lets you configure display items for the current Mode, Measurement View or Window. 3.5.5.1 Meas Display Contains controls for setting up the display for the current Measurement, View or Window.
Page 602 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Preset State Saved Saved in instrument state :DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe] OFF | ON | 0 | 1 Backwards Compatibility :DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe]? SCPI This command is accepted for backwards compatibility with older instruments, but the WINDow, TRACe GRID parameters are ignored...
Page 603 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :DISP:ANN:TRAC OFF Example Preset State Saved Saved in instrument state Control Annotation Turns on and off the display of values on the Active Function controls for all measurements in the current Mode. This is a security feature. :DISPlay:ACTivefunc[:STATe] ON | OFF | 1 | 0 Remote Command :DISPlay:ACTivefunc[:STATe]?
Page 604 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement 2. To reduce emissions from the display, drive circuitry 3. For security purposes If you have turned off the display: – and you are in local operation, the display can be turned back on by pressing any key or by sending :SYSTem:DEFaults MISC :DISPlay:ENABle ON...
Page 605 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Backwards :SYST:PRES no longer turns on :DISPlay:ENABle as it did in legacy analyzers Compatibility Notes 3.5.5.3 View Contains controls for selecting the current View, and for editing User Views. View "Views"...
Page 606 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Restore Layout to Default Restores the Layout to the default for Basic. Modified Views are very temporary; if you exit the current measurement they are discarded, and they are not saved in State. To retain this View for later use, and to be able to return easily to your original Basic View, you can save your edited View as a “User View”.
Page 607 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :DISP:VIEW:ADV:REN “Baseband” Example <alphanumeric> Notes is case insensitive; you can specify mixed case, however the name will be evaluated on a single case If the <alphanumeric> specifying the new name is already present in the list of View names, the error message “-224, Illegal parameter value;...
Page 608 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement nodes, :DISPlay:VIEW[:SELect] and :DISPlay:VIEW:NSEL, are retained for backwards compatibility, but they only support predefined views. View Listing Query Returns a string containing a comma-separated list of names for all the Views, including User Views, available for the current Measurement.
Page 609 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement For example, Center Frequency is the same for all measurements — it does not change as you change measurements. 3.5.6.1 Settings Contains controls that pertain to the X axis parameters of the measurement. These parameters control how data on the vertical (X) axis is displayed and control instrument settings that affect the horizontal axis.
Page 610 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Increment the Center Frequency by the value of CF Step: :FREQ:CENT UP Return the current value of Center Frequency: :FREQ:CENT? Notes Sets the RF, External Mixing or I/Q Center Frequency depending on the selected input: –...
Page 611 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Freq Option CF after Mode Stop Freq after Mode Max Freq (can't tune Preset Preset above) 526 (except CXA and 13.255 GHz 26.5 GHz 27.0 GHz* MXE) 526 (CXA) 13.255 GHz 26.5 GHz 26.55 GHz 526 (MXE)
Page 612 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Tracking Min Freq If above this Freq, Stop Freq Max Freq (clips to this freq when turn (can't tune Generator clipped to this Freq when TG TG on and can’t tune below above) Option turned on...
Page 613 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement If the equivalent SCPI command is sent, this same message is generated as part of a “-221, Settings conflict” warning Preset See table above State Saved Saved in instrument state -79.999995 MHz 26.999999995 GHz "Center Frequency Presets"...
Page 614 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement The minimum frequency in the currently selected mixer band + 5 Hz If the knob or step keys are being used, also depends on Span The maximum frequency in the currently selected mixer band – 5 Hz If the knob or step keys are being used, also depends on Span I/Q Center Freq Sets the Center Frequency to use when the I/Q input is selected, even if the I/Q...
Page 615 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :CHP:FREQ:SPAN? Dependencies If the electrical attenuator is enabled, any attempt to set Span such that the Stop Frequency would be >3.6 GHz results in an error In instruments with an RF Preselector, such as MXE, you cannot sweep across the band break at 3.6 GHz while the RF Preselector is on in Continuous sweep, as there is a mechanical switch which bypasses the RF Preselector above 3.6 GHz.
Page 616 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement [:SENSe]:CHPower:FREQuency:SPAN:AUTO ON | OFF | 1 | 0 Remote Command [:SENSe]:CHPower:FREQuency:SPAN:AUTO? :CHP:FREQ:SPAN:AUTO OFF Example :CHP:FREQ:SPAN:AUTO? Notes The span value is adjusted when the relevant carrier parameters such as bandwidth, integration bandwidth, number of component carriers etc., are changed, whatever the span state (Auto or Man) When in Man state, if the input value is less than the required sum of total integration bandwidths and gaps of the multi-carriers, the required span value is set...
Page 617 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Freq Option Max Span (can't set higher than this) 5.75 GHz (VXT models M9410A/11A) F06 & EP6 6.27 GHz (VXT models M9410A/11A) F06 & LFE & EP6 6.5999935 GHz (VXT models M9411A) M9415A-F06 6.27 GHz M9415A-F08...
Page 618 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement CF Step Changes the step size for Center Frequency and start and stop frequency functions. Once a step size has been selected and the center frequency function is active, the step keys (and the UP|DOWN parameters for Center Frequency from remote...
Page 619 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement [:SENSe]:CHPower:FREQuency:SPAN:FULL Remote Command :CHP:FREQ:SPAN:FULL Example Couplings Selecting full span changes the measurement span value 3.5.7 Marker Accesses a menu that enables you to select, set up and control the markers for the current measurement.
Page 620 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement control mode is Normal or Delta. :CALCulate:CHPower:MARKer[1]|2|…|12:X <freq> Remote Command :CALCulate:CHPower:MARKer[1]|2|…|12:X? :CALC:CHP:MARK3:X 0 Example :CALC:CHP:MARK3:X? Notes If no suffix is sent, uses the fundamental units for the current marker X Axis Scale. If a suffix is sent that does not match the current marker X Axis Scale unit, an error “Invalid suffix”...
Page 621 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :CALCulate:CHPower:MARKer[1]|2|…|12:Y? Remote Command :CALC:CHP:MARK11:Y? Example Notes Returns the marker Y-Axis result if the control mode is Normal or Delta If the marker is Off, then the response is Not A Number Preset Result dependent on Markers setup and signal source State Saved...
Page 622 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :CALC:CHP:MARK3:STAT ON Example :CALC:CHP:MARK3:STAT? Preset State Saved Saved in instrument state OFF|ON Range :CALCulate:CHPower:MARKer[1]|2|…|12:STATe OFF | ON | 0 | 1 Backwards Compatibility :CALCulate:CHPower:MARKer[1]|2|…|12:STATe? SCPI Delta Marker (Reset Delta) This control has the same effect as pressing Delta in "Marker Mode"...
Page 623 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Marker Frequency This is the fundamental control that you use to move a marker around on the trace. It is the same as "Marker Frequency" on page 619 in the Settings tab. Peak Search Moves the selected marker to the trace point that has the maximum Y-Axis value for that marker’s trace.
Page 624 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Marker Frequency This is the fundamental control that you use to move a marker around on the trace. It is the same as "Marker Frequency" on page 619 in the Settings tab. Relative To Selects the marker to which the selected marker is relative (its reference marker).
Page 625 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Specifying a Marker Trace manually or with this command associates the marker with the specified trace. If the marker is not Off, it moves the marker from the trace it was on to the new trace.
Page 626 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement [:SENSe]:CHPower:AVERage:COUNt? Command :CHP:AVER:COUN 15 Example :CHP:AVER:COUN? Preset SA, WLAN: 10 WCDMA, LTEAFDD, LTEATDD, 5G NR, MSR: 200 State Saved Saved in instrument state Min/Max 1 / 10000 Annotation The average count is displayed in the measurement bar on the front panel display. The annotation appears in the format where is the current average and...
Page 627 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :CHP:AVER:TCON EXP Example :CHP:AVER:TCON? Preset State Saved EXPonential|REPeat Range Integ BW Specifies the range of integration used in calculating the power in the channel. The integration bandwidth (IBW) is displayed on the trace as two markers connected by an arrow.
Page 628 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement PSD Unit Sets the unit bandwidth for Power Spectral Density. The available units are dBm/Hz (DBMHZ) and dBm/MHz (DBMMHZ). :UNIT:CHPower:POWer:PSD DBMHZ | DBMMHZ Remote Command :UNIT:CHPower:POWer:PSD? :UNIT:CHP:POW:PSD DBMMHZ Example :UNIT:CHP:POW:PSD? Couplings When the PSD unit is changed, the response to :MEAS|READ|FETCH:CHP1?
Page 629 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :CHP:IF:GAIN:AUTO ON Example :CHP:IF:GAIN:AUTO? Couplings Auto sets IF Gain to High Gain if the input attenuator is set to 0 dB, or if the preamp is turned on and the frequency range is under 3.6 GHz For other conditions, Auto sets IF Gain to Low Gain Preset...
Page 630 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Auto Couple Immediately puts all Auto/Man functions into Auto. Auto Couple is confined to the current measurement only. It does not affect other measurements in the Mode. In the Auto state, Auto/Man functions are said to be “coupled”, meaning their values change as you make changes to other values in the measurement.
Page 631 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Executing Auto Coupledoes not affect markers, marker functions, trace or display attributes, or any other instrument setting other than those specifically mentioned above. Measurement-Specific Details TOI (SA Mode only) Parameters affected by Auto Couple are: –...
Page 632 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement 3.5.8.2 Meas Method Allows you to choose between Integration Bandwidth and RRC Weighted methods of making the measurement, and to set certain other relevant parameters. In MSR, LTE-A FDD/TDD and 5G NR Modes, this feature is not supported. Meas Method Selects either the Integration BW (OFF) or RRC Weighted (ON) methods.
Page 633 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement RRC Filter BW Sets the Root Raised Cosine (RRC) filter bandwidth. Normally, the filter bandwidth is the same as the symbol rate of the signal. [:SENSe]:CHPower:FILTer[:RRC]:BANDwidth <real> Remote Command [:SENSe]:CHPower:FILTer[:RRC]:BANDwidth? :CHP:FILT:BAND 10MHz Example :CHP:FILT:BAND?
Page 634 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement ZigBee (IEEE 802.15.4) It’s defined in IEEE 802.15.4 standard Z-Wave (ITU-T G.9959) It’s defined in ITU-T G.9959 standard LoRa A proprietary modulation schemes owned by Semtech HRP UWB It’s defined in IEEE 802.15.4 standard All three choices are enabled for all measurements although it is not necessarily the case that each measurement supports all three standards.
Page 635 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Preset to Std This group of controls lets you easily set up the analyzer for ZigBee (IEEE 802.15.4), Z-Wave (ITU-T G.9959) , LoRa CSS or HRP UWB measurements. [:SENSe]:RADio:STANdard:PRESet ZIGBEE2450 | ZIGBEE915 | ZIGBEE868 | Remote Command ZBOQPSK780 | ZBOQPSK915 | ZBOQPSK868 | ZWAVER1 | ZWAVER2 | ZWAVER3 | LORA7K | LORA10K | LORA15K | LORA20K | LORA31K | LORA41K | LORA62K | LORA125K |...
Page 636 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement 3.5.8.4 Limits Lets you set up the test limit for channel power or power spectral density. When DVB-T radio standard is selected in SA Mode, this functionality is disabled, and the input signal is instead compared against a pre-defined spectrum mask. In LTE-A FDD/TDD and 5G NR Modes, this feature is not supported.
Page 637 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement exceeds Power Limit, the channel power test fails, otherwise, it passes. If Power Limit state is OFF, the channel power test always passes. :CALCulate:CHPower:LIMit:POWer <ampl> Remote Command :CALCulate:CHPower:LIMit:POWer? :CALC:CHP:LIM:POW 16.00 Example :CALC:CHP:LIM:POW? Notes...
Page 638 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement If PSD Limit state is ON, PSD Limit is a threshold to determine whether the real measured PSD will pass or not. If real measured PSD exceeds PSD Limit, the test fails, otherwise, it passes.
Page 639 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Power Limit Fail (Remote Query Only) Queries whether a power test passes or fails. When DVB-T radio standard is selected in SA Mode, the result of this query has no meaning. While implementing the scpi, don’t try to remove the SCPI command from the SCPI tree when DVB-T is selected as current radio standard.
Page 640 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement For full details, see "Parameter Options, Installed Options & Ranges" on page 640 below. [:SENSe]:CHPower:FREQuency:SYNThesis[:STATe] 1 | … | 5 Remote Command For the meaning of each numeric option value, see "Parameter Options, Installed Options &...
Page 641 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Option Description – In instruments with EP0, emphasizes close-in phase noise "Best Close-in" 4 or 1* on page 641 performance without regard to spur avoidance – In instruments without EP0, this setting is accepted but no action is taken –...
Page 642 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement the span observed with an on-screen carrier. When there will be such a spur, the LO is reconfigured in a way that allows the phase noise to increase by 7 dB mostly within ±1 octave around 400 kHz offset.
Page 643 642. It is available with the "Fast Tuning" on page 642 label for convenience, and to make the user interface more consistent with other X-Series instrument family members. (In models whose hardware does not provide for a "Fast Tuning" on page 642 option, the settings for "Best Close-in"...
Page 644 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Models with Option Conditions Selection CF < 130 kHz , or "Best Close-in" on page 641 Models with option EP2 use a different CF > 12 MHz and Span < 495 kHz and loop bandwidth for the fast-tuning RBW <...
Page 645 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Ranges Option Option # Phase Noise Option Range No EPx Option Best Close-in [offset < 20 kHz] Best Wide-offset [offset > 30 kHz] Fast Tuning [same as Best Close-In] Best Close-in [offset <...
Page 646 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Adaptive NFE (in Modes which support it) is recommended for general-purpose use. For fully ATE (automatic test equipment) applications, where the distraction of a person using the instrument is not a risk, Full NFE is recommended. NFE works with any RBW, VBW, detector, any setting of Average Type, any amount of trace averaging, and any signal type.
Page 647 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement the SCPI command will be accepted without error but has no effect Couplings When NFE is enabled in any mode manually, a prompt will be displayed reminding you to perform the Characterize Noise Floor operation if it is needed.
Page 648 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement In other cases, operation is often not quite as good but still highly effective. With peak detection, the noise floor is estimated based on the RBW and the duration of the bucket using the same equations used in the noise marker function.
Page 649 3.5 Channel Power Measurement On instruments with the NF2 license installed, the calibrated Noise Floor used by Noise Floor Extensions should be refreshed periodically. Keysight recommends that the Characterize Noise Floor operation be performed after the first 500 hours of operation, and once every calendar year. The control to perform this is located in the System, Alignments, Advanced menu.
Page 650 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement This function resets to when "Restore Defaults" on page 1719 is pressed, or when System, Restore Defaults, All Modes is pressed. :INSTrument:COUPle:FREQuency:CENTer ALL | NONE Remote Command :INSTrument:COUPle:FREQuency:CENTer? :INST:COUP:FREQ:CENT ALL Example :INST:COUP:FREQ:CENT? Preset...
Page 651 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :INSTrument:COUPle:DEFault Remote Command :INST:COUP:DEF Example :GLOBal:DEFault Backwards Compatibility SCPI 3.5.9 Sweep Accesses controls to configure and control the acquisition of data, and the X-axis parameters of the instrument. Depending on the selected mode and measurement, these controls might include: Sweep Time, Continuous/Single, Pause/Resume, X Scale and Number of Points.
Page 652 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement and/or VBW. On non-sweeping hardware, this control is grayed-out. The value shown on this NOTE control is an estimate. It is the measurement’s turnaround time, which is the sum of signal acquisition time, FFT time, and other overhead time, to complete the entire span of the measurement.
Page 653 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Non-sweeping hardware: N/A Annotation The sweep time is displayed in the lower-right corner of the screen. The number of points is displayed parenthetically, as: Sweep 13.3 ms (1001 points) A “#” mark appears before “Sweep” in the annotation when it is switched from Auto to Manual coupling Status Bits/OPC Meas Uncal is Bit 0 in the register:...
Page 654 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement <meas> is the identifier for the current measurement; any one of CHPower- |ACPower|OBWidth|MONitor Example Channel Power measurement :CHP:SWE:ACQ:TIME 500 ms :CHP:SWE:ACQ:TIME? Dependencies Available only on non-sweeping hardware Couplings Coupled to Span, RBW, and VBW when in the Auto state When you manually set a value when in the Auto state, the state automatically changes to Man Preset Automatically calculated...
Page 655 X-Series B-models have a Cont/Single toggle control instead of Single and Cont hardkeys, but it is still true that, if in single measurement, the Cont/Single toggle control never restarts a measurement and...
Page 656 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement If the instrument is already in Single sweep, :INIT:CONT OFF has no effect. If the instrument is already in Single sweep, then pressing Cont/Single in the middle of a sweep does not restart the sweep or sequence. Similarly, pressing Cont/Single does not restart the sweep or sequence if the sweep is not in the idle state (for example, if you are taking a very slow sweep, or the instrument is waiting for a trigger).
Page 657 (displayed average count reset to 1) for a trace in Clear Write, but did not Notes restart Max Hold and Min Hold :INIT:REST In X-Series, the Restart hardkey and the command restart not only Trace Average, but MaxHold and MinHold traces as well More Information The Restart function first aborts the current sweep or measurement as quickly as possible.
Page 658 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Trace Update The numeric results are not blanked at any time during the restart cycle. For slow sweeps (see Trace Update section in Trace/Detector), the traces are updated real-time during the sweep. There may be a special circumstance in application mode measurements where an exception is made and the traces and/or results need to be blanked before displaying the new results.
Page 659 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Pause/Resume Pauses a measurement after the current data acquisition is complete. When paused, the label on the control changes to Resume. Pressing Resume un- pauses the measurement. When paused, pressing Restart performs a Resume. :INITiate:PAUSe Remote Command :INITiate:RESume...
Page 660 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Sweep Time Annotation (Remote Query Only) Returns the Sweep Time Annotation value. Available only on non-sweeping hardware. This value is also displayed in the result trace window. The value returned is the estimated turnaround time of each measurement cycle, in seconds.
Page 661 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Dependencies Does not appear in Spectrum Analyzer Mode in VXT model M9421A NORMal Preset State Saved Saved in instrument state NORMal|ACCuracy Range Points Sets the number of points taken per sweep, and displayed in the traces. The current value of Points is displayed parenthetically, next to the sweep time in the lower-right corner of the display.
Page 662 IF Dithering Lets you turn IF Dithering on or off. This is a technique used in unpreselected instruments (such as Keysight’s modular instruments) to enhance the rejection of images and internally-generated spurious signals. [:SENSe]:SWEep:IF:DITHer OFF | ON | 0 | 1...
Page 663 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement 3.5.10 Trace Lets you control the acquisition, display, storage, detection and manipulation of trace data for the available traces. The Trace Control tab of this menu contains radio-button selections for the trace type (Clear/Write, Trace Average, Max Hold, Min Hold) and View/Blank setting for the selected trace.
Page 664 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Each trace also has two values that determine whether it is being written or not, and whether it is being displayed or not. These values, Update and Display, are described fully in the "View/Blank"...
Page 665 View and Blank. Averaging was global to all traces and was controlled under the BW/Avg menu. In X-Series, trace averaging can be done on a per-trace basis. The Trace Modes (now called Trace Types) are Clear/Write, Trace Average, Max Hold and Min Hold.
Page 666 [:STATe] ON|OFF|1|0 was used to turn Averaging on or off In X-Series, Averaging is turned on or off on a per-trace basis, so it can be on for one trace and off for another For backwards compatibility, the old global Average State variable is retained solely as a legacy...
Page 667 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement variable, turned on and off and queried by the legacy command [:SENSe]:AVERage[:STATe] OFF|ON|0|1. When Average is turned on, any trace in Clear/Write will get put into Average. While Average is on, any trace put into Clear/Write by the old :TRAC:MODE command will instead get put into Average.
Page 668 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement – The average/hold count k is set to 1, so that the next time the average trace is displayed it simply represents one trace of new data – A new sweep is initiated –...
Page 669 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement When in Min Hold, if a measurement-related instrument setting is changed(that is, one which requires new data to be taken, like Center Frequency or Attenuation), the Min Hold sequence restarts and a new sweep is initiated but the trace is not cleared. Restarting the Min Hold sequence means: –...
Page 670 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement annotation panel in the Measurement Bar. In the example below, Traces 3, 4, 5 and 6 have UpdateOFF, and Traces 4 and 6 have DisplayOFF. See: "More Information" on page 671 Notes For the commands to control the two variables, Update and Display, see "Trace Update State On/Off"...
Page 671 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Trace Display State On/Off Remote For Swept SA Measurement (in SA Mode): Command :TRACe[1]|2|…|6:DISPlay[:STATe] ON | OFF | 1 | 0 :TRACe[1]|2|…|6:DISPlay[:STATe]? For all other measurements: :TRACe[1]|2|3:<meas>:DISPlay[:STATe] ON | OFF | 1 | 0 :TRACe[1]|2|3:<meas>:DISPlay[:STATe]? where <meas>...
Page 672 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement horizontal placement does not change, even if X-Axis settings subsequently are changed, although Y-Axis settings do affect the vertical placement of data. When a trace becomes active (Update=ON), the trace is cleared, the average count is reset, and a new sweep is initiated.
Page 673 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement :CALC:MATH TRACE3,PSUM,TRACE1,TRACE2,0,0 Sets Trace 3 to Power Sum trace math function and sets the First Trace operand (for Trace 3) to Trace 1 and the Second Trace operand (for Trace 3) to Trace 2 :CALC:MATH TRACE3,LOFF,TRACE1,TRACE2,-6.00,0 Sets Trace 3 to Log Offset trace math function, sets the First Trace operand (for Trace 3) to Trace 1, leaves the Second Trace operand (for Trace 3) unchanged (it is irrelevant for this function) and sets the...
Page 674 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement For all other measurements: OFF,TRACE2,TRACE3,0,0 | OFF,TRACE3,TRACE1,0,0 | OFF,TRACE1,TRACE2,0,0 State Saved The trace math function for each trace is saved in instrument state Annunciation An “f” is shown on the trace annunciation panel in the Measurement Bar when a math function is on; and the function is annotated on the trace if Trace Annotation is on Status Bits/OPC *OPC...
Page 675 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Otherwise, if the result of the subtraction is less than or equal to 0, the resultant point is mintracevalue. Power Sum (Op1 + Op2) Calculates a power sum between the First Trace operand and the Second...
Page 676 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement selected trace. Each destination trace has its own reference. Offsets the difference between the First Trace operand and the Second Trace operand by a reference and puts the result in the destination trace. This is like the A- B+DL function in some older instruments.
Page 677 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement For each active trace, the current trace point is processed for Trace 1, then Trace 2, then Trace 3, etc. Trace data is taken from either the detector for that trace, or Short Range Comms &...
Page 678 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement from the mathematical result of up to two other traces and an offset, depending on whether trace math is on or not. The resultant data is then fed to the Average/Hold processing block, where (if the trace type is Average, Max Hold, or Min Hold) it is processed with previous trace data.
Page 679 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement 5; for Trace 6, it presets to Trace 4 Operand 2: Trace number minus 1 (wraps at 1). For example, for Trace 1, Operand 2 presets to Trace 6; for Trace 6, it presets to Trace 5 State Saved Operands 1 and 2 for each trace are stored in instrument state Offset...
Page 680 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Option Parameter Detector Behavior functions, average type, and the trace averaging function This option is set using "Detector Select Auto/Man" on page 681 NORMal Normal The detector determines the peak of the CW-like signals, and it yields alternating maximums and minimums of noise-like signals.
Page 681 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement – POSitive (peak) with MAXHold – NEGative (peak) with MINHold AVERage Preset State Saved Saved in instrument state NORMal|AVERage|POSitive|SAMPle|NEGative|RMS Range Detector Select Auto/Man Sets the Detector mode to Auto or Manual. In Auto, the proper detector is chosen based on rules that take into account the measurement settings and other instrument settings.
Page 682 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Preset To Trace Selects the trace to be copied from or exchanged with the "From Trace" on page 1506 when a "Copy" on page 1506 "Exchange" on page 1507 is performed Preset Copy Executes a Trace Copy based on the...
Page 683 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement The X-Axis settings and domain of a trace are also copied when it is exchanged with another trace. Remote For Swept SA Measurement (in SA Mode): Command :TRACe:EXCHange TRACE1 | … | TRACE6, TRACE1 | … | TRACE6 For all other measurements: :TRACe:<meas>:EXCHange TRACe1 | TRACe2 | TRACe3, TRACe1 | TRACe2 | TRACe3 <meas>...
Page 684 3 Short-Range Comms & IoT Mode 3.5 Channel Power Measurement Measure Trace Specifies which trace’s scalar results are displayed in the Metrics window, and :READ :FETCh retrieved by sending a query: – Trace 1 – Trace 2 – Trace 3 :CALCulate:<meas>:MTRace TRACe1 | TRACe2 | TRACe3 Remote Command :CALCulate:<meas>:MTRace?
Page 685 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement 3.6 Power Stat CCDF Measurement Many modern digitally-modulated signals look noise-like in the time and frequency domain, requiring statistical measurement of these signals for meaningful characterization and differentiation. The Power Statistics Complementary Cumulative Distribution Function (CCDF) measurement displays curves to characterize the higher-level power statistics of digitally modulated signals.
Page 686 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Programming the Instrument. The following measurement commands and queries are used to configure the measurement: :INITiate:PSTatistic Initiates a trigger cycle for the measurement, but does not return any data. You must then use :FETC:PST[n]? to retrieve data Does not change any measurement settings...
Page 687 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Results Returned Item Unit, if Count Power level that has 0.00001% of the power if "Minimum Probability" on page 691 is PP7 (0.00001 %) This value is returned only when PP7 is selected Returns a series of 5001 floating point numbers (in percent) that represent the current measured power stat trace.
Page 688 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement 3.6.1.1 Normal Windows: "Metrics" on page 689, "Graph" on page 688 The Power Stat CCDF measurement provides CCDF curves and power statistics metrics. This is common for both Uplink (MS) and Downlink (BTS). :PST:SLTV OFF Example 3.6.2 Windows...
Page 689 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement 3.6.2.2 Metrics Displays the textual results of the Power Stat CCDF measurement. Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 690 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement For the list of = 1 measurement results, see "Measurement Results for Power Stat CCDF" on page 686 above. Name Unit Corresponding Results Results Explanation Item for n = Average Average input power 99.99 dBm...
Page 691 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Name Unit Corresponding Results Results Explanation Item for n = 0.0001% Power level that has 0.0001 % 99.99 dB of the power 0.00001% Power level that has 0.00001% 99.99 dB of the power if "Minimum Probability"...
Page 692 Controls the attenuator functions and interactions between the attenuation system components. There are two attenuator configurations in the X-Series. One is a Dual-Attenuator configuration consisting of a mechanical attenuator and an optional electronic attenuator. The other configuration uses a single attenuator with combined mechanical and electronic sections that controls all the attenuation functions.
Page 693 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Configuration 2: Mechanical attenuator, no optional electronic attenuator Note that Configuration 2 is not strictly speaking a dual-section attenuator, since there is no electronic section available. However, it behaves exactly like Configuration 1 without the Electronic Attenuator Option EA3, therefore for the sake of this document it is grouped into the “Dual-Attenuator”...
Page 694 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement (Note that depending on the measurement, there may be no Auto/Man functionality on the Mech Atten control.) In the Single-Attenuator configuration, you control the attenuation with a single control, as the fixed stage has only two states. In the Dual-Attenuator configuration, both stages have significant range, so you are given separate control of the mechanical and electronic attenuator stages.
Page 695 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement In the Amplitude, "Y Scale" on page 1633 menu, and the Atten Meas Bar dropdown menu panel, a summary is displayed as follows: “Total Atten below 50 GHz” followed by the value of Full Range Atten + Mech Atten + Elec Atten “Total Atten above 50 GHz”...
Page 696 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement External Gain, Ref Level Offset, Max Mixer Level, µW Path Control and IF Gain settings. Limit this value to be no less than 6 dB (total attenuation below 6 dB can never be chosen by Auto) –...
Page 697 As described under "Attenuation" on page 1636, there are two distinct attenuator configurations available in the X-Series, the Single Attenuator and Dual-Attenuator configurations. In Dual-Attenuator configurations, we have mechanical attenuation and electronic attenuation, and current total attenuation is the sum of electronic + mechanical attenuation.
Page 698 However, in the Single-Attenuator configuration, EATT SCPI commands are accepted for compatibility with other X-series instruments, and set a “soft” attenuation. The “soft” attenuation is treated as an addition to the “main” attenuation value set by the...
Page 699 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement frequency range lockout takes precedence If the electronic/soft Attenuator is enabled, then the Stop Freq of the instrument is limited to 3.6 GHz and Internal Preamp is unavailable "LNA" on page 1658 is ON, the electronic attenuator (and the “soft”...
Page 700 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement frequency is reflected in the disabled message displayed for Electrical Attenuator. For N9032B and N9042B IFBW values > 1.5 GHz do not support a Center Frequency that can reach the Low Band maximum frequency. In these cases, the Electrical Attenuator will remain disabled no matter the Center Frequency.
Page 701 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement – Mech Atten at 0 dB. Elec Atten enabled, Mech Atten set to 10 dB, and Elec Atten set to 0 dB. New total attenuation does not equal the value before Elec Atten enabled –...
Page 702 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Adjust Atten for Min Clipping Sets the combination of mechanical and electronic attenuation and gain based on the current measured signal level so that clipping will be at a minimum. This is an immediate action function, that is, it executes once, when the control is pressed.
Page 703 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement In Dual-Attenuator models, you can set Elec+Mech Atten, in which case both attenuators participate in the autoranging, or Elec Atten Only, in which case the mechanical attenuator does not participate in the autoranging. This latter case results in less wear on the mechanical attenuator and is usually faster.
Page 704 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement aliases to "Off" (:POW:RANG:OPT:ATT OFF) :POW:RANG:AUTO? returns true if :POW:RANG:OPT:ATT is not [:SENSe]:POWer[:RF]:RANGe:AUTO ON | OFF | 1 | 0 Backwards Compatibility [:SENSe]:POWer[:RF]:RANGe:AUTO? SCPI Adjustment Algorithm The algorithms for the adjustment are documented below: Single-Attenuator Models Dual-Attenuator models "Adjust Atten for Min Clipping"...
Page 705 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 706 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement "Pre-Adjust for Min Clipping" on page 702 selection is Elec Only. Note that the Mech Atten value is not adjusted, and the value previously set is used. Therefore, there is a case that IF Overload is still observed depending on the input signal level and the Mech Atten setting.
Page 707 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement [:SENSe]:POWer[:RF]:ATTenuation:STEP[:INCRement]? :POW:ATT:STEP 2 Example :POW:ATT:STEP? Notes Has a toggle control on the front panel, but takes a specific value (in dB) when used remotely. The only valid values are 2 and 10 Dependencies Blanked in EXA, CXA and CXA-m if option FSA (2 dB steps) is not present.
Page 708 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Not all measurements support Range Auto/Man. If Auto is not supported in the current measurement, this control is grayed-out, displaying Man, and returned to a SCPI query, but this does not change the Auto/Man setting for Range. When you switch to a measurement that supports Auto, it goes back to Auto if it was previously in Auto mode.
Page 709 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :VOLT:IQ:RANG? Notes The numeric entries are mapped to the smallest gain range whose break point is greater than or equal to the value, or 1 V Peak if the value is greater than 1 V Couplings When "Q Same as I"...
Page 710 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Q Range The internal gain range for the Q channel. Q Range only applies to Input Path Q Only and Ind I/Q. For input I+jQ "I Range" on page 1535 determines both I and Q channel range settings.
Page 711 State Saved Saved in instrument state OFF|ON Range 3.6.3.4 Range (Non-attenuator models) Only available for Keysight’s modular signal analyzers and certain other Keysight products, such as VXT and M941xE. State Saved Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 712 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Range Represents the amplitude of the largest sinusoidal signal that could be present within the IF without being clipped by the ADC. For signals with high peak-to- average ratios, the range may need to exceed the rms signal power by a significant amount to avoid clipping.
Page 713 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement [:SENSe]:POWer[:RF]:RANGe:OPTimize:ATTenuation? Notes Because there is no attenuator control available in these models, the control displays only choices. However, for SCPI compatibility with other platforms, all three parameters (ELECtrical, COMBined, and ON) are honored and all are mapped to ELECtrical, so if any of these three parameters is sent, a subsequent query will return ELEC Dependencies...
Page 714 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement via SCPI, but is not changeable. In such applications the control is grayed-out. Attempts to change the value via SCPI are ignored, but no error message is generated Dependencies Does not appear in Spectrum Analyzer Mode Preset VXT Models M9410A/11A...
Page 715 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement This tab does appear in VXT Models M9410A/11A/15A/16A and M9410E/11E/15E/16E, because "Software Preselection" on page 1669 is under this tab, and VXT Models M9410A/11A/15A/16A and M9410E/11E/15E/16E implement a version of Software Preselection. Presel Center Adjusts the centering of the preselector filter to optimize the amplitude accuracy at the frequency of the selected marker.
Page 716 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement dependencies subsequent measurement has completed, nor are results returned in response to :READ :MEASure queries Measuring bit remains set (true) while this command is operating, and does not go false until the subsequent sweep/measurement has completed Proper Preselector Operation Certain considerations should be observed to ensure proper operation:...
Page 717 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement – Does not appear in VXT Models M9410A/11A/15A/16A – Does not appear in M9410E/11E/15E/16E – Grayed-out if microwave preselector is off – Grayed-out if entirely in Band 0, that is, if Stop Freq is lower than about 3.6 GHz –...
Page 718 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Selection Example Note :POW:GAIN OFF Low Band :POW:GAIN ON Sets the internal preamp to use only the low band. The frequency range of the installed (optional) low-band :POW:GAIN:BAND preamp is displayed in square brackets on the Low Band selection in the dropdown Full Range :POW:GAIN ON...
Page 719 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement When the USB Preamp is connected to USB, the Preamp annotation says “Preamp: USB” if the internal preamp is off or “Preamp: USB, Int” if the internal preamp is on (only for measurements that support the USB preamp) Auto Function [:SENSe]:POWer[:RF]:GAIN[:STATe] OFF | ON | 0 | 1...
Page 720 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement More Information When LNA is installed, the preamp annotation changes to show the state of both LNA and Internal Preamp. Below is an example: Note that when operating entirely in the low band (below about 3.6 GHz), if LNA is on, Internal Preamp is switched off (even if you have its switch set to ON).
Page 721 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement without giving the best possible noise floor. The preamp, if purchased and used, gives better noise floor than does Low Noise Path Enable, but the preamp’s compression threshold and third-order intercept are much poorer than that of Low Noise Path Enable.
Page 722 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement In any of these cases, if the required options are not present and the SCPI command is sent, error - 241, "Hardware missing; Option not installed" is generated Low Noise Path Enable and Full Bypass Enable are grayed-out if the current measurement does not support them Low Noise Path Enable and Full Bypass Enable are not supported in Avionics and MMR Modes (non- modulation measurements).
Page 723 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement This allows the function to automatically switch based on certain Auto Rules as shown below: VMA Mode Measurement µW Path Control Auto behavior Digital Demod Use Standard Path unless tuned frequency > 3.6 GHz and IFBW > 15 MHz, in which case choose Preselector Bypass Monitor Spectrum Always Presel Bypass...
Page 724 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Measurement µW Path Control Auto behavior Modulation Use Standard Path unless tuned frequency > 3.6 GHz and IFBW > 15 MHz, in Analysis which case choose Full Bypass if conditions warrant(FBP Option is available and “Allow Full Bypass in Auto”...
Page 725 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Low Noise Path Enable Low Noise Path Enable provides a lower noise floor under some circumstances, particularly when operating in the 21–26.5 GHz region. With the Low Noise Path enabled, the low band/high band switch and microwave preamp are bypassed whenever all the following are true: –...
Page 726 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement range of the preamp path is too little and the noise floor of the standard path is too high, the Low Noise Path can provide the best dynamic range The graph below illustrates the concept.
Page 727 Option MPB or pre-selector bypass provides an unpreselected input mixer path for certain X-Series signal analyzers with frequency ranges above 3.6 GHz. This signal path allows a wider bandwidth and less amplitude variability, which is an advantage when doing modulation analysis and broadband signal analysis.
Page 728 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement interface. Also, if the preamp is turned on, the Low Noise Path is not used, whether or not the Full Bypass Enable is selected in the user interface. The only time the Low Noise Path is used is when Full Bypass Enable is selected, the sweep is completely in High Band (>...
Page 729 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Preselector and Bandwidth Conflict When the Frequency Extender Preselector is applied and the signal bandwidth is greater than 2.5 [GHz], then a settings alert message will show to warn the user that the signal may be distorted due to the limitation of the Frequency Extender Preselector bandwidth.
Page 730 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement N9042B+V3050A Software Preselection compensates for the frequency range limit of the microwave preselector. Since the microwave preselector only goes up to 50 GHz, software preselection must be used to suppress and separate images above 50 GHz. The specific algorithm used for software preselection is specified by the SW Preselection Type selection –...
Page 731 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Preset N9041B N9042B+V3050A M9410A/11A State Saved Saved in instrument state SW Preselection Type Specifies the algorithm used for software preselection. Two hidden sweeps occur in succession. The second sweep is offset in LO frequency by 2 * IF / N.
Page 732 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement SW Preselection BW Specifies the effective bandwidth to be used for Software Preselection. The options are: – NORMal – when making Swept measurements, a software preselection algorithm is used which takes up to 4 background acquisitions, then post-processes the result.
Page 733 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement and 6000 MHz. The Prefilter provides the necessary rejection of the unwanted signal. [:SENSe]:<measurement>:PFILter[:STATe] ON | OFF | 1 | 0 Remote Command [:SENSe]:<measurement>:PFILter[:STATe]? Example Enable High Freq Prefilter for the Complex Spectrum Measurement in BASIC Mode: :SPEC:PFIL ON...
Page 734 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement 3.6.4 BW Opens the Bandwidth (BW) menu, which contains the Info BW control. 3.6.4.1 Settings Contains basic bandwidth functions. It is the only tab under BW. Info BW Allows you to enter a frequency value to set the channel bandwidth that will be used for data acquisition.
Page 735 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Preset Values Modes Option Preset Values SA, WCDMA 5 MHz 10 MHz LTEATDD, LTEAFDD, 5G NR Automatically calculated Same as max value WLAN None 10 MHz 25 MHz Radio Std Preset 802.11a/b/g/n/ac/ax/be (20 25 MHz...
Page 736 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement User View Lets you choose a View from the saved User Views for the current measurement. This panel only appears if a User View exists for the current measurement. :DISPlay:VIEW:ADVanced:SELect <alphanumeric>...
Page 737 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Save Layout as New View Saves your new View as a User View. An alpha keyboard appears, which lets you name your new View; the default is the old View name plus a number. :DISPlay:VIEW:ADVanced:NAME <alphanumeric>...
Page 738 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Delete User View You can delete the current View if it is a User View. The default view becomes the current view for the Measurement. :DISPlay:VIEW:ADVanced:DELete Remote Command :DISP:VIEW:ADV:DEL Example Notes <alphanumeric>...
Page 739 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :DISP:VIEW:ADV:CAT? Example Notes Returns a quoted string of the available Views for the current measurement, separated by commas. The list includes names for all the Views, including User Views, available for the current Measurement Example: "Normal,Trace Zoom,Spectrogram,Baseband,myView1,yourView1"...
Page 740 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Preset State Saved Saved in instrument state :DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe] OFF | ON | 0 | 1 Backwards Compatibility :DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe]? SCPI This command is accepted for backwards compatibility with older instruments, but the WINDow, TRACe GRID parameters are ignored...
Page 741 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :DISP:ANN:TRAC OFF Example Preset State Saved Saved in instrument state Control Annotation Turns on and off the display of values on the Active Function controls for all measurements in the current Mode. This is a security feature. :DISPlay:ACTivefunc[:STATe] ON | OFF | 1 | 0 Remote Command :DISPlay:ACTivefunc[:STATe]?
Page 742 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement 2. To reduce emissions from the display, drive circuitry 3. For security purposes If you have turned off the display: – and you are in local operation, the display can be turned back on by pressing any key or by sending :SYSTem:DEFaults MISC :DISPlay:ENABle ON...
Page 743 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Backwards :SYST:PRES no longer turns on :DISPlay:ENABle as it did in legacy analyzers Compatibility Notes 3.6.6 Frequency Opens the Frequency menu, which contains controls that allow you to control the frequency and channel parameters of the instrument.
Page 744 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement – "Center Frequency Presets" on page 745 – "VXT Models with Radio Heads/CIU Frequency Range" on page 747 – "RF Center Freq" on page 747 – "Ext Mix Center Freq" on page 748 –...
Page 745 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :FREQ:CENT:AUTO OFF Example :FREQ:CENT:AUTO? Dependencies Only available for the Monitor Spectrum, Power Stat CCDF and IQ waveform measurements in MSR, LTE-Advanced FDD/TDD and 5G NR Modes Couplings When Center Frequency changes, state automatically changes to Manual (OFF) Center Frequency, Center Frequency Offset and Carrier Reference Frequency are coupled.
Page 746 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Freq Option CF after Mode Stop Freq after Mode Max Freq (can't tune Preset Preset above) 25.005 GHz 50.0 GHz 52 GHz F03 (CXA-m) 1.505 GHz 3.0 GHz 3.08 GHz F07 (CXA-m) 3.755 GHz 7.5 GHz...
Page 747 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Tracking Min Freq If above this Freq, Stop Freq Max Freq (clips to this freq when turn (can't tune Generator clipped to this Freq when TG TG on and can’t tune below above) Option turned on...
Page 748 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Ext Mix Center Freq Specifies the External Mixer Center Frequency. Sets the Center Frequency to use when the External Mixer is selected, even if the External Mixer input is not the input that is selected at the time the command is sent.
Page 749 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement [:SENSe]:FREQuency:IQ:CENTer? :FREQ:IQ:CENT 30 MHz Example Notes This command is the same in all Modes, but the parameter is Measurement Global, so the value is independent in each Mode and common across all the measurements in the Mode Preset 0 Hz State Saved...
Page 750 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement [:SENSe]:FREQuency:CENTer:STEP:AUTO OFF | ON | 0 | 1 Remote Command [:SENSe]:FREQuency:CENTer:STEP:AUTO? :FREQ:CENT:STEP:AUTO ON Example :FREQ:CENT:STEP:AUTO? Preset 3.6.7 Marker Accesses a menu that enables you to select, set up and control the markers for the current measurement.
Page 751 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Marker X-Axis Value Sets the marker X-Axis value in the current marker X-Axis Scale unit. This function has no effect if the control mode is Off, but is the remote command equivalent of entering an X value if the control mode is Normal or Delta.
Page 752 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Normal and places it at the center of the screen on the trace determined by the Marker Trace rules. At the same time, Marker X Axis Value appears on the Active Function area.
Page 753 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Marker Settings Diagram Lets you configure the Marker system using a visual utility. All Markers Off Turns off all markers. :CALCulate:PSTatistic:MARKer:AOFF Remote Command :CALC:PST:MARK:AOFF Example Couple Markers When this function is ON, moving any marker causes an equal X-Axis movement of every other marker that is not Off.
Page 754 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Relative To Selects the marker to which the selected marker is relative (its reference marker). Every marker has another marker to which it is relative. This marker is referred to as the “reference marker”...
Page 755 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :CALCulate:PSTatistic:MARKer[1]|2|…|12:TRACe MEASured | GAUSsian | REFerence Remote Command :CALCulate:PSTatistic:MARKer[1]|2|…|12:TRACe? :CALC:PST:MARK3:TRAC MEAS Example :CALC:PST:MARK:TRACE? MEASured Preset State Saved MEASured|GAUSsian|REFerence Range Marker Settings Diagram Lets you configure the Marker system using a visual utility. This is the same as "Marker Settings Diagram"...
Page 756 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Meas Cycles Set the number of measurement cycles to calculate power statistic data. This number is coupled to "Counts" on page 755, by: Meas Cycles = Counts / (Sampling Frequency * Meas Interval) When the Counts value cannot be divided by (Sampling Frequency * "Meas Interval"...
Page 757 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Auto Couple Immediately puts all Auto/Man functions into Auto. Auto Couple is confined to the current measurement only. It does not affect other measurements in the Mode. In the Auto state, Auto/Man functions are said to be “coupled”, meaning their values change as you make changes to other values in the measurement.
Page 758 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Executing Auto Coupledoes not affect markers, marker functions, trace or display attributes, or any other instrument setting other than those specifically mentioned above. Measurement-Specific Details TOI (SA Mode only) Parameters affected by Auto Couple are: –...
Page 759 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :CONF:PST Example Couplings Selecting Meas Preset restores all measurement parameters to their default values 3.6.8.2 Meas Standard This tab contains controls for setting the standard based on which the current measurement is made.
Page 760 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement Standard Compatibility ZigBee (IEEE 802.15.4) LoRa HRP UWB Z-Wave (ITU-T G.9959) Channel Power Spurious Emissions CCDF IQ Waveform Monitor Spectrum Modulation Analysis (Digital) LoRa CSS Demod (Analog) Preset to Std This group of controls lets you easily set up the analyzer for ZigBee (IEEE 802.15.4), Z-Wave (ITU-T G.9959) , LoRa CSS or HRP UWB measurements.
Page 761 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement OBW, Monitor Spectrum and Spurious Emissions have been supported by this application, with the following exceptions: – For Spurious Emissions, there isn’t any customized setting for any radio standard; –...
Page 762 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement IF Gain Used to set the IF Gain function to: Auto, Low Gain or High Gain. These settings affect sensitivity and IF overloads. Only applies to the RF input. Does not apply to baseband I/Q input. [:SENSe]:PSTatistic:IF:GAIN[:STATe] ON | OFF | 1 | 0 Remote Command [:SENSe]:PSTatistic:IF:GAIN[:STATe]?
Page 763 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement [:SENSe]:PSTatistic:URATio? :PST:URAT X8 Example :PST:URAT? Notes X1 is for backwards compatibility Preset State Saved Yes, Saved in instrument state X1|X2|X4|X8|X16|X32 Range 3.6.8.4 Global The controls in this menu apply to all Modes in the instrument. Some controls (for example, "Global Center Freq"...
Page 764 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :INST:COUP:FREQ:CENT ALL Example :INST:COUP:FREQ:CENT? Preset Set to on Global Settings, Restore Defaults and System, Restore Defaults, All Modes ALL|NONE Range Preset :GLOBal:FREQuency:CENTer[:STATe] 1 | 0 | ON | OFF Backwards Compatibility SCPI :GLOBal:FREQuency:CENTer[:STATe]?
Page 765 – A line with an arrow is Single – A loop with an arrow is Continuous Backwards X-Series A-models had Single and Cont hardkeys in place of the SweepSingleCont softkey. In the X- Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 766 X-Series B-models have a Cont/Single toggle control instead of Single and Cont hardkeys, but it is still true that, if in single measurement, the Cont/Single toggle control never restarts a measurement and...
Page 767 (displayed average count reset to 1) for a trace in Clear Write, but did not Notes restart Max Hold and Min Hold :INIT:REST In X-Series, the Restart hardkey and the command restart not only Trace Average, but MaxHold and MinHold traces as well Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 768 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement More Information The Restart function first aborts the current sweep or measurement as quickly as possible. It then resets the sweep and trigger systems, sets up the measurement and initiates a new data measurement sequence with a new data acquisition (sweep) taken once the trigger condition is met.
Page 769 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement application mode measurements where an exception is made and the traces and/or results need to be blanked before displaying the new results. To summarize, the following list shows what happens to the trace data on various events: Event Trace Effect...
Page 770 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :INITiate:RESume :INIT:PAUS Example :INIT:RES Dependencies Not displayed in Modes that do not support pausing Annotation Only on control Abort (Remote Command Only) Stops the current measurement. Aborts the current measurement as quickly as possible, resets the sweep and trigger systems, and puts the measurement into an "idle"...
Page 771 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :DISPlay:PSTatistic:VIEW[1]:WINDow2:TRACe:X[:SCALe]:PDIVision <rel_ampl> Remote Command :DISPlay:PSTatistic:VIEW[1]:WINDow2:TRACe:X[:SCALe]:PDIVision? :DISP:PST:VIEW:WIND2:TRAC:X:PDIV 10 Example :DISP:PST:VIEW:WIND2:TRAC:X:PDIV? Notes The CCDF measurement has the trace display only in Window 2, because values other than “2” are not available as the sub-op code Preset 2.00 State Saved...
Page 772 3 Short-Range Comms & IoT Mode 3.6 Power Stat CCDF Measurement :DISPlay:PSTatistic:RTRace[:STATe] OFF | ON | 0 | 1 Remote Command :DISPlay:PSTatistic:RTRace[:STATe]? :DISP:PST:RTR OFF Example :DISP:PST:RTR? Preset State Saved Saved in instrument state OFF|ON Range [:SENSe]:PSTatistic:RTRace[:STATe] Backwards Compatibility SCPI Gaussian Line Toggles the Gaussian trace display On or Off.
Page 773 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7 ACP Measurement ACP is a measurement of the amount of interference, or power, in an adjacent frequency channel. The results are displayed as a bar graph or as spectrum data, with measurement data at specified offsets.
Page 774 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Results Returned Returns <Num Pts> comma-separated scalar values representing the Y values in Trace 1 Returns <Num Pts> comma-separated scalar values representing the Y values in Trace 2 Returns <Num Pts> comma-separated scalar values representing the Y values in Trace 3 Dependent on Mode and "Measurement Type"...
Page 775 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Results Returned Measurement Type Item Unit, if any TPRef Relative power or PSDRef Relative PSD TPRef Absolute power PSDRef Absolute PSD dBm/Hz, dBm/MHz* TPRef Reference power PSDRef Reference PSD dBm/Hz, dBm/MHz* Reference Index 1 Reference Index 2 0 (Reserved)
Page 776 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7.1 Measurement Results for n = 1, or no Index Specified Mode = SA, Radio Std = None, Number of carriers = 1, Only Offset A is On Returns 3 comma-separated values that correspond to: Item Unit, if Reference carrier power...
Page 777 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Conditions Results Item Unit, if any Lower offset A - relative power Lower offset A - absolute power Upper offset A - relative power Upper offset A - absolute power Lower offset B - relative power Lower offset B - absolute power Upper offset B - relative power Upper offset B - absolute power...
Page 778 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Measurement Type = Power Spectral Density Reference Conditions Results Mode: LTEAFDD, For the trace specified by "Measure Trace" on page 1508, returns comma-separated scalar LTEATDD, 5GNR, MSR results in the following order: "Power Ref"...
Page 779 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Conditions Results Item Unit, if any Upper offset B - relative power Upper offset B - absolute power dBm/Hz or dBm/MHz* When "Max Num of Offsets" on page 902 is 6, returns 28 results (Offset A-F: 28 = 4 + 4*6) and when set to 12, returns 52 results (Offset A-L: 52 = 4 + 4 * 12) *The unit is determined by "PSD Unit"...
Page 780 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Item Result Unit, if any Upper offset B Absolute power … When "Max Num of Offsets" on page 902 is 6, returns 48 results (Offset A-F: 48 = 24 + 4*6) and when set to 12, returns 72 results (Offset A-L: 72 = 24 + 4 * 12) If any result is not available, -999.0 is returned Measurement Type = Power spectral density reference For the trace specified by...
Page 781 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7.3 Measurement Results for n = 3 For the trace specified by "Measure Trace" on page 1508, returns scalar pass/fail values (0 = passed, or 1 = failed) determined by comparing the relative to the reference carrier and by testing the absolute power limit of the offset frequencies (measured as total power in dB if "Measurement Type"...
Page 782 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Measurement Type = Total power reference For the trace specified by "Measure Trace" on page 1508, returns (2 * Number of Carriers) comma-separated scalar results in the following order: Channel Result Unit, if any Channel (1) Relative power...
Page 783 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Item Unit, if any page 783) Inner Lower offset A - relative power Inner Lower offset A - absolute power dBm, dBm/Hz or dBm/MHz* Inner Upper offset A - relative power Inner Upper offset A - absolute power dBm, dBm/Hz or dBm/MHz*...
Page 784 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Power Ref Setting Option Reference Power #1 Reference Power #2 dBm, dBm/Hz or dBm/MHz* dBm, dBm/Hz or dBm/MHz* Others Reference carrier power dBm, dBm/Hz or dBm/MHz* *For PSD results, the unit is determined by "PSD Unit"...
Page 785 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement View Selection by Number (Remote Command Only) Selects the results view. The following command allows you to select the desired measurement view numerically. :DISPlay:ACPower:VIEW:NSELect <integer> Remote Command For view numbers, see table above :DISPlay:ACPower:VIEW:NSELect? :DISP:ACP:VIEW:NSEL 1 Example...
Page 786 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement The results of the measurement can be displayed as a single spectrum trace view or displayed with a Bar Graph trace on the spectrum trace. The Graph window appears in several Views, as follows: View Size Position...
Page 787 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Metrics Window in Carrier Info view: The text window displays the following results: Total Carrier Power This is the total power of all the carriers with carrier power present set to yes. The power is calculated by integrating across the bandwidth declared by the Carrier Integ BW parameter for each carrier and then totaling the sums.
Page 788 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement present, the power will be relative to the reference carrier. The power is calculated by integrating across the bandwidth declared by the Carrier Integ BW parameter. The integration bandwidth is shown as part of the result. This is the value of the Carrier Integ BW for the carrier unless the RRC Filter is on, then the integration bandwidth used is the displayed value, which is (1 + alpha)/T where T = 1/(Carrier Integ BW).
Page 789 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Shows the offset frequency from the carrier reference frequency in multi-carrier measurements. The carrier frequency display type determines whether the relative frequency or absolute frequency will be displayed. Sub-block For intra-band non-contiguous spectrum operation, the sub-block concept is introduced, which refers to one contiguous allocated block of spectrum for transmission and reception in the intra-band non-contiguous aggregation mode.
Page 790 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7.8.1 Y Scale Contains controls that pertain to the Y axis parameters of the measurement. These parameters control how data on the vertical (Y) axis is displayed and control instrument settings that affect the vertical axis. Ref Value Sets the value for the absolute power reference.
Page 791 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Couplings Coupled to "Scale Range" on page 1363 as follows: Scale/Div = Scale Range/10 (number of divisions) is ON, this value is automatically determined by the measurement When "Auto Scaling" on page 792 result When you change a value, Auto Scaling automatically changes to Off Preset...
Page 792 Controls the attenuator functions and interactions between the attenuation system components. There are two attenuator configurations in the X-Series. One is a Dual-Attenuator configuration consisting of a mechanical attenuator and an optional electronic attenuator. The other configuration uses a single attenuator with combined mechanical and electronic sections that controls all the attenuation functions.
Page 793 Meas Preset. Only available when the hardware set includes an input attenuator, which is typically only the case for Keysight’s benchtop instruments. For example, this tab does not appear in VXT models M9420A/10A/11A/15A/16A, M9410E/11E/15E/16E, nor in UXM. In UXM, all Attenuation and Range settings are disabled, as the expected input power level is handled by the Call Processing App that drives the DUT power control.
Page 794 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Single-Attenuator Configuration You can tell which attenuator configuration you have by pressing the Attenuation tab, which (in most Modes) opens the Attenuation menu. If the first control in the Attenuation menu says Mech Atten you have the Dual-Attenuator configuration. If the first control says Atten you have the Single-Attenuator configuration.
Page 795 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :POW:FRAT? Notes When you enter an amplitude value that falls between valid values, the value will be incremented to the next smallest valid value Dependencies Only appears if input RF is selected, RF Input Port 2 is selected, and the Full Range Attenuator exists Couplings This value is never changed by any coupling, but other couplings use this value.
Page 796 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:POWer[:RF]:ATTenuation <rel_ampl> Remote Command [:SENSe]:POWer[:RF]:ATTenuation? :POW:ATT 20 Example Dual-Attenuator configuration: sets the mechanical attenuator to 20 dB Single-Attenuator mode: sets the main attenuation to 20 dB (see below for definition of “main” attenuation) In either case, if the attenuator was in Auto, it is set to Manual Dependencies Some measurements do not support Auto setting of Mech Atten.
Page 797 As described under "Attenuation" on page 1636, there are two distinct attenuator configurations available in the X-Series, the Single Attenuator and Dual-Attenuator configurations. In Dual-Attenuator configurations, we have mechanical attenuation and electronic attenuation, and current total attenuation is the sum of electronic + mechanical attenuation.
Page 798 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement the Single-Attenuator configuration, for compatibility purposes). Then current total attenuation is the sum of main + soft attenuation. "Elec Atten" on page 1641 for more about “soft” attenuation. In some measurements, the Mech Atten control has an Auto/Man function. In NOTE these measurements, an Auto/Man switch is shown on the Mech Atten control: Note that in configurations that include an Electronic Attenuator, this switch is...
Page 799 However, in the Single-Attenuator configuration, SCPI commands are accepted for compatibility with other X-series instruments, and set a “soft” attenuation. The “soft” attenuation is treated as an addition to the “main” attenuation value set by the...
Page 800 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Auto Function [:SENSe]:POWer[:RF]:EATTenuation:STATe OFF | ON | 0 | 1 Remote Command [:SENSe]:POWer[:RF]:EATTenuation:STATe? :POW:EATT:STAT ON Example :POW:EATT:STAT? Preset (Disabled) for Swept SA measurement (Enabled) for all other measurements that support the electronic attenuator The maximum Center Frequency for Low Band can change based on the NOTE selected IFBW for measurements that support IFBW (for example, Waveform...
Page 801 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement knob, and it behaves as it normally would in manual mode – The Auto/Man state of (Mech) Atten is saved – The Auto/Man toggle on the (Mech) Atten control disappears, and the auto rules are disabled –...
Page 802 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement than the even-decibel steps, so one tradeoff for this superior relative accuracy is reduced absolute amplitude accuracy. Another disadvantage of the electronic attenuator is that the spectrum analyzer loses its “Auto” setting, making operation less convenient. Also, the relationship between the dynamic range specifications (TOI, SHI, compression, and noise) and instrument performance are less well-known with the electrical attenuator.
Page 803 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :POW:RANG:OPT:TYPE? Dependencies Does not appear in the Swept SA, RTSA, Monitor Spectrum and Complex Spectrum measurements Appears in the Waveform measurement in BASIC and 5G NR Modes COMBined Preset State Saved Saved in instrument state Pre-Adjust for Min Clipping If this function is ON, it applies the adjustment described under...
Page 804 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement "Pre-Adjust for Min Clipping" on page 803 is grayed-out Does not appear in the Swept SA, RTSA, Monitor Spectrum and Complex Spectrum measurements Appears in the Waveform measurement in BASIC and 5G NR Modes ELEC Preset when Elec Atten is Disabled at preset, otherwise...
Page 805 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Single-Attenuator Models Dual-Attenuator models "Adjust Atten for Min Clipping" on page 1645 "Pre-Adjust for Min Clipping" on page 803 selection is Mech + Elec Atten: Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 806 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Short Range Comms & IoT Mode User's & Programmer's Reference...
Page 807 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement "Pre-Adjust for Min Clipping" on page 803 selection is Elec Only. Note that the Mech Atten value is not adjusted, and the value previously set is used. Therefore, there is a case that IF Overload is still observed depending on the input signal level and the Mech Atten setting.
Page 808 All other models: 2 dB State Saved Saved in instrument state 3.7.8.3 Range (Non-attenuator models) Only available for Keysight’s modular signal analyzers and certain other Keysight products, such as VXT and M941xE. State Saved Range Represents the amplitude of the largest sinusoidal signal that could be present within the IF without being clipped by the ADC.
Page 809 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Adjust Range for Min Clipping Sets the combination of attenuation and gain based on the current measured signal level so that clipping will be at a minimum. This is an "immediate action" function, that is, it executes once, when the key is pressed.
Page 810 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Peak-to-Average Ratio Used with "Range (Non-attenuator models)" on page 1651 to optimize the level control in the instrument. The value is the ratio, in dB, of the peak power to the average power of the signal to be measured.
Page 811 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Mixer Lvl Offset This is an advanced setting to adjust target Range at the input mixer, which in turn affects the signal level in the instrument’s IF. This setting can be used when additional optimization is needed after setting "Peak-to-Average Ratio"...
Page 812 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement between Start Freq and Stop Freq, the instrument first performs a peak search, and then performs centering on the marker’s center frequency. The value displayed on "Preselector Adjust" on page 1656 changes to reflect the new preselector tuning.
Page 813 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement search to find 2. If the selected marker is already On, the instrument attempts the centering at that marker’s frequency. There is no preselector for signals below about 3.6 GHz, so if the marker is on a signal below 3.6 GHz, no centering is attempted, and an advisory message is generated 3.
Page 814 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved The Preselector Adjust value set by "Presel Center" on page 1654, or by manually adjusting Preselector Adjust Not saved in instrument state, and does not survive a Preset or power cycle Min/Max –/+500 MHz [:SENSe]:POWer[:RF]:MW:PADJust...
Page 815 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement The maximum Center Frequency for Low Band, displayed in square brackets, NOTE can change based on the selected IFBW for measurements that support IFBW (for example, Waveform measurement across all Modes that support it). In certain models (such as N9042B &...
Page 816 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement LNA is an additional preamplifier that provides superior DANL and frequency range compared to "Internal Preamp" on page 1657. LNA provides lower system noise figure, especially at frequencies above 100 MHz, and can be operated up to the full range of 50 GHz instruments.
Page 817 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement µW Path Control Options for this control include µW Preselector Bypass (Option MPB), Low Noise Path (Option LNP) and Full Bypass Enable in the High Band path circuits. When the µW Preselector is bypassed, flatness is improved, but will be subject to spurs from out of band interfering signals.
Page 818 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:POWer[:RF]:MW:PATH STD | LNPath | MPBypass | FULL Remote Command [:SENSe]:POWer[:RF]:MW:PATH? :POW:MW:PATH LNP Example Enables the Low Noise path :POW:MW:PATH? Notes When "Presel Center" on page 1654 is performed, the instrument momentarily switches to the Standard Path, regardless of the setting of µW Path Control The DC Block will always be switched in when the low noise path is switched in, to protect succeeding circuitry from DC.
Page 819 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Annotation In the Meas Bar, if the Standard path is chosen: µW Path: Standard If Low Noise Path is enabled but the LNP switch is not thrown: µW Path: LNP,Off If the Low Noise Path is enabled and the LNP switch is thrown: µW Path: LNP,On If the preselector is bypassed: µW Path: Bypass...
Page 820 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Measurement µW Path Control Auto behavior Always Presel Bypass Always Presel Bypass Spurious Always Standard Path Emissions WLAN Mode Measurement µW Path Control Auto behavior Modulation Always Presel Bypass Analysis Spectral Flatness Always Presel Bypasss Power vs Time Always Presel Bypass...
Page 821 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Measurement µW Path Control Auto behavior Emissions Transmit On|Off Use Standard Path unless tuned frequency > 3.6 GHz and Info BW > 15 MHz, in Power which case choose Preselector Bypass Channel Quality Mode Measurement µW Path Control Auto behavior Group Delay...
Page 822 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement whether or not the Low Noise Path Enable is selected in the user interface. The only time the Low Noise Path is used is when Low Noise Path Enable is selected, the sweep is completely in High Band (>...
Page 823 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement There are other times where selecting the low noise path improves performance, too. Compression-limited measurements such as finding the nulls in a pulsed-RF spectrum can profit from the low noise path in a way similar to the TOI-limited measurement illustrated.
Page 824 3.7 ACP Measurement Option MPB or pre-selector bypass provides an unpreselected input mixer path for certain X-Series signal analyzers with frequency ranges above 3.6 GHz. This signal path allows a wider bandwidth and less amplitude variability, which is an advantage when doing modulation analysis and broadband signal analysis. The disadvantage is that, without the preselector, image signals will be displayed.
Page 825 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement whenever Full Bypass Enable is selected, a warning message appears in the status bar: “Full Bypass Enabled, maximum safe input power reduced” Microwave Preselector Bypass Backwards Compatibility Example Bypass the microwave preselector: :POW:MW:PRES OFF Notes Included for Microwave Preselector Bypass backwards compatibility...
Page 826 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Settings Alert message in the error queue Software Preselection Provided in some instruments, either to compensate for issues with provided hardware preselection or to provide the preselection function when there is no hardware preselector.
Page 827 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Note that for N9042B+V3050A, in the Swept SA measurement, Software Preselection works even if the measurement is using an FFT Sweep Type. In measurements other than Swept SA, Software Preselection is not used if the measurement is using an FFT Sweep Type.
Page 828 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Two hidden sweeps occur in succession. The second sweep is offset in LO frequency by 2 * IF / N. For each point in each trace, the smaller amplitude from the two traces is taken and placed in that point in the selected trace.
Page 829 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement wideband signals with occupied bandwidths up to 2 GHz. This increases the risk of images failing to be rejected, but improves the measurement speed [:SENSe]:POWer[:RF]:SWPResel:BW NORMal | NARRow Remote Command [:SENSe]:POWer[:RF]:SWPResel:BW? :POW:SWPR:BW NARR Example Dependencies Only appears in N9041B and N9042B+V3050A.
Page 830 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Prefilter Presets Meas Mode Preset SPEC BASIC BASIC, WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA WCDMA WCDMA PCON WCDMA EVMQ WCDMA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA WCDMA, LTEAFDD, LTEATDD, 5GNR, VMA, SA WCDMA, WLAN, LTEAFDD, LTEATDD, 5GNR, VMA, SA...
Page 831 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Res BW Activates the resolution bandwidth active function, which allows you to manually set the resolution bandwidth (RBW) of the instrument. Normally, Res BW (Auto) selects automatic coupling of Res BW to "Span"...
Page 832 For backwards compatibility, this command accepts both the BANDwidth BWIDth forms Compatibility For ESA, the maximum Res BW was 5 MHz; for X-Series it is 8 MHz Notes The following command is supported [:SENSe]:ACP:SWEep:BANDwidth|BWIDth[:RESolution] Auto Function [:SENSe]:ACPower:BANDwidth[:RESolution]:AUTO ON | OFF | 1 | 0...
Page 833 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement corresponding bandwidth of the single LTE carrier, as shown in the table below. In the Multi-carrier case, the narrowest Res BW among the active carriers is used. LTEAFDD, LTEATDD Modes Carrier BW Auto Res BW, kHz 1.4 MHz 3 MHz...
Page 834 –3 dB bandwidth of the filter. That is, a 10 MHz Res BW filter was a Gaussian shape with its –3 dB points 10 MHz apart. In X-Series, the RBW Filter BW menu lets you choose between a Gaussian and Flat Top filter shape, for varying measurement conditions.
Page 835 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Filter Type SCPI Example Gaussian :BAND:SHAP GAUS Flattop :BAND:SHAP FLAT [:SENSe]:ACPower:BANDwidth:SHAPe GAUSsian | FLATtop Remote Command [:SENSe]:ACPower:BANDwidth:SHAPe? :ACP:BAND:SHAP GAUS Example :ACP:BAND:SHAP? Notes GAUSsian= Gaussian FLATtop = Flattop Dependencies Disabled when "Meas Method" on page 863 FAST FPOWer If pressed, an advisory message is generated.
Page 836 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7.10 Display Lets you configure display items for the current Mode, Measurement, View, or Window. 3.7.10.1 Meas Display Contains controls for setting up the display for the current Measurement, View or Window.
Page 837 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Notes The graticule is the set of horizontal and vertical lines that make up the grid/divisions for the X-Axis and Y-Axis Preset State Saved Saved in instrument state :DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe] OFF | ON | 0 | 1 Backwards Compatibility :DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe]?
Page 838 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :DISPlay:ANNotation:TRACe[:STATe]? :DISP:ANN:TRAC OFF Example Preset State Saved Saved in instrument state Control Annotation Turns on and off the display of values on the Active Function controls for all measurements in the current Mode. This is a security feature. :DISPlay:ACTivefunc[:STATe] ON | OFF | 1 | 0 Remote Command :DISPlay:ACTivefunc[:STATe]?
Page 839 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 1. To increase speed as much as possible by freeing the instrument from having to update the display 2. To reduce emissions from the display, drive circuitry 3. For security purposes If you have turned off the display: –...
Page 840 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Set by :SYST:DEF MISC, but not affected by *RST :SYSTem:PRESet State Saved Not saved in instrument state Backwards :SYST:PRES no longer turns on :DISPlay:ENABle as it did in legacy analyzers Compatibility Notes 3.7.10.3 View Contains controls for selecting the current View, and for editing User Views.
Page 841 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Backwards The legacy node Compatibility :DISPlay:VIEW[:SELect] SCPI is retained for backwards compatibility, but it only supports predefined views Restore Layout to Default Restores the Layout to the default for Basic. Modified Views are very temporary; if you exit the current measurement they are discarded, and they are not saved in State.
Page 842 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Rename User View You can rename the current View by giving it a new unique name. Only User Views can be renamed, if the current View is a Predefined View, an error occurs. :DISPlay:VIEW:ADVanced:REName <alphanumeric>...
Page 843 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :DISP:VIEW:ADV:DEL:ALL Example Notes Disabled if there are no User Views View Editor Remote Commands The following remote commands help you manage Views and User Views. Note that the SCPI node for User Views handles both Predefined and User Views. The legacy nodes, :DISPlay:VIEW[:SELect] and :DISPlay:VIEW:NSEL, are retained for...
Page 844 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7.11 Frequency Contains controls that allow you to control the Frequency and Channel parameters of the instrument. Some features in the Frequency menu are the same for all measurements in the current Mode –...
Page 845 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:FREQuency:CENTer <freq> Remote Command [:SENSe]:FREQuency:CENTer? Example Set Center Frequency to 50 MHz: :FREQ:CENT 50 MHz Increment the Center Frequency by the value of CF Step: :FREQ:CENT UP Return the current value of Center Frequency: :FREQ:CENT? Notes Sets the RF, External Mixing or I/Q Center Frequency depending on the selected input...
Page 846 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Freq Option CF after Mode Stop Freq after Mode Max Freq (can't tune Preset Preset above) 507 (CXA) 3.755 GHz 7.5 GHz 7.58 GHz 508 (all but MXE) 1.805 GHz 3.6 GHz 8.5 GHz 508 (MXE) 4.205 GHz 8.4 GHz...
Page 847 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Model CF after Mode Preset Stop Freq after Mode Preset Max Freq (can't tune above) CXA opt C75 0.7505 GHz 1.5 GHz 1.58 GHz 505 MHz 1 GHz 1.000025 GHz Tracking Generator Frequency Limits (CXA only) Tracking Min Freq If above this Freq, Stop Freq...
Page 848 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :FREQ:RF:CENT 30 MHz Example :FREQ:RF:CENT? Notes This command is the same in all Modes, but the parameter is Measurement Global. So, the value is independent in each Mode and common across all the measurements in the Mode Dependencies If the electronic/soft attenuator is enabled, any attempt to set Center Frequency such that the Stop Frequency would be >3.6 GHz fails and results in an advisory message.
Page 849 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Stop frequencies are 26.5 and 40 GHz respectively. The center of these two frequencies is 33.25 GHz Therefore, after Restore Input/Output Defaults, if you go to External Mixing and do a Mode Preset while in Spectrum Analyzer Mode, the resulting Center Frequency is 33.25 GHz State Saved The minimum frequency in the currently selected mixer band + 5 Hz...
Page 850 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:FREQuency:SPAN <freq> Remote Command [:SENSe]:ACPower:FREQuency:SPAN? :ACP:FREQ:SPAN 10 MHz Example :ACP:FREQ:SPAN? Notes In Bluetooth Mode, the value of Span has to be an odd MHz Dependencies If the electrical attenuator is enabled, any attempt to set Span such that the Stop Frequency would be >3.6 GHz results in an error In instruments with an RF Preselector, such as MXE, you cannot sweep across the band break at 3.6 GHz while the RF Preselector is on in Continuous sweep, as there is a mechanical switch that...
Page 851 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Freq Option Max Span (can't set higher than this) 503, F03 (CXA, CXA-m) 3.08 GHz 507 (all but CXA) 7.1 GHz 507 (CXA, CXA-m) 7.575 GHz 508 (all but MXE) 8.5 GHz 508 (MXE) 8.5 GHz 513, F13...
Page 852 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement CF Step Changes the step size for the center frequency and start and stop frequency functions. Once a step size has been selected and the center frequency function is active, the step keys (and the UP|DOWN parameters for Center Frequency from remote commands) change the center frequency by the step-size value.
Page 853 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7.12 Marker Accesses a menu that enables you to select, set up and control the markers for the current measurement. If there are no active markers, Marker selects marker 1, sets POSition it to (Normal) and places it at the center of the display.
Page 854 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :CALCulate:ACPower:MARKer[1]|2|…|12:X? :CALC:ACP:MARK3:X 0 Example :CALC:ACP:MARK3:X? Notes If no suffix is sent, uses the fundamental units for the current marker X-Axis Scale. If a suffix is sent that does not match the current marker X-Axis Scale unit, an error “Invalid suffix” is generated The query returns the marker’s absolute X Axis value if the control mode is POSition, or the offset from the marker’s reference marker if the control mode is DELTa.
Page 855 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :CALCulate:ACPower:MARKer[1]|2|…|12:Y? Remote Command :CALC:ACP:MARK11:Y? Example Notes Returns the marker Y-axis result, if the control mode is POSition or DELTa. If the marker is OFF, the response is Not A Number Dependencies Unavailable when "Meas Method"...
Page 856 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset State Saved Saved in instrument state OFF|ON Range :CALCulate:ACPower:MARKer[1]|2|…|12:STATe OFF | ON | 0 | 1 Backwards Compatibility :CALCulate:ACPower:MARKer[1]|2|…|12:STATe? SCPI Delta Marker (Reset Delta) DELTa Pressing this button has exactly the same effect as pressing in Marker Mode.
Page 857 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset Presets on Mode Preset and All Markers Off State Saved Saved in instrument state 3.7.12.3 Peak Search The controls on this tab allow you to move the marker to selected peaks of the signal, giving you enormous analysis capabilities, particularly when combined with the Delta Marker function.
Page 858 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Next Peak Moves the selected marker to the peak that is next lower in amplitude than the current marker value. If the selected marker was OFF, then it is turned on as a normal marker and a peak search is performed.
Page 859 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :CALCulate:ACPower:MARKer[1]|2|…|12:MINimum Remote Command :CALC:ACP:MARK:MIN Example Notes Sending this command selects the subopcoded marker State Saved Not part of saved state Pk-Pk Search Finds and displays the amplitude and frequency (or time, if in zero span) differences between the highest and lowest Y-Axis value.
Page 860 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Marker Frequency This is the fundamental control that you use to move a marker around on the trace. It is the same as "Marker Frequency" on page 853 on the Settings tab. Relative To Selects the marker to which the selected marker is relative (its reference marker).
Page 861 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Axis Scale of the marker. All markers have an associated trace; it is from that trace that they determine their attributes and behaviors, and it is to that trace that they go when they become Normal ...
Page 862 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Avg | Hold Number Specifies the number of measurement averages used to calculate the measurement result. The average will be displayed at the end of each sweep. After the specified number of average counts, the average mode (termination control) setting determines the average action.
Page 863 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Avg Mode Sets the Averaging Mode. This determines the averaging action after the specified number of data acquisitions (average count) is reached. – When set to EXPonential, the measurement averaging continues using the specified number of averages to compute each averaged value.
Page 864 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement FAST Provides the same method as the Integration BW method, but is optimized for speed to measure a W- CDMA signal SA Mode with CDMA2K radio standard selected: Provides faster measurement using the FFT method with a limited parameter flexibility. When this is selected, CDMA2K preset offsets are given and control of the following are unavailable: –...
Page 865 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Couplings IBW (Range) restricts the Res BW available for making this measurement to 30 kHz. When selected, Res BW is clipped to this value if required and an error number displayed Preset State Saved Saved in instrument state...
Page 866 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:CARR:LIST:COUP? Notes Some modes do not support Carrier subopcode 2. In those cases, commands with subopcode 2 are accepted without error but ignored For LTEAFDD or LTEATDD Modes, this control is not shown. In order to maintain backwards compat- ibility with legacy LTE FDD/TDD, the SCPI command is supported in LTE &...
Page 867 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement legacy LTE FDD/TDD Modes, the SCPI command is supported in the LTE & LTE-A converged applic- ations Couplings Coupled to number of carriers. When the SCPI command is sent, the number of carriers is set to the number of entries in the parameter list Preset State Saved...
Page 868 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:MCPower:CARRier[1]|2:LIST:WIDTh Backwards Compatibility SCPI Measurement Noise Bandwidth Specifies the Measurement Noise Bandwidth used to calculate the power in the carriers. Each Measurement Noise Bandwidth value is entered individually by selecting the desired carrier.
Page 869 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:CARRier[1]|2:LIST:BWIDth[:INTegration] SCPI [:SENSe]:MCPower:CARRier[1]|2:LIST:BANDwidth[:INTegration] [:SENSe]:MCPower:CARRier[1]|2:LIST:BWIDth[:INTegration] Method for Carrier Accesses the carrier configuration method settings. [:SENSe]:ACPower:CARRier[1]|2:LIST:FILTer[:RRC][:STATe] ON | OFF | 1 | 0, … Remote Command [:SENSe]:ACPower:CARRier[1]|2:LIST:FILTer[:RRC][:STATe]? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:CARR:LIST:FILT 0,0,0,0 Example :ACP:CARR:LIST:FILT?
Page 870 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:CARR2:LIST:FILT:ALPH 0.5 Example :ACP:CARR2:LIST:FILT:ALPH? Notes Some Modes do not support Carrier subopcode 2. In those cases, commands with subopcode 2 are accepted without error but ignored For LTEAFDD or LTEATDD Modes, this control is not shown. In order to maintain backwards compat- ibility with legacy LTE FDD/TDD Modes, the SCPI command is supported in the LTE &...
Page 871 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement which is defined in each 3GPP standard, regardless of ** RF BW = BWchannel,CA “Measure Carrier” for the uppermost and the lowermost carriers being Enabled or Disabled. When the Number of Component Carrier = 1, RF BW = BW = 2 x channel offset,RAT...
Page 872 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Mode: 5G NR [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE CTOCenter | CTOEdge | ETOCenter | Remote ETOEdge | RTOCenter | RTOEdge | RCTOCenter | SCTOCenter Command [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:TYPE? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS:TYPE ETOC Example :ACP:OFFS:TYPE? CTOCenter...
Page 873 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Diagram for MSR, LTEAFDD, LTEATDD, 5G NR Note: RF BW Edge and Outermost Carrier Edge are not always the same. e.g.) 5G NR (3GPP) defines BW_channel, CA which calculates F_offset,high and F_ offset,low asymmetrically with SCS shift.
Page 874 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement The list contains up to six (6) entries, depending on the mode selected, for offset frequencies. Each offset frequency in the list corresponds to a reference bandwidth in the bandwidth list. An offset frequency of zero turns the display of the measurement for that offset off, but the measurement is still made and reported.
Page 875 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:STAT 1,1,0,0,0,0 Example :ACP:OFFS2:LIST:STAT? Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is the same as the Offset F value Modes Values...
Page 876 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset When "Max Num of Offsets" on page 902 is set to 12, the preset value of Offset G ~ L is the same as the Offset F value Modes Values 2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz|2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz WCDMA...
Page 877 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:SIDE NEGative | BOTH | POSitive, … Remote Command [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:SIDE? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS:LIST:SIDE BOTH Example :ACP:OFFS:LIST:SIDE? Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are accepted without error but ignored If you set in an offset, result of the inactive side returns -999...
Page 878 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Mode Values 0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0,0 WCDMA 1, 1, 1, 1, 1, 1 | 1, 1, 1, 1, 1, 1 LTEAFDD, LTEATDD, 5G NR, MSR 0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0,0 Radio Test 0, 0, 0, 0, 0, 0...
Page 879 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Res BW Sets the resolution bandwidth. If an unavailable bandwidth is entered with the numeric keypad, the closest available bandwidth is selected. [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:RESolution <freq>,… Remote Command [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:RESolution? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:BAND:RES 220kHz,220kHz,220kHz,220kHz,220kHz,220kHz Example :ACP:OFFS2:LIST:BAND:RES?
Page 880 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:OFFSet[1]|2:LIST:BWIDth:RESolution:AUTO Backwards Compatibility SCPI Video BW Enables you to change the instrument post-detection filter (VBW). [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:VIDeo <freq>,… Remote Command [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:VIDeo? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:BAND:VID 5MHz,5MHz,5MHz,5MHz,5MHz,5MHz Example :ACP:OFFS2:LIST:BAND:VID? Notes The values shown in this table reflect the conditions after Mode Preset...
Page 881 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved [:SENSe]:ACPower:OFFSet[1]|2:LIST:BWIDth:VIDeo:AUTO Backwards Compatibility SCPI Filter Type Selects the type of bandwidth filter that is used. [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:SHAPe GAUSsian | Remote Command FLATtop,… [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:SHAPe? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:BAND:SHAP FLAT,GAUS,GAUS,GAUS,GAUS,GAUS Example :ACP:OFFS2:LIST:BAND:SHAP?
Page 882 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Dependencies When "RBW Filter Type" on page 834 is Flattop, or "Res BW" on page 831 Mode for the offset is Auto, this cell is grayed-out and disabled. Since Res BW Mode for the offset is preset to Auto on changing "Meas Method"...
Page 883 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:ABS -10,-10,-10,-10,-10,-10 Example :ACP:OFFS2:LIST:ABS? Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are accepted without error but ignored Preset When "Max Num of Offsets"...
Page 884 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:RCARrier? Command Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:RCAR 0,0,0,0,0,0 Example :ACP:OFFS2:LIST:RCAR? Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are accepted without error but ignored Preset When...
Page 885 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Modes Values -45, -60, 0, 0, 0, 0 | -45, -60, 0, 0, 0, 0 WCDMA -44.2, -49.2, -49.2, -49.2, -49.2, -49.2 | -32.2, -42.2, -42.2, -42.2, - 42.2, -42.2 LTEAFDD, LTEATDD, -44.2,-44.2,-44.2,-44.2,-44.2,-44.2 | -29.2, -29.2, -29.2, -29.2, -29.2, -29.2 5G NR...
Page 886 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved Saved in instrument state Min/Max -150.0/50.0 :CALCulate:MCPower:OFFSet:LIST:LIMit:NEGative[:UPPer]:DATA Backwards Compatibility (Power Suite, WCDMA) SCPI Rel Limit (PSD) Enters a relative limit value for the level of the power spectral density. This sets the amplitude levels to test against for any custom offsets.
Page 887 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved Saved in instrument state Min/Max -150.0 dB/50.0 dB Fail Mask Accesses a menu that lets you select one of the logics for the fail conditions between the measurement results and the test limits. The setting defines the type of testing to be done at any custom offset frequencies.
Page 888 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Modes Values REL, REL, REL, REL, REL, REL Radio Test State Saved Saved in instrument state ABSolute|AND|OR|RELative Range [:SENSe]:MCPower:OFFSet[1]|2:LIST:TEST Backwards Compatibility SCPI Offset Frequency Define Allows you to select “Offset” definition: CTOCenter From the lowermost carrier center frequency (for lower offset), the uppermost carrier center frequency (for upper offset) to the center frequency of each Offset Integ BW...
Page 889 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:OFFS:INN:TYPE ETOC Example :ACP:OFFS:INN:TYPE? STOCenter Preset State Saved Saved in instrument state CTOCenter|CTOEdge|ETOCenter|ETOEdge|STOCenter|STOEdge Range Mode: 5G NR [:SENSe]:ACPower:OFFSet[1]|2:INNer:TYPE CTOCenter | CTOEdge | ETOCenter | Remote ETOEdge | STOCenter | STOEdge | SCTOCenter Command [:SENSe]:ACPower:OFFSet[1]|2:INNer:TYPE? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink...
Page 890 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Diagram for Offset Freq Define Note: RF BW Edge and Outermost Carrier Edge are not always same. e.g.) 5G NR (3GPP) defines BW_channel,CA which calculates F_offset,high and F_ offset,low asymmetrically with SCS shift (*) For MSR, F_offset,high (or ,low) = F_offset,RAT,high (or ,low) Offset Freq Determines the frequency difference between the center of the main channel and...
Page 891 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Each Offset Freq state value is entered individually by selecting the desired carrier. Use the Enabled checkbox to turn the Offset Freq State on or off. The list contains up to 6 entries, depending on the mode selected, for offset frequencies.
Page 892 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Integ BW Sets the Integration Bandwidth for the offsets. Each resolution bandwidth in the list [:SENSe]:ACP:OFFSet corresponds to an offset frequency in the list defined by [n]:INNer:LIST[:FREQuency]. Enter each value individually by selecting the desired offset on the Offset menu key using the up down arrows, the knob, or the numeric keypad, then enter the Offset Integration Bandwidth using the Offset Integration Bandwidth menu key.
Page 893 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement – BOTH - Both sides in the sub-block gap are enabled – POSitive - The lower side in the sub-block gap only (that is, positive sideband of the lower sub-block) is enabled The diagram below shows the relation between the negative/positive offset side setups and the upper/lower results in the MSR, LTEAFDD and LTEATDD Modes.
Page 894 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is the same as the Offset F value Modes Values LTEAFDD 1,1,1,1,1,1 | 1,1,1,1,1,1 MSR, LTEATDD, 5G NR 0,0,0,0,0,0 | 0,0,0,0,0,0 State Saved...
Page 895 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement command is sent, a "Setting conflict" warning is generated Couplings When "Res BW" on page 831 Mode is Auto, this value is exactly the same as Res BW. When you change this value, Res BW Mode also changes to Man Preset When "Max Num of Offsets"...
Page 896 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:VIDeo:AUTO OFF | ON | 0 | Remote 1,… Command [:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:VIDeo:AUTO? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:INN:LIST:BAND:VID:AUTO 0,0,0,0,1,1 Example :ACP:OFFS2:INN:LIST:BAND:VID:AUTO? Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is ON, ON, ON, ON, ON, ON State Saved...
Page 897 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Auto, this cell is grayed-out and disabled. Since Res BW Mode for the offset is preset to Auto on changing "Meas Method" on page 863 to RBW, FAST or Fast Power, this cell is also grayed-out and disabled.
Page 898 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:OFFS:INN:LIST:PREF:AUTO? Dependencies Available only in LTEAFDD, LTEATDD and 5G NR Modes Couplings When in the LTEAFDD, LTEATDD Modes, the inner power ref type is set automatically when the power ref type state is auto according to the scopes of the sub-block gap in the following table Sub-block Gap Inner ACP offset Power Ref Type...
Page 899 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Offset Freq This column is the same as "Offset Freq" on page 932 in the Offset tab. Abs Limit Specifies an absolute limit value, which sets the absolute amplitude levels to test against for each of the custom offsets.
Page 900 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement You can turn off (not use) specific offsets with [:SENSe]:ACP:OFFSet [n]:INNer:LIST:STATe. The query returns the 6 sets of real numbers that are the current amplitude test limits, relative to the carrier, for each offset. Offset[n] n = 1 is base station and n = 2 is mobiles.
Page 901 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is 0 0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0, 0 State Saved Saved in instrument state Min/Max...
Page 902 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Max Num of Offsets Sets the max number of offsets: either 6 or 12. This setting applies only to SCPI operations. To specify the same behavior as that of the previous version, selecting 6 offsets is recommended. If you select 12 offsets, the :READ|:FETCh results returned by the queries increase accordingly.
Page 903 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved Saved in instrument state ON|OFF Range [:SENSe]:MCPower:LIMit[:STATe] Backwards Compatibility SCPI [:SENSe]:ACPower:LIMit[:STATe] Spur Avoidance Because VXT models M9410A/11A/15A are direct-conversion (zero-IF) receivers, feedthrough leakage from the local oscillator appears as a spurious signal (spur) at the center frequency.
Page 904 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Auto Couple Immediately puts all Auto/Man functions into Auto. Auto Couple is confined to the current measurement only. It does not affect other measurements in the Mode. In the Auto state, Auto/Man functions are said to be “coupled”, meaning their values change as you make changes to other values in the measurement.
Page 905 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Executing Auto Coupledoes not affect markers, marker functions, trace or display attributes, or any other instrument setting other than those specifically mentioned above. Measurement-Specific Details TOI (SA Mode only) Parameters affected by Auto Couple are: –...
Page 906 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :CONF:ACP Example Couplings Selecting Meas Preset restores all measurement parameters to their default values 3.7.13.2 Reference All ACP measurements are taken relative to a specific carrier frequency, relative to whose power the offset channel power is measured. The controls on this tab let you specify the reference carrier frequency and other parameters relevant to the reference carrier.
Page 907 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Carrier Lets you configure your carriers, carrier spacing, noise bandwidth and measurement method. Dependencies Appears in all Modes except MSR, LTEAFDD, LTEATDD and 5G NR Number of Carriers This is the same as "Number of Carriers"...
Page 908 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Carrier Pwr Present Configures the carriers for this measurement. Allows spaces to be inserted between carriers. Carriers with the power present parameter set to are carriers, and those with the power present parameter set to are spaces.
Page 909 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Carrier Spacing Sets the width of the carrier spacing. This is the value applied to all the current slots, whether they are carriers or spaces. Enter each carrier spacing value individually by selecting the desired carrier, and then enter the carrier width.
Page 910 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Each Measurement Noise Bandwidth value is entered individually by selecting the desired carrier. Enter the measurement noise bandwidth on the Carrier page of the Carr/Offset/Limits Config dialog. [:SENSe]:ACPower:CARRier[1]|2:LIST:BANDwidth[:INTegration] <freq>, … Remote Command [:SENSe]:ACPower:CARRier[1]|2:LIST:BANDwidth[:INTegration]? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink...
Page 911 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:CARRier[1]|2:LIST:FILTer[:RRC][:STATe] ON | OFF | 1 | 0, … Remote Command [:SENSe]:ACPower:CARRier[1]|2:LIST:FILTer[:RRC][:STATe]? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:CARR:LIST:FILT 0,0,0,0 Example :ACP:CARR:LIST:FILT? Notes The binary values translate as follows: 1|ON RRC Weighted 0|OFF...
Page 912 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved Saved in instrument state Min/Max 0.01/1.0 Offset Lets you configure the spacing of the offset regions. Offset Frequency Define Lets you select offset frequency definition. Each standard defines each offset frequency from Carrier.
Page 913 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Enabled or Disabled. When the Number of Component Carrier within each sub- block = 1, sub-block (bandwidth) = BW = 2 x F channel offset,RAT "Diagrams for Offset Freq Define" on page 914.
Page 914 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:OFFS:TYPE? CTOCenter Preset State Saved Saved in instrument state CTOCenter | CTOEdge | ETOCenter | ETOEdge | RTOCenter | RTOEdge | RCTOCenter Range | SCTOCenter Diagrams for Offset Freq Define Details depend on the selected mode. Diagram for Modes other than MSR, LTEAFDD, LTEATDD, 5G NR Short Range Comms &...
Page 915 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Diagram for MSR, LTEAFDD, LTEATDD, 5G NR Note: RF BW Edge and Outermost Carrier Edge are not always the same. e.g.) 5G NR (3GPP) defines BW_channel, CA which calculates F_offset,high and F_ offset,low asymmetrically with SCS shift.
Page 916 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement The list contains up to six (6) entries, depending on the mode selected, for offset frequencies. Each offset frequency in the list corresponds to a reference bandwidth in the bandwidth list. An offset frequency of zero turns the display of the measurement for that offset off, but the measurement is still made and reported.
Page 917 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:STAT 1,1,0,0,0,0 Example :ACP:OFFS2:LIST:STAT? Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is the same as the Offset F value Modes Values...
Page 918 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset When "Max Num of Offsets" on page 902 is set to 12, the preset value of Offset G ~ L is the same as the Offset F value Modes Values 2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz|2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz WCDMA...
Page 919 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:SIDE NEGative | BOTH | POSitive, … Remote Command [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:SIDE? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS:LIST:SIDE BOTH Example :ACP:OFFS:LIST:SIDE? Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are accepted without error but ignored If you set in an offset, result of the inactive side returns -999...
Page 920 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Mode Values 0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0,0 WCDMA 1, 1, 1, 1, 1, 1 | 1, 1, 1, 1, 1, 1 LTEAFDD, LTEATDD, 5G NR, MSR 0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0,0 Radio Test 0, 0, 0, 0, 0, 0...
Page 921 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Res BW Sets the resolution bandwidth. If an unavailable bandwidth is entered with the numeric keypad, the closest available bandwidth is selected. [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:RESolution <freq>,… Remote Command [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:RESolution? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:BAND:RES 220kHz,220kHz,220kHz,220kHz,220kHz,220kHz Example :ACP:OFFS2:LIST:BAND:RES?
Page 922 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:OFFSet[1]|2:LIST:BWIDth:RESolution:AUTO Backwards Compatibility SCPI Video BW Enables you to change the instrument post-detection filter (VBW). [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:VIDeo <freq>,… Remote Command [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:VIDeo? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:BAND:VID 5MHz,5MHz,5MHz,5MHz,5MHz,5MHz Example :ACP:OFFS2:LIST:BAND:VID? Notes The values shown in this table reflect the conditions after Mode Preset...
Page 923 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved [:SENSe]:ACPower:OFFSet[1]|2:LIST:BWIDth:VIDeo:AUTO Backwards Compatibility SCPI Filter Type Selects the type of bandwidth filter that is used. [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:SHAPe GAUSsian | Remote Command FLATtop,… [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:BANDwidth:SHAPe? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:BAND:SHAP FLAT,GAUS,GAUS,GAUS,GAUS,GAUS Example :ACP:OFFS2:LIST:BAND:SHAP?
Page 924 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Dependencies When "RBW Filter Type" on page 834 is Flattop, or "Res BW" on page 831 Mode for the offset is Auto, this cell is grayed-out and disabled. Since Res BW Mode for the offset is preset to Auto on changing "Meas Method"...
Page 925 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:ABS -10,-10,-10,-10,-10,-10 Example :ACP:OFFS2:LIST:ABS? Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are accepted without error but ignored Preset When "Max Num of Offsets"...
Page 926 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:RCARrier? Command Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:LIST:RCAR 0,0,0,0,0,0 Example :ACP:OFFS2:LIST:RCAR? Notes Some Modes do not support Offset subopcode 2. In those cases, commands with subopcode 2 are accepted without error but ignored Preset When...
Page 927 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Modes Values -45, -60, 0, 0, 0, 0 | -45, -60, 0, 0, 0, 0 WCDMA -44.2, -49.2, -49.2, -49.2, -49.2, -49.2 | -32.2, -42.2, -42.2, -42.2, - 42.2, -42.2 LTEAFDD, LTEATDD, -44.2,-44.2,-44.2,-44.2,-44.2,-44.2 | -29.2, -29.2, -29.2, -29.2, -29.2, -29.2 5G NR...
Page 928 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved Saved in instrument state Min/Max -150.0/50.0 :CALCulate:MCPower:OFFSet:LIST:LIMit:NEGative[:UPPer]:DATA Backwards Compatibility (Power Suite, WCDMA) SCPI Rel Limit (PSD) Enters a relative limit value for the level of the power spectral density. This sets the amplitude levels to test against for any custom offsets.
Page 929 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement State Saved Saved in instrument state Min/Max -150.0 dB/50.0 dB Fail Mask Accesses a menu that lets you select one of the logics for the fail conditions between the measurement results and the test limits. The setting defines the type of testing to be done at any custom offset frequencies.
Page 930 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Modes Values REL, REL, REL, REL, REL, REL Radio Test State Saved Saved in instrument state ABSolute|AND|OR|RELative Range [:SENSe]:MCPower:OFFSet[1]|2:LIST:TEST Backwards Compatibility SCPI Offset Frequency Define Allows you to select “Offset” definition: CTOCenter From the lowermost carrier center frequency (for lower offset), the uppermost carrier center frequency (for upper offset) to the center frequency of each Offset Integ BW...
Page 931 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:OFFS:INN:TYPE ETOC Example :ACP:OFFS:INN:TYPE? STOCenter Preset State Saved Saved in instrument state CTOCenter|CTOEdge|ETOCenter|ETOEdge|STOCenter|STOEdge Range Mode: 5G NR [:SENSe]:ACPower:OFFSet[1]|2:INNer:TYPE CTOCenter | CTOEdge | ETOCenter | Remote ETOEdge | STOCenter | STOEdge | SCTOCenter Command [:SENSe]:ACPower:OFFSet[1]|2:INNer:TYPE? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink...
Page 932 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Diagram for Offset Freq Define Note: RF BW Edge and Outermost Carrier Edge are not always same. e.g.) 5G NR (3GPP) defines BW_channel,CA which calculates F_offset,high and F_ offset,low asymmetrically with SCS shift (*) For MSR, F_offset,high (or ,low) = F_offset,RAT,high (or ,low) Offset Freq Determines the frequency difference between the center of the main channel and...
Page 933 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Each Offset Freq state value is entered individually by selecting the desired carrier. Use the Enabled checkbox to turn the Offset Freq State on or off. The list contains up to 6 entries, depending on the mode selected, for offset frequencies.
Page 934 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Integ BW Sets the Integration Bandwidth for the offsets. Each resolution bandwidth in the list [:SENSe]:ACP:OFFSet corresponds to an offset frequency in the list defined by [n]:INNer:LIST[:FREQuency]. Enter each value individually by selecting the desired offset on the Offset menu key using the up down arrows, the knob, or the numeric keypad, then enter the Offset Integration Bandwidth using the Offset Integration Bandwidth menu key.
Page 935 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement – BOTH - Both sides in the sub-block gap are enabled – POSitive - The lower side in the sub-block gap only (that is, positive sideband of the lower sub-block) is enabled The diagram below shows the relation between the negative/positive offset side setups and the upper/lower results in the MSR, LTEAFDD and LTEATDD Modes.
Page 936 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is the same as the Offset F value Modes Values LTEAFDD 1,1,1,1,1,1 | 1,1,1,1,1,1 MSR, LTEATDD, 5G NR 0,0,0,0,0,0 | 0,0,0,0,0,0 State Saved...
Page 937 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement command is sent, a "Setting conflict" warning is generated Couplings When "Res BW" on page 831 Mode is Auto, this value is exactly the same as Res BW. When you change this value, Res BW Mode also changes to Man Preset When "Max Num of Offsets"...
Page 938 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:VIDeo:AUTO OFF | ON | 0 | Remote 1,… Command [:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:BANDwidth:VIDeo:AUTO? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:OFFS2:INN:LIST:BAND:VID:AUTO 0,0,0,0,1,1 Example :ACP:OFFS2:INN:LIST:BAND:VID:AUTO? Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is ON, ON, ON, ON, ON, ON State Saved...
Page 939 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Auto, this cell is grayed-out and disabled. Since Res BW Mode for the offset is preset to Auto on changing "Meas Method" on page 863 to RBW, FAST or Fast Power, this cell is also grayed-out and disabled.
Page 940 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:OFFS:INN:LIST:PREF:AUTO? Dependencies Available only in LTEAFDD, LTEATDD and 5G NR Modes Couplings When in the LTEAFDD, LTEATDD Modes, the inner power ref type is set automatically when the power ref type state is auto according to the scopes of the sub-block gap in the following table Sub-block Gap Inner ACP offset Power Ref Type...
Page 941 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Offset Freq This column is the same as "Offset Freq" on page 932 in the Offset tab. Abs Limit Specifies an absolute limit value, which sets the absolute amplitude levels to test against for each of the custom offsets.
Page 942 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement You can turn off (not use) specific offsets with [:SENSe]:ACP:OFFSet [n]:INNer:LIST:STATe. The query returns the 6 sets of real numbers that are the current amplitude test limits, relative to the carrier, for each offset. Offset[n] n = 1 is base station and n = 2 is mobiles.
Page 943 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is 0 0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0, 0 State Saved Saved in instrument state Min/Max...
Page 944 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Reference Carrier (Carrier Index) Sets the reference carrier. Relative power measurements are made from the reference carrier. If set to Auto, the measurement selects the carrier with the highest power as the reference carrier and the Ref Carrier parameter is updated.
Page 945 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:CARRier[1]|2:RCARrier:AUTO OFF | ON | 0 | 1 Remote Command [:SENSe]:ACPower:CARRier[1]|2:RCARrier:AUTO? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:CARR:RCAR:AUTO OFF Example :ACP:CARR:RCAR:AUTO? Couplings If you enter a ref carrier this parameter will be set to manual Preset State Saved Range...
Page 946 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Notes Note that Carrier subopcode 2 is not supported in some Modes. In those cases, Carrier subopcode 1 is used for both BTS and MS and commands with subopcode 2 are accepted without error but ignored Dependencies Not available in multicarrier applications (MSR, 5GNR, LTE Modes) Couplings...
Page 947 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement If there is only one carrier present, Ref Carrier Freq is the same as Center Frequency Preset Calculated based on the current Center Frequency State Saved Saved in instrument state Min/Max -79.999995 MHz/Hardware Dependent [:SENSe]:MCPower:RCFRequency[1]|2 (Power Suite) Backwards...
Page 948 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Power Ref Selects the power reference type. This control has two different forms, depending on the currently-selected Mode: – "Power Ref (Modes: SA, WCDMA, VMA, SRComms)" on page 948 – "Power Ref (Modes: LTEAFDD, LTEATDD, 5G NR, MSR)" on page 948 Power Ref (Modes: SA, WCDMA, VMA, SRComms) Type Option...
Page 949 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Type Option Description evaluated MPCarrier Max Power Maximum carrier power among the carriers of Measure Carrier On is the Carrier reference of measurement. If Measure Carriers of all the carriers are off, the reference power and all the relative power results are NAN.
Page 950 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement The powers of carriers are not included in the reference power when their Measure Carriers are Off. When Measure Carriers of all the carriers in a sub-block are Off, the reference power and all the relative power results are NaN. Therefore, relative limits are not evaluated.
Page 951 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Measurement Type = PSD Ref [:SENSe]:ACPower:CARRier[1]|2:PREFerence:TYPE LRCarriers | MPCarrier | CINDex Remote | MANual | MPCSubblock | ACBandwidth | TMCarriers | MINPcarrier | MINSubblock Command | LRSubblocks [:SENSe]:ACPower:CARRier[1]|2:PREFerence:TYPE? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:CARR:PREF:TYPE CIND Example :ACP:CARR:PREF:TYPE?
Page 952 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:ACPower:CARRier[1]|2:AUTO[:STATe]? Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink :ACP:CARR:AUTO OFF Example :ACP:CARR:AUTO? Preset State Saved Saved in instrument state Range Auto | Man [:SENSe]:MCPower:CARRier[1]|2:AUTO[:STATe] Backwards Compatibility SCPI Total Power Ref Sets manual total power reference.
Page 953 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Min/Max -200 dBm/200 dBm [:SENSe]:MCPower:CARRier[1]|2[:POWer] Backwards Compatibility SCPI Total Power Ref (Modes: LTEAFDD, LTEATDD, 5G NR, MSR) Sets the multi-carrier power reference. This is used when Power Ref is Manual and "Measurement Type"...
Page 954 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement – "PSD Ref (Modes: SA, WCDMA, VMA, SRComms)" on page 954 – "PSD Ref (Modes: LTEAFDD, LTEATDD, 5GNR, MSR)" on page 955 PSD Ref (Modes: SA, WCDMA, VMA, SRComms) This is used when "Power Ref"...
Page 955 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset State Saved Saved in instrument state Auto|Man Range [:SENSe]:ACPower:CARRier[1]|2:AUTO[:STATe] OFF | ON | 0 | 1 Backwards Compatibility [:SENSe]:ACPower:CARRier[1]|2:AUTO[:STATe]? SCPI [:SENSe]:MCPower:CARRier[1]|2:AUTO[:STATe] OFF | ON | 0 | 1 [:SENSe]:MCPower:CARRier[1]|2:AUTO[:STATe]? PSD Ref (Modes: LTEAFDD, LTEATDD, 5GNR, MSR) Sets manual PSD reference.
Page 956 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :UNIT:ACP:POW:PSD DBMMHZ Example :UNIT:ACP:POW:PSD? Dependencies Enabled when "Measurement Type" on page 947 is PSD Reference Couplings When the PSD unit is changed, the PSD reference result of :MEAS|READ|FETCH:ACP[n]? is also changed by the PSD unit basis (in either dBm/Hz or dBm/MHz) DBMHZ Preset State Saved...
Page 957 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement conditionally shown according to the selected radio standard) The SCPI command is kept only for backward compatibility. Writing new SCPI script with this command since XA25 is not recommendable. Using the SCPI command of “preset to standard” instead is advised Couplings “Preset to Std”...
Page 958 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Range 802.15.4 OQPSK 2450 MHz | 802.15.4 BPSK 915 MHz | 802.15.4 BPSK 868/950 MHz | 802.15.4 OQPSK 780 MHz | 802.15.4 OQPSK 915 MHz | 802.15.4 OQPSK 868 MHz | Z-Wave R1 (9.6 kbps) FSK | Z-Wave R2 (40 kbps) FSK | Z-Wave R3 (100kbps) GFSK | LoRa CSS 7.815 kHz| LoRa CSS 10.4167 kHz| LoRa CSS 15.625 kHz| LoRa CSS 20.8333 kHz| LoRa CSS 31.25 kHz| LoRa CSS 41.667 kHz| LoRa CSS 62.5 kHz| LoRa CSS 125 kHz| LoRa CSS 203.125 kHz| LoRa CSS 250 kHz| LoRa CSS 406.25 kHz|...
Page 959 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7.13.4 Advanced Contains controls for setting advanced functions of the instrument. This tab does not appear in the following instruments: – EXM – VXT model M9420A Phase Noise Opt Selects the LO (local oscillator) phase noise behavior for various operating conditions.
Page 960 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:FREQ:SYNT:AUTO 1 Example :ACP:FREQ:SYNT:AUTO? Preset Parameter Options, Installed Options, Auto Rules & Ranges The Phase Noise Optimization control lets you optimize the setup and behavior of the Local Oscillator (LO) depending on your specific measurement conditions. You may wish to trade off noise and speed, for example, to make a measurement faster without regard to noise or with optimum noise characteristics without regard to speed.
Page 961 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Best Close-in Without option EP0 :FREQ:SYNT 1 The LO phase noise is optimized for smaller offsets from the carrier, at the expense of phase noise farther out. The actual frequency offset within which noise is optimized is shown with in square brackets, as this can vary depending on the hardware set in use.
Page 962 961. It is available with the "Fast Tuning" on page 962 label for convenience, and to make the user interface more consistent with other X-Series instrument family members. (In models whose hardware does not provide for a "Fast Tuning" on page 962...
Page 963 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Auto Optimization Rules X-Series instruments have several grades of LO, offering different configurations when in the Auto Mode. The rules for Auto selection are as follows: Models with Option Conditions Selection Center frequency is <...
Page 964 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Models with Option Conditions Selection All other conditions "Best Wide- offset" on page All Other Models Span > 12.34 MHz, or "Fast Tuning" on page 962 Note that in these models, the RBW >...
Page 965 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Option Option # Phase Noise Option Range EP2, EP3, EP5 Best Close-in [offset < 70 kHz] Best Wide-offset [offset > 100 kHz] Fast Tuning [medium loop bw] Best Close-in [offset < 90 kHz] Best Wide-offset [offset >...
Page 966 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Noise Floor Extension Lets you configure Noise Floor Extension (NFE). All Modes that support NFE let you set it on or off. Additionally, some Modes support two “on” states for NFE, Full and Adaptive, as described below.
Page 967 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement – [:SENSe]:CORRection:NOISe:FLOor ON|OFF|1|0 is retained, with the default changed to for Modes that support Adaptive NFE – [:SENSe]:CORRection:NOISe:FLOor:ADAPtive ON|OFF|1|0 is added (for certain Modes), default = When NFE is On or Full, the expected noise power of the instrument (derived from a factory calibration) is subtracted from the trace data.
Page 968 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement In Adaptive NFE, there is not the same dramatic visual impact on the noise floor as there is in Full NFE. Adaptive NFE controls the amount of correction that is applied based on other instrument settings like RBW, averaging and sweep time.
Page 969 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement [:SENSe]:CORRection:NOISe:FLOor:ADAptive? Command Example First turn NFE on, this is Full mode :CORR:NOIS:FLO ON Then set it to Adaptive :CORR:NOIS:FLO:ADAP ON Couplings To maintain backwards compatibility, sending :CORR:NOIS:FLO ON turns NFE AdaptiveOFF. To turn Adaptive on, you must issue the commands in the proper order, as shown in the example above Preset Not affected by Mode Preset, but set to...
Page 970 Recalibration of Noise Floor In instruments with the NF2 license installed, the calibrated noise floor used by Noise Floor Extension should be refreshed periodically. Keysight recommends that the Characterize Noise Floor operation be performed after the first 500 hours of operation, and once every calendar year. To do this, use "Characterize Noise Floor"...
Page 971 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Fast Power RBW Mode Specifies RBW behavior of Fast Power under Meas Method. Option SCPI Description SPEed Best Speed The acquisition RBW is set to be configured for best speed. The RBW is automatically calculated, and is not configurable EXPLicit Explicit...
Page 972 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:FILT:BAND DB3 Example :ACP:FILT:BAND? Dependencies Applicable for carriers and offsets whose filter method is not RRC, and when "Meas Method" on page is other than Preset State Saved Saved in instrument state Range -3 dB|-6 dB 3.7.13.5 Global...
Page 973 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :INST:COUP:FREQ:CENT? Preset Set to on Global Settings, Restore Defaults and System, Restore Defaults, All Modes ALL|NONE Range Preset :GLOBal:FREQuency:CENTer[:STATe] 1 | 0 | ON | OFF Backwards Compatibility SCPI :GLOBal:FREQuency:CENTer[:STATe]? Global EMC Std When this control is switched ON, the current Mode’s EMC Std is copied into the Global EMC Std, and from then on all Modes that support global settings use the Global EMC Std, so you can switch between any of these Modes and the EMC Std...
Page 974 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement 3.7.13.6 Offset RRC Weighting (Backwards Compatibility SCPI) :ACP:FILT OFF Example :ACP:FILT? Couplings This command is an alias of: [:SENSe]:ACPower:OFFSet[1]|2:LIST:FILTer[:RRC][:STATe] Sending the command sets values of all offsets for BS and MS, but the query always returns a value of BS Offset A Preset SA, LTEAFDD, LTEATDD, MSR...
Page 975 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement :ACP:CARR2:LIST:METH? Notes Maximum of Array length depends on the number of carriers Couplings This command is an alias of: [:SENSe]:ACPower:CARRier[1]|2:LIST:FILTer[:RRC][:STATe] The enum value translates as follows: – RRC Weighted = 1|ON –...
Page 976 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement You can select a shorter sweep time to improve the measurement throughput (with some potential unspecified accuracy reduction), but the Meas Uncal indicator will appear if the sweep time you set is less than the calculated Auto Sweep time. You can also select a longer sweep time, which can be useful (for example) for obtaining accurate insertion loss measurements on very narrowband filters.
Page 977 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement changes when these parameters are changed When you manually set a value when in the Auto state, the state automatically changes to Man Preset Automatically Calculated unless noted below WCDMA Mode –...
Page 978 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement When in Auto, this parameter’s value is determined by other parameters, such as Span, RBW and VBW. You can manually increase this parameter value from this Auto value. If increased, the instrument acquires signal for the specified time duration for each chunk.
Page 979 X-Series B-models have a Cont/Single toggle control instead of Single and Cont hardkeys, but it is still true that, if in single measurement, the Cont/Single toggle control never restarts a measurement and...
Page 980 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement If the instrument is in Single measurement mode, pressing the Cont/Single toggle control does not zero the count and does not cause the sweep to be reset; the only action is to put the instrument into Continuous measurement operation. If the instrument is already in Continuous sweep: –...
Page 981 (displayed average count reset to 1) for a trace in Clear Write, but did not Notes restart Max Hold and Min Hold :INIT:REST In X-Series, the Restart hardkey and the command restart not only Trace Average, but MaxHold and MinHold traces as well More Information The Restart function first aborts the current sweep or measurement as quickly as possible.
Page 982 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement sweep is equivalent to a single measurement. A single sweep is taken after the trigger condition is met; and the instrument stops sweeping once that sweep has completed. However, with Average/Hold Num >1, and at least one trace set to Trace Average, Max Hold, or Min Hold, or a Waterfall window being displayed, multiple sweeps/data acquisitions are taken for a single measurement.
Page 983 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Averaging The weighting factor used for averaging is k. This is also the average/hold count for how many valid sweeps (data acquisitions) have been done. This is used for comparisons with N, as those comparisons always needs to be based on valid completed sweeps.
Page 984 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Notes :INIT:CONT is ON, then a new continuous measurement will start immediately, with sweep (data acquisition) occurring once the trigger condition has been met is OFF, then :INIT:IMM :INIT:CONT is used to start a single measurement, with sweep (data acquisition) occurring once the trigger condition has been met Dependencies For continuous measurement,...
Page 985 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement instrument amplitude accuracy specifications only apply when Auto Sweep Time is set to ACCuracy. Additional amplitude errors that occur when Auto Sweep Time is set to NORMal usually well under 0.1 dB, though this is not guaranteed. Because of the faster sweep times and still low errors, NORMal is the preferred setting of Auto Sweep...
Page 986 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Cont, a new trace is taken. If any trace is in average or hold, the averaging starts over. Because of sweep time quantization issues, the knob and up/down keys cannot be used to adjust the number of points.
Page 987 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Auto Scaling Toggles the scale coupling function On or Off. :DISPlay:ACPower:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:COUPle 0 | 1 | OFF | ON Remote Command :DISPlay:ACPower:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:COUPle? :DISP:ACP:WIND:TRAC:X:COUP ON Example :DISP:ACP:WIND:TRAC:X:COUP? Couplings When Auto Scaling is and the "Restart"...
Page 988 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Notes The selected trace is remembered even when not in the Trace menu Dependencies For the Swept SA measurement: – In Image Suppress mode, when you select a trace it becomes the active trace, and the formerly active trace goes into View –...
Page 989 View and Blank. Averaging was global to all traces and was controlled under the BW/Avg menu. In X-Series, trace averaging can be done on a per-trace basis. The Trace Modes (now called Trace Types) are Clear/Write, Trace Average, Max Hold and Min Hold.
Page 990 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement retained and a new Trace Type command has been added. The :TRACe:MODE command is retained for backwards compatibility, and the :TRACe:TYPE, :TRACe:UPDate :TRACe:DISPlay commands introduced for ongoing use. The old Trace Modes are selected using :TRAC:MODE, whose parameters are mapped into calls to :TRACe:TYPE, :TRACe:UPDate and :TRACe:DISPlay, and the old...
Page 991 [:STATe] ON|OFF|1|0 was used to turn Averaging on or off In X-Series, Averaging is turned on or off on a per-trace basis, so it can be on for one trace and off for another For backwards compatibility, the old global Average State variable is retained solely as a legacy...
Page 992 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Pressing Clear/Write stops the current sweep and initiates a new one, so Trace Average, Max Hold and Min Hold data may be interrupted in mid-sweep when Clear/Write is pressed, and therefore may not accurately reflect the displayed count.
Page 993 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Pressing Max Hold for the selected trace, or sending :TRAC:TYPE MAXH for the specified trace, sets the Trace Type to Max Hold, clears the trace , initiates a new sweep, and restarts the hold sequence, even if you are already in Max Hold. When in Max Hold, if a measurement-related instrument setting is changed(that is, one which requires new data to be taken, like Center Frequency or Attenuation), the Max Hold sequence restarts and a new sweep is initiated but the trace is not...
Page 994 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement – the control is provided because it may not be obvious that reselecting the same selection from a radio button menu will take any action. This control displays different labels, depending on the selected Trace Type: –...
Page 995 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement already selected Loading a trace from a file puts that trace in View regardless of the state it was in when it was saved; as does being the target of a Copy or a participant in an Exchange Trace Update State On/Off Remote For Swept SA Measurement (in SA Mode):...
Page 996 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Preset For Swept SA Measurement (in SA Mode): 1|0|0|0|0|0 for Trace 1; for 2–6 For all other measurements: 1|0|0 for Trace 1; for 2 &3 State Saved Saved in instrument state More Information When a trace becomes inactive, any update from the :SENSe...
Page 997 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Math Function Trace Math functions perform mathematical operations between traces and, in some cases, user-specified offsets. When in a Trace Math function, the indicated function is performed during the sweep with the math function used in place of a detector.
Page 998 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Turns off trace math for trace 1 Notes The Trace Math Function command has 6 main set of parameters: - Set 1 defines the “result trace”: TRACE1|…|TRACE6 -Set 2 defines the “function”: PDIFference|PSUM|LOFFset|LDIFference|OFF - Set 3 is a “trace operand”...
Page 999 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement Trace Math Options To generate a trace math result, you must take a sweep . The trace math engine, IMPORTANT described below, operates in concert with the sweep engine in the instrument. Until a sweep has been taken, even if the constituent traces are not in Update mode, no result is generated.
Page 1000 3 Short-Range Comms & IoT Mode 3.7 ACP Measurement DestinationTrace = 10 log(10(1/10)(FirstTrace) + 10(1/10)(SecondTrace)) The values of the trace points are assumed to be in a decibel scale, as they are internally stored. If a point in either trace operand is equal to maxtracevalue, the resultant point is also maxtracevalue.
