Commands Quick Reference
Table 50 General :TRIGger Commands Summary
Command
:TRIGger:FORCe (see
page 1057)
:TRIGger:HFReject {{0
| OFF} | {1 | ON}}
page 1058)
(see
:TRIGger:HOLDoff
<holdoff_time> (see
page 1059)
:TRIGger:HOLDoff:MAXi
mum <max_holdoff>
page 1060)
(see
:TRIGger:HOLDoff:MINi
mum <min_holdoff>
page 1061)
(see
:TRIGger:HOLDoff:RAND
om {{0 | OFF} | {1 |
page 1062)
ON}} (see
:TRIGger:LEVel:ASETup
page 1063)
(see
:TRIGger:LEVel:HIGH
<level>, <source>
page 1064)
(see
:TRIGger:LEVel:LOW
<level>, <source>
page 1065)
(see
:TRIGger:MODE <mode>
page 1066)
(see
152
Query
n/a
:TRIGger:HFReject?
page 1058)
(see
:TRIGger:HOLDoff?
page 1059)
(see
:TRIGger:HOLDoff:MAXi
page 1060)
mum? (see
:TRIGger:HOLDoff:MINi
page 1061)
mum? (see
:TRIGger:HOLDoff:RAND
page 1062)
om? (see
n/a
:TRIGger:LEVel:HIGH?
<source> (see
page 1064)
:TRIGger:LEVel:LOW?
<source> (see
page 1065)
:TRIGger:MODE? (see
page 1066)
Keysight InfiniiVision M9241/42/43A PXIe Oscilloscopes SCPI Programmer's Guide
Options and Query Returns
n/a
{0 | 1}
<holdoff_time> ::= 60 ns to 10 s
in NR3 format
<max_holdoff> ::= maximum
holdoff time in seconds in NR3
format
<min_holdoff> ::= minimum
holdoff time in seconds in NR3
format
<setting> ::= {0 | 1}
n/a
<level> ::= .75 x full-scale
voltage from center screen in NR3
format.
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
<level> ::= .75 x full-scale
voltage from center screen in NR3
format.
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
<mode> ::= {EDGE | GLITch |
PATTern | TV | DELay | EBURst |
OR | RUNT | SHOLd | TRANsition |
SBUS{1 | 2} | NFC}
