:SEARch:SERial:CAN:MODE

Command Syntax
:SEARch:SERial:CAN:MODE <value>
<value> ::= {IDEither | IDData | DATA | IDRemote | ERRor | ACKerror
The :SEARch:SERial:CAN:MODE command selects the type of CAN information to
find in the Lister display:
Cond ition
IDEither
IDData
DATA
IDRemote
ERRor
ACKerror
FORMerror
STUFferror
CRCerror
ALLerrors
OVERload
MESSage
MSIGnal
Query Syntax
:SEARch:SERial:CAN:MODE?
The :SEARch:SERial:CAN:MODE? query returns the currently selected mode.
Return Format
<value><NL>
<value> ::= {IDE | IDD | DATA | IDR | ERR | ACK | FORM | STUF | CRC
See Also •
•
•
Keysight InfiniiVision M9241/42/43A PXIe Oscilloscopes SCPI Programmer's Guide
(see page 1354)
| FORMerror | STUFferror | CRCerror | ALLerrors | OVERload
| MESSage | MSIGnal}
Front-panel name
Frame ID
Data Frame ID
Data Frame ID and Data
Remote Frame ID
Error Frame
Acknowledge Error
Form Error
Stuff Error
CRC Field Error
All Errors
Overload Frame
Message
Message and Signal
(non-FD)
| ALL | OVER | MESS | MSIG}
Chapter 28, ":SEARch Commands," starting on page 933
":SEARch:SERial:CAN:PATTern:DATA"
":SEARch:SERial:CAN:PATTern:ID"
Description
Finds remote or data frames matching the specified ID.
Finds data frames matching the specified ID.
Finds data frames matching the specified ID and data.
Finds remote frames with the specified ID.
Finds CAN active error frames.
Finds the acknowledge bit if the polarity is incorrect.
Finds reserved bit errors.
Finds 6 consecutive 1s or 6 consecutive 0s, while in a
non-error or non overload frame.
Finds when the calculated CRC does not match the
transmitted CRC.
Finds any form error or active error.
Finds CAN overload frames.
Finds a symbolic message.
Finds a symbolic message and a signal value.
on page 973
on page 975
